CIRCUIT ID:
--------------------- For Information or Technical Support -------------------
Support Hours ( Normal 7am - 7pm CST, Emergency 7 days x 24 hours )
Phone: 800.726.8663 / 888.873.HDSL
-------------------------------------------------------------------------------
HTU-C INFORMATION
-------------------—
S/N :
CLEI:
MANF: /
HRE #1 INFORMATION
--------------------
S/N : B905A5505
CLEI: T1RGDJEDAA
MANF: 05/99
CIRCUIT ID:
61246026L6-5B
ADTRAN
901 Explorer Boulevard
Huntsville, Alabama 35806-2807
Fax: 256.963.6217
SIGNAL QUALITY
[X] 9 [X]
L[X] 8 L[X]
O[X] 7 O[X]
O[X] 6 O[X]
P[X] 5 P[X]
[X] 4 [X]
1[X] 3 2[X]
[X] 2 [X]
[X] 1 [X]
[X] 0 [X]
AT HTU-C
Press "M" to view Main Menu.

Figure 6. Introductory Menu Screen

ADTRAN HDSL MAIN MENU
1) CURRENT SYSTEM STATUS
2) PERFORMANCE HISTORY
3) ADTRAN INFORMATION
4) LOOPBACK OPTIONS
5) SELF-TEST
6) PROVISIONING
7) TROUBLESHOOTING
H) ALARM HISTORY
S) SET TIME/DATE/CIRCUIT ID
Choose a screen by pressing the corresponding number.

Figure 7. HDSL Main Menu Screen

Section 61246026L6-5, Issue 2
01/01/99
Internet: www.adtran.com
HTU-R INFORMATION
--------------------
S/N :
CLEI:
MANF: /
HRE #2 INFORMATION
--------------------
S/N : A917C2045
CLEI: T1R6DTEDAA
MANF: 06/99
00:10:57
SIGNAL QUALITY
[X] 9 [X]
L[X] 8 L[X]
O[X] 7 O[X]
O[X] 6 O[X]
P[X] 5 P[X]
[X] 4 [X]
1[X] 3 2[X]
[X] 2 [X]
[X] 1 [X]
[X] 0 [X]
AT HTU-R
01/01/99 00:09:42
