Summary of Contents for Bass Habit Play PP600.1 G2
- Page 1 PP600.1 G2 PP1000.1 G2 Play Power Mono Amplifier User Manual...
- Page 2 THANK YOU FOR PURCHASING BASS HABIT Thank you for purchasing this Play Power Class D amplifier from Bass Habit. Please read this manual in order to fully understand how to get the best result from this product and ensure that the advices on how to look after the product and the safety precautions are followed.
- Page 3 TABLE OF CONTENT • SAFETY & WARRANTY Caution Warranty What is not covered Warning International technical enquiries • INSTRUCTIONS Installation experience Choosing amplifier mounting locations Installation precautions Step 1) Power connections Step 2) Speaker connections Step 3) Signal connections • CONTROL PANEL Input level control (GAIN) Bass boost control (BASS BOOST) LPF crossover (LPF)
-
Page 4: Safety And Warranty
Please use common sense when listening to your audio system and practice safe sound. Keep the volume at a level so you can still hear outside noise. Failure to do this may result in an accident. Bass Habit recommends caution when listening at a high volume. -
Page 5: Step 1) Power Connections
STEP 1) POWER CONNECTIONS The Bass Habit Play Power amplifiers are capable of delivering extremely high power levels and require a heavy- duty and reliable connection to the vehicle’s electrical system. To get the very best performance out of your Bass Habit Play Power amplifier, carefully follow the instructions below:... -
Page 6: Step 2) Subwoofer Connections
STEP 1) POWER CONNECTIONS POWER CONNECTIONS STEP 2) SUBWOOFER CONNECTIONS Subwoofer output connections should be made using a minimum of 16 awg / 1.25mm² wire. The terminal accepts up to 8 awg/10mm². Minimum total allowed impedance load is 1 Ohm mono. MONO CHANNEL SUBWOOFER SYSTEM (1 SUBWOOFER) min. -
Page 7: Step 3) Signal Connections
STEP 2) SUBWOOFER CONNECTIONS MONO CHANNEL SUBWOOFER SYSTEM (2 SUBWOOFER) min. 2 Ohm min. 2 Ohm STEP 3) SIGNAL CONNECTIONS Use high quality RCA jacks cable to make sure that you get the full audio experience. The Signal on BRIDGE OUT is the same as FRONT INPUT. SIGNAL CABLE CONNECTIONS - 7 -... -
Page 8: Control Panel
CONTROL PANEL Bass Habit Play Power mono amplifiers are constructed to be used for subwoofers. While listening to music, adjust the gain/crossover/subsonic/bass boost for the least perceived distortion from the subwoofers, allowing them to reproduce as much bass as possible. - Page 9 Bridge In/Output (BRIDGE IN/OUT) Two separeate Bass Habit Play Power mono amplifier G2 (same model) can be linked to power a minimum 2 Ohm subwoofer setup for increased power output. Follow these instructions carefully, if not carried out correctly you may permanently damage your products.
- Page 10 BRIDGE CONNECTION PP1000.1 G2 AMP 1 AMP 2 AMP 1 AMP 2 Total subwoofer setup min. 2 Ohm - 10 -...
- Page 11 SIDE PANEL PP600.1 G2 BRIDGE OUT RCA out BRIDGE IN RCA in INPUT RCA input GAIN Gain control, input signal adjustment 0.2V-6V BASS BOOST 0-18dB (45Hz) Low Pass Filter 32-300Hz (12dB/Oct) SUBSONIC 15-50Hz (12dB/Oct) PHASE Phase shift adjustable 0-180 deg REMOTE Remote control input POWER/PROTECT...
- Page 12 SIDE PANEL PP1000.1 G2 POWER INPUT SPEAKER OUTPUTS +12V PROTECT Protect indicator (Red) POWER Power indicator (Green) REMOTE Remote control input INPUT RCA input BRIDGE IN RCA in BRIDGE OUT RCA out GAIN Gain control, input signal adjustment 0.2V-6V Low Pass Filter 40-180Hz (12db/Oct) SUBSONIC Subsonic 15-50Hz (12db/Oct) BASS BOOST FREQ.
-
Page 13: Specifications
SPECIFICATIONS PP600.1 G2 PP1000.1 G2 Class D amplifier Class D amplifier Component 1 channel (mono) 1 channel (mono) Number of channels 1x600W RMS * 1x1000W RMS * Power output @ 1 ohm 1x380W RMS * 1x650W RMS * Power output @ 2 ohm 1x180W RMS * 1x380W RMS * Power output @ 4 ohm... -
Page 14: Troubleshooting
TROUBLESHOOTING Symptom Check / Control No sound • Check and measure voltage at +12V and REM terminals / No active POWER LED (allowed working range is 10-16V DC). • Check and measure ground connections. • Check external fuse. • Check input signal and cables from source unit. •... - Page 15 The crossed-out wheelie bin symbol means that the product, literature and packaging included must be taken to separate collection at the end of their working life. Do not dispose of these products as unsorted municipal waste: dispose of them at a recycling point. For info on your nearest recycling point, check with your local waste authority. Products marked with the RoHS symbol complies with the relevant provisions of the RoHS Directive for the European Union.
