Figure 10. Loopback Options Screen; Figure 11. Self-Test Options Screen - ADTRAN T200 Installation And Maintenance Manual

CIRCUIT ID:
--->|-----|<=====>|-----|<=====>|-----|<=====>|-----|<—-
NET |
<---|-----|<=====>|-----|<=====>|-----|<=====>|-----|—>
CIRCUIT ID:
12
LOOPBACK OPTIONS
_____ _____
|HTU-C| |HRE 1|
| | LP1 | |
| | | |
| | |
| | LP2 | |
| | | |
|_____| |_____|
1) LOOPBACK TO NETWORK
2) LOOPBACK TO CUSTOMER AT HTU-C = INACTIVE
3) LOOPBACK TO NETWORK
4) LOOPBACK TO CUSTOMER AT HTU-R = INACTIVE
5) LOOPBACK TO NETWORK
6) LOOPBACK TO CUSTOMER AT HRE-1 = UNAVAILABLE
7) LOOPBACK TO NETWORK
8) LOOPBACK TO CUSTOMER AT HRE-2 = UNAVAILABLE
Press corresponding number to toggle loopback option.
Press "M" to return to the Main Menu

Figure 10. Loopback Options Screen

Press "S" to initiate HTU-C and HTU-R self-tests.
Press "M" to return to the Main Menu.

Figure 11. Self-Test Options Screen

Section 61246026L6-5, Issue 2
_____
|HRE 2| |HTU-R|
LP1 | | LP1 |
| | |
| | |
LP2 | | LP2 |
| | |
|_____| |_____|
AT HTU-C = INACTIVE
AT HTU-R = INACTIVE
AT HRE-1 = UNAVAILABLE
AT HRE-2 = UNAVAILABLE
SELF-TEST
01/01/99 00:11:09
_____
|
|
| CUST
|
|
01/01/99 00:11:33
61246026L6-5B
