Parameter loader for multi-loop module-type temperature controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
International Sales Div
Sales Group
Gate City Ohsaki, East Tower, 11-2, Osaki 1-chome,
Shinagawa-ku, Tokyo 141-0032, Japan
http://www.fujielectric.com
Phone: 81-3-5435-7280, 7281 Fax: 81-3-5435-7425
http://www.fujielectric.com/products/instruments/
Thank you very much for purchasing Fuji's multi-loop module-type temperature controller. Please read this instruction manual
carefully before using the instrument. Make sure that this instruction manual will be handed over to the final user of this
software (PUM parameter loader).
Note
The contents of this manual are subject to change without notice.
This manual is complied with possible care for the purpose of accuracy, however, Fuji Electric shall not be held liable for any
damages, including indirect damage, caused by typographical errors, absence of information or use of information in this
manual.
Contents
2 Outline ................................................................. 3
3 Operating environment ........................................ 3
4 Installing/uninstalling the software . ...................... 4
Installation . .................................................................... 4
Uninstallation ................................................................ 6
Connection with RS-232C ............................................ 7
6 Starting the PUM parameter loader . ...................11
7 Initial setting . ...................................................... 23
8 Parameter setting .............................................. 25
Setting parameters ..................................................... 29
Favorite ....................................................................... 31
Switching between display ON and OFF . ................... 35
Relevant parameters .................................................. 37
Online function . ........................................................... 39
INP-TN5A1634-E
Type
Parameter loader for multi-loop
module-type temperature controller
PUM
(For version 2.2.0 or later)
Instruction Manual
Module composition.................................................... 41
Checking the type code . ............................................. 43
Displaying trend .......................................................... 45
Copying parameters ................................................... 47
Copy and paste . .......................................................... 51
UnDo . .......................................................................... 52
Function of Station No. Change ................................. 53
Insert . .......................................................................... 57
Compare parameter to initial Data ............................. 58
Parameter list . ............................................................. 61
Opening files . .............................................................. 69
Saving the setting in a file . .......................................... 71
Exiting the PUM parameter loader ............................. 72
Multi launcher function................................................ 73
9 Troubleshooting ................................................. 74
INP-TN5A1634a-E
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PUM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel
