Summary of Contents for Bass Habit Play PP55.4 G2
- Page 1 PP55.4 G2 PP65.4 G2 Play Power 4-channel Amplifier User Manual...
- Page 2 THANK YOU FOR PURCHASING BASS HABIT Thank you for purchasing this Play Power Class A/B amplifier from Bass Habit. Please read this manual in order to fully understand how to get the best result from this product and ensure that the advices on how to look after the product and the safety precautions are followed.
- Page 3 TABLE OF CONTENT • SAFETY & WARRANTY Caution Warranty What is not covered Warning International technical enquiries • INSTRUCTIONS Installation experience Choosing amplifier mounting locations Installation precautions Step 1) Power connections Step 2) Speaker connections Step 3) Signal connections • CONTROL PANEL Input level control (GAIN) Bass boost control (BASS BOOST) LPF crossover (LPF)
-
Page 4: Safety And Warranty
Please use common sense when listening to your audio system and practice safe sound. Keep the volume at a level so you can still hear outside noise. Failure to do this may result in an accident. Bass Habit recommends caution when listening at a high volume. -
Page 5: Installation Precautions
INSTRUCTIONS INSTALLATION EXPERIENCE Installation of Bass Habit amplifiers may require experience with a variety of mechanical procedures including cable wiring, drilling, etc. This manual only provides general installation and operation instructions. If you have any reservations about your installation skills, please contact your local authorized Bass Habit dealer for help. -
Page 6: Step 1) Power Connections
STEP 1) POWER CONNECTIONS The Bass Habit Play Power amplifiers are capable of delivering extremely high power levels and require a heavy- duty and reliable connection to the vehicle’s electrical system. To get the very best performance out of your Bass Habit Play Power amplifier, carefully follow the instructions below:... -
Page 7: Step 2) Speaker Connections
STEP 2) SPEAKER CONNECTIONS Speaker output connections should be made using a minimum of 16 awg / 1.25mm² wire. The terminal accepts up to 8 awg/10mm². Minimum total allowed impedance load is 2 Ohm stereo / 4 Ohm Bridge mode. 4-CHANNEL STEREO SPEAKER SYSTEM 2-8 Ohm 2-8 Ohm... -
Page 8: Step 3) Signal Connections
STEP 2) SPEAKER CONNECTIONS 2-CHANNEL MONO BRIDGE MODE min. 4 Ohm min. 4 Ohm STEP 3) SIGNAL CONNECTIONS Use high quality RCA jacks cable to make sure that you get the full audio experience. The Signal on FRONT OUTPUT is the same as FRONT INPUT. SIGNAL CABLE CONNECTIONS - 8 -... -
Page 9: Control Panel
CONTROL PANEL Bass Habit Play Power 4-channels amplifiers can be used for both speakers and subwoofers. While listening to music, adjust the gain/crossover/subsonic/bass boost for the least per- ceived distortion from the speakers, allowing them to reproduce as much bass as possible. -
Page 10: Bass Boost
FRONT PANEL PP55.4 G2 High Pass Filter 80-3000Hz (12dB/Oct) HPF/LFP/FULL Filter mode settings Low Pass Filter 50-250Hz (12db/Oct) BASS BOOST 12dB/6dB/0dB (45Hz) GAIN Gain control rear, input signal adjustment 0.2V-6V INPUT RCA Rear input OUTPUT RCA Front output INPUT RCA Front input GAIN Gain control front, input signal adjustment 0.2V-6V FULL/HPF... - Page 11 FRONT PANEL PP65.4 G2 High Pass Filter 50-3000Hz (12dB/Oct) HPF/LFP/FULL Filter mode settings Low Pass Filter 50-250Hz (12db/Oct) BASS BOOST 12dB/6dB/0dB (45Hz) GAIN Gain control rear, input signal adjustment 0.2V-6V INPUT RCA Rear input OUTPUT RCA Front output INPUT RCA Front input GAIN Gain control front, input signal adjustment 0.2V-6V FULL/HPF...
-
Page 12: Specifications
SPECIFICATIONS PP55.4 G2 PP65.4 G2 Class AB amplifier Class AB amplifier Component 4 channels 4 channels Number of channels 4x75W RMS * 4x110W RMS * Power output @ 2 ohm 4x55W RMS * 4x65W RMS * Power output @ 4 ohm 2x140W RMS * 2x180W RMS * Bridged power @ 4 ohm... -
Page 13: Troubleshooting
TROUBLESHOOTING Symptom Check / Control No sound • Check and measure voltage at +12V and REM terminals / No active POWER LED (allowed working range is 10-16V DC). • Check and measure ground connections. • Check external fuse. • Check input signal and cables from source unit. •... - Page 14 The crossed-out wheelie bin symbol means that the product, literature and packaging included must be taken to separate collection at the end of their working life. Do not dispose of these products as unsorted municipal waste: dispose of them at a recycling point. For info on your nearest recycling point, check with your local waste authority. Products marked with the RoHS symbol complies with the relevant provisions of the RoHS Directive for the European Union.
