Table Of Contents - SPX APV DELTA SV1B Operating Manual

DEL TA SV1B / SVS1FB-UK0.qxp / 09.2007
T able of Contents :
1. General T erms
2. Safety Instructions
3. Mode of Operation
4. Positioner TC 8630
5. Installation
5.1 Welding Instructions
6. Dimensions / Weights
7 . T echnical Data
8. Materials
9. Maintenance
10. Service Instructions SV1B
10.1 Disassembly from the line system
10.1.1 Disassembly of the valve SV1B
10.1.2 Replacement of seals
10.1.3 Installation of the inner parts
10.1.4 Assembly of the valve
11. Service Instructions SVS1FB
11.1 Disassembly from the line system
11.1.1 Disassembly of the valve SVS1FB
11.1.2 Replacement of seals
11.1.3 Installation of the inner parts
11.1.4 Assembly of the valve
12. Spare parts lists
(see appendix)
SV1B - NC - NO DN 25 - 100
SV1B - NC - NO 1" - 4" Inch
SVS1FB - NC - NO DN 25 - 100
SVS1FB - NC - NO 1" - 4" Inch
Actuator S/A for feedback unit
Modulating-Butterfly Valve with T op Control TC 8630
DEL TA SV1B and SVS1FB
Operating manual : rev . 0
Page:
2
2
3
4
4 - 5
6
7
7
8
9 - 10
11 - 12
13
- RN 01.037 .553
- RN 01.037 .553-1
- RN 01.037 .554
- RN 01.037554-1
- RN 01.076
UK
1
