Page 1 PageWorks 18N User’s Manual...
Page 2 TAR printers have a feature that allows them to automatically “go to sleep” after a period of inactivity. This auto-feature can reduce a machine’s annual electricity cost by 60 percent. As an NERGY TAR Partner, we have determined that this machine meets the for energy efficiency. NERGY TAR Printer ? NERGY TAR Guidelines...
Page 3: Safety Information
Foreword Safety Information Laser Safety This is a page printer which operates by means of a laser. There is no possibility of danger from the laser, provided the printer is operated according to the instructions in this manual. Since radiation emitted by the laser is completely confined within pro- tective housing, the laser beam cannot escape from the machine during any phase of user operation.
Page 4: Warning Label
Foreword WARNING: Use of controls, adjustments or performance of procedures other than those specified in this manual may result in hazardous radia- tion exposure. This is a semiconductor laser. The maximum power of the laser diode is 5mW and the wavelength is 770-810 nm. WARNING LABEL...
Page 5 USER INSTRUCTIONS (For U.S.A. Users) FCC PART 15 - RADIO FREQUENCY DEVICES WARNING FCC: Declaration of Conformity Product Type Laser Beam Printer Product Name PageWorks 18N Options Third Paper Cassette Unit (4166) Accessories Duplex Unit (4168) DRAM SIMM (Maximum 64MB) Adobe PostScript SIMM (4179-291) This device complies with Part 15 of the FCC Rules.
Page 6 Foreword This device must be used with a shielded interface cable and shielded network (10/100BaseT) cable. The use of non-shield cables is likely to result in interference with radio communications and is prohibited under FCC rules. The design and production of this unit conform to FCC regulations, and any changes or modifications must be registered with the FCC and are subject to FCC control.
Page 7 Foreword OZONE RELEASE (For All Users) During printer operation, a small quantity of ozone is released. This amount is not large enough to harm anyone adversely. However, be sure the room where the machine is being used has adequate ventila- tion, especially if you are printing a high volume of materials, or if the machine is being used continuously over a long period.
Page 8: Trademark Acknowledgments
Welcome And thank you for selecting a Minolta PageWorks 18N Printer! This User’s Manual explains the functions of the printer and how it operates. It also provides you with troubleshooting tips as well as gen- eral precautions you should observe when operating the printer. To...
Page 9: Technical Support
Technical Support Technical support for all Minolta PageWorks printer products is avail- able 24 hours a day, seven days a week by calling (from within North America). Minolta also maintains a Web site which provides printer driver downloads, Frequently Asked Questions and handles all e-mail requests for technical assistance at: http://www.minoltaprinters.com...
Page 10: Table Of Contents
Indicator Lights...1-4 Control Panel Button ...1-8 Job Cancel...1-8 Print Configuration ...1-8 Form Feed ...1-8 Chapter 2: Setting-up Installation Precautions ...2-1 Selecting a Location for the Printer ...2-1 Power Source...2-2 Grounding ...2-2 Space Requirements...2-3 Operational Precautions ...2-4 Operating Environment ...2-4 Printer ...2-4 Printer Supplies...2-6...
Page 11 Installing Tray 1 ...2-8 Second Paper Cassette Unit ...2-9 Installing the Second Paper Cassette Unit ...2-9 Connecting the Power Cord ...2-11 Loading Paper...2-12 Turning On the Printer...2-14 Testing the Printer ...2-15 Connecting to a Computer ...2-17 Network Interface Card (NIC)...2-18 Options ...2-19 SIMM (Single In-line Memory Module)...2-19...
Page 12 Printing on Envelopes ...3-13 Duplex Printing...3-15 Paper Type...3-16 Paper Size ...3-16 Chapter 4: Printer Driver Introduction...4-1 System Requirements...4-1 Installing the Printer Driver Under Windows 95/98...4-2 To Install the Printer Driver Using the Installer (Auto Run) ...4-2 To Uninstall the Printer Driver ...4-6...
Page 13 Installing the Printer Driver Under Windows NT 4.0 ...4-8 To Install the Printer Driver Using the Installer (Auto Run) ...4-8 To Uninstall the Printer Driver ...4-14 Installing the Printer Driver Under Windows 3.1 ...4-16 To Install the Printer Driver...4-16 To Uninstall the Printer Driver ...4-19 Displaying the Driver Setup Dialog (Windows 95/98/NT 4.0)...4-21...
Page 14 Contents Using the Printer Driver Under Windows 3.1 ...4-43 Common Buttons ...4-43 Settings ...4-44 DOS Printing Utilities ...4-49 Installing the Printer Driver Under DOS ...4-49 Loading and Unloading the Status Display ...4-51 To Load the Status Display From the DOS Prompt...4-51 To Remove the Status Display From Memory ..4-51...
Page 15 Change Popup Message Command (Setup Menu) ...4-64 Close (button) ...4-65 Help (button) ...4-65 Chapter 5: Printer Status Display and Control Panel Using the Printer Status Display...5-1 Opening the Printer Status Display ...5-1 To Open the Printer Status Display...5-1 To Close the Printer Status Display ...5-2 Using the Printer Status Display ...5-2...
Page 16 Chapter 6: Maintenance Replacing the Imaging Cartridge ...6-1 To Replace the Imaging Cartridge ...6-2 Cleaning the Printer ...6-6 Cleaning the Outside of the Printer ...6-6 Cleaning the Paper Transport Roller ...6-7 Chapter 7: Troubleshooting Technical Support ...7-1 Clearing a Paper Misfeed ...7-2 Inside the Printer ...7-2...
Page 17 Irregularities ...7-12 White or black line ...7-13 Toner smudges...7-13 No output...7-14 Are you using the correct type of printer cable? ...7-14 Are your computer’s communications port settings correct? ...7-14 Chapter 8: Specifications PageWorks 18N Printer ...8-1 Second Paper Cassette Unit...8-4 Third Paper Cassette Unit (Option)...8-5...
Page 18 Contents Interface Connector and Cable ...8-7 SIMM (Option) ...8-8 Appendix A: Glossary Appendix B: Index...
Page 19: Chapter 1: Introduction
Chapter Introduction...
Page 21: Features
Features The Minolta PageWorks 18N is a laser printer developed exclusively for use with Windows 95, Windows 98, Windows NT 4.0, Windows 3.1 and DOS operating systems. The various features listed below make the Minolta PageWorks 18N the perfect printer for any size office.
Page 22: Printer Parts And Accessories
Printer Parts and Accessories Printer Parts and Accessories Second paper Third paper cassette unit cassette unit (option) Power switch Top cover release button Control panel Face-down tray Manual feed tray Paper size guide Tray cover Cassette cover Tray 2 (500-sheet...
Page 23 Network Interface Card (NIC) Ethernet interface connector (10/100BaseT) Top cover Image transfer roller Printer Parts and Accessories Power cord socket Parallel interface connector Fusing unit Imaging cartridge...
Page 24: Control Panel
Indicator Lights The three indicator lights turn on, off, or blink in combination to let you know the current status of the printer. You can find out details of the printer’s status by checking the information that appears on your computer screen through the Status Monitor.
Page 25 Installation of additional memory will help to prevent data from being compressed. Memory overflow/data received cannot be processed because it is too complex. Install an optional expansion memory SIMM into the printer or decrease the amount of data being sent to the printer. Control Panel...
Page 26 Load the appropriate size of paper onto the specified tray. Press the button to resume printing. The printer is waiting for paper to be loaded. Load the appropriate size of paper onto one of the trays. The printer is waiting for paper to be loaded manually.
Page 27 Controller-memory error. Turn off the printer and contact Minolta Technical Support. Engine error (jogging function). Turn the printer off and on again. If the problem persists, contact Minolta Technical Support. Engine error (fusing unit). Turn off the printer and contact Minolta Technical Support immediately.
Page 28: Control Panel Button
Control Panel Control Panel Button Depending on the status of the printer, the control panel button performs any one of the following operations. • Job cancel • Print configuration page • Form feed Job Cancel Use the following procedure whenever you want to cancel the current job.
Page 29: Chapter 2: Setting-Up
Chapter Setting-up...
Page 31: Installation Precautions
Selecting a Location for the Printer A proper location helps to ensure that your printer provides you with the long service life for which it is designed. Double-check to make sure that the location you select has the following characteristics.
Page 32: Power Source
• Be sure to plug the power cord all the way into the outlet. The outlet should be located near the printer and be easily accessible so you can unplug the power cord immediately if necessary. • Make sure the outlet you use is visible, and not hidden behind the printer or any other object.
Page 33: Space Requirements
Space Requirements Be sure to provide space around the printer as indicated below, to ensure easier printer operation, paper and toner replacement, and maintenance. 11-3/4 or more 29-1/2 (746 mm) " or more * 34-1/4 (867 mm) " or more 6"...
Page 34: Operational Precautions
• Humidity: 15% to 85% with fluctuation of 20% per hour Printer The following describes precautions for using the printer. • Never turn the printer off or open any of its covers during a print operation. • Never place flammable gasses, liquids or objects that generate magnetic forces near the printer.
Page 35 Such objects create the danger of fire or electrical shock. • Do not allow water or other liquids to spill on or near the printer. Fire or electrical shock can occur should water or liquid come into contact with the printer.
Page 36: Printer Supplies
Areas subjected to large amounts of dust. • Keep paper that has been removed from its wrapper, but not yet loaded onto the printer tray, in a sealed plastic bag and store it in a cool, dark location. • Only use imaging cartridges that are expressly specified for this printer.
Page 37: Setting-Up
• Always use a shielded interface cable. Use of an unshielded cable can result in radio interference with data. • Keep all the boxes and packing materials that the printer comes in for later use when transporting the printer. Installing the Face-Down Tray With both hands, gently bend the face-down tray inwards and insert one of its tabs into its holder on the upper portion of the printer.
Page 38: Installing Tray 1
Setting-up Installing Tray 1 Using the left and right slots in the printer as guides, gently push Tray 1 until it cannot be inserted any further (as shown in the illustration). Attach the tray cover onto Tray 1.
Page 39: Second Paper Cassette Unit
Place the printer on top of the base unit. Make sure to align the coupling pins of the base unit with the holes located underneath the printer.
Page 40 Setting-up Insert Tray 2 into the second paper cassette unit. Note • Be sure to use both hands whenever Tray 2 is being removed from or inserted into the second paper cassette unit. 2-10...
Page 41: Connecting The Power Cord
Connecting the Power Cord Make sure that the printer’s power switch is in the tion. Connect one end of the power cord that comes with the printer to the power cord socket. Plug the other end into a power outlet. Setting-up...
Page 42: Loading Paper
Setting-up Loading Paper Remove the tray cover from Tray 1. Open all three paper size guides. 2-12...
Page 43 Place the paper stack onto the tray, print-side up. Secure the stack by adjusting the paper size guides. Note • A maximum level mark on the paper size guide shows how high you can stack paper on Tray 1. Make sure that paper is stacked no higher than this mark.
Page 44: Turning On The Printer
After connecting the printer to a power outlet, press the power switch to turn it on. Turning on the printer causes all the indicators on the control panel to light, which indicates that the printer is warming up. In about 23 seconds only the READY indicator remains lit, indicating that the printer is ready to print.
Page 45: Testing The Printer
Testing the Printer Before connecting to a computer, perform the following procedure to print a Configuration Page and see if the printer is working correctly. Place the paper onto Tray 1. Make sure that both the PAPER and ERROR indicators are off, and the READY indicator is on.
Page 46 Setting-up Sample Configuration Page Note • See Chapter 7 of this manual for information on what to do if the Con- figuration Page does not print when you press the panel button. • The Configuration Page can be printed on Letter size paper only. 2-16...
Page 47: Connecting To A Computer
Connect the other end of the cable to the parallel connector on the back of the printer. Secure the cable using the two clips on the parallel connector. See page 8-7 of this User’s Manual for cable specifications and pin assignments.
Page 48: Network Interface Card (Nic)
Setting-up Network Interface Card (NIC) This printer is equipped with a network interface card. 10/100BaseT For details, please see the Network Interface Card User’s Manual. 2-18...
Page 49: Options
Configuration Page. Installing the Optional SIMM Warning • Electric shock hazard! Do not remove any cover of the printer that is not directly specified for removal in the User’s Manual. Turn off the printer and unplug the power cord. Disconnect the parallel cable from the printer.
Page 50 Clips secure the exterior side cover from the inside of the printer. Gently maneuver the exterior side cover until the clips release (see illustration). Caution • Do not touch any part of the main circuit inside of the printer. 2-20...
Page 51 With the exterior side cover removed, the internal side cover of the printer is exposed. With the screwdriver, loosen and remove the four screws that secure the internal side cover. Remove the internal side cover to expose the main circuit.
Page 52 Options Being careful not to touch the connection points along the edge of the SIMM, insert the SIMM into one of the available sockets on the main circuit. • Insert the SIMM at an angle as shown and gently swing it into the socket.
Page 53 • To release the SIMM from the socket, push out on the taps on each side of the socket. • After installation of the SIMM, reset the Printer Memory Setting to reflect the new memory capacity (see page 4-60). Options...
Page 54: Duplex Unit
Your printer supports double-sided printing if the optional duplex unit is installed. Double-sided documents can be generated for binding along either the short or long edges of the paper through the printer software. For more information, refer to page 3-15.
Page 55 Options Align the “L” shaped duplex unit to the back of the main unit of the printer so that the bottom of the “L” is inside of the opening at the bottom of the printer. Note • Make sure that the connector of the unit is inserted into the printer securely.
Page 56 • Hold up the duplex unit with your hand during installation until it is secured to the printer with the screws. Connect the power cord to the printer and then turn the printer on. See “Connecting the Power Cord”, page 2-11.
Page 57: Third Paper Cassette Unit
• Take the paper cassette unit out of the shipping box. • Remove the plastic bag and all shipping materials. • Turn the printer off and then disconnect the power cord and inter- face cable from the printer. Place the paper cassette unit in the location you have chosen (see page 2-1 “Selecting a Location for the Printer”).
Page 58 Options Set the printer onto the third paper cassette unit using the cou- pling pins as a guide. Note • The printer weighs approximately 18 kg (39.7 lbs.). Two people are recommended to lift it when necessary. Insert Tray 3 into the third paper cassette unit.
Page 59 • Be sure to use both hands whenever Tray 3 is being removed from or inserted into the third paper cassette unit. Connect the power cord to the printer and then turn the printer on. See “Connecting the Power Cord”, page 2-11.
Page 60: Adobe Postscript Rom-Simm
Installing the Optional Adobe PostScript ROM-SIMM Warning • Electric shock hazard! Do not remove any cover of the printer that is not directly specified for removal in the User’s Manual. Turn off the printer and unplug the power cord.
Page 61 Gently maneuver the exterior side cover until the clips release (see illustration). Caution • Do not touch any part of the main circuit inside of the printer. With the exterior side cover removed, the internal side cover of the printer is exposed. With the screwdriver, loosen and remove the four screws that secure the internal side cover.
Page 62 Options Remove the internal side cover to expose the main circuit. Being careful not to touch the connection points along the edge of the SIMM, insert the SIMM into the socket of the main circuit. • Insert the SIMM at an angle as shown and gently swing it into the socket.
Page 63 Replace the external side cover using the two screws. Connect the power cord to the printer and then turn the printer on. See “Connecting the Power Cord”, page 2-11. See “Turning On the Printer”, page 2-14. Generate a configuration page to verify that PostScript is listed under the Printer Configuration item.
Page 64 Options PRINTER CONFIGURATION Tray 2 = Installed Tray 3 = Not Installed Duplex Unit = Not Installed PostScript = Installed Network Card = Installed 2-34...
Page 65: Chapter 3: Using The Printer
Chapter Using the Printer...
Page 67: Paper
Paper Caution • This printer is designed to print on only the following types of paper. Type Paper Plain Paper Feeding weighing: Recycled Port 60 to 90 g/m Paper 16 to 24 lbs. weighing: 60 to 90 g/m 16 to 24 lbs.
Page 68: Envelopes And Custom Sizes (Tray 1 And Manual Feed Tray)
• Do not use the following types of paper to avoid reduced print quality, a misfeed or a print failure. Paper already used in a thermal transfer printer or ink jet printer. Paper that is too thin or too thick.
Page 69: Loading Paper
Loading Paper Loading Paper There are three sources that can be used to feed paper into the printer: Tray 1, the manual feed tray, and Tray 2. Tray 1 is the standard source for supplying paper to the printer. Various types and sizes of paper can be fed from this tray.
Page 70: Loading Paper Onto Tray 1
Loading Paper Loading Paper onto Tray 1 You can load up to 250 sheets of standard paper onto Tray 1. See page 3-1 for details on paper sizes and types. Remove the tray cover from Tray 1. Open the paper size guides.
Page 71 Place a stack of paper in the center of Tray 1. Adjust the paper size guides so that both the left and the right sides of the paper stack are secure. Note • A maximum level mark on the paper size guide shows how high you can stack paper on Tray 1.
Page 72 Loading Paper Replace the tray cover onto Tray 1.
Page 73: Loading Paper Onto Tray 2/Tray 3
Then gently raise the for- ward-end up, and remove Tray 2/Tray 3 from the unit. • Tray 3 is available as an option for this printer. Contact Minolta Tech- nical Support to find out how you can acquire this tray to increase the capabilities of your printer.
Page 74 Loading Paper Remove the cassette cover from Tray 2/Tray 3. Press down on the paper lifting plate located inside of Tray 2/ Tray 3 until it locks.
Page 75 Place a stack of up to 500 sheets of paper into Tray 2/Tray 3 so that the side that was facing up when the paper was unwrapped is still facing up. Note • A maximum level mark inside the inlet of Tray 2/Tray 3 shows how high you can stack paper.
Page 76 Loading Paper Replace the cassette cover and insert Tray 2/Tray 3 into the second/third paper cassette unit. Tray 2 Tray 3 3-10...
Page 77: Manual Paper Feed
Manual Paper Feed Make sure that the tray cover is properly attached to Tray 1. Open the paper size guides. Insert the sheet of paper into the manual feed tray with the side to be printed facing up. Loading Paper 3-11...
Page 78 Loading Paper Adjust the paper size guides so that both sides of the paper are secure. Note • Insert only one sheet of paper or one envelope at a time when feeding manually. 3-12...
Page 79: Printing On Envelopes
• Because there is great variation in the quality of paper used for enve- lopes, we suggest that you produce test prints of various types before purchasing any envelope in large quantities for use with this printer. Note the following points whenever printing on envelopes.
Page 80 • Do not use envelopes that are wrinkled. • Never use envelopes that have clasps or any other type of fastener that can damage the printer. • Do not store envelopes in an area that is subject to high humidity.
Page 81: Duplex Printing
Loading Paper Duplex Printing This feature prints document data on both sides of a sheet of paper. Installation of the optional duplex unit is required to perform duplex printing. You can choose either Bind Long Edge or Bind Short Edge when generating duplex documents.
Page 82: Paper Type
Paper Size A4, A5, JIS B5, Letter, Legal, Executive. Note • The Long Edge Binding setting of the printer driver cannot be used to print duplex documents on custom size paper. Remember the following points when generating duplex documents: • The size of both original documents that will be used to make one duplex document must be the same.
Page 83: Chapter 4: Printer Driver
Chapter Printer Driver...
Page 85: Introduction
Important! • This printer driver is located on the CD-ROM that comes with your printer. If your computer does not have a CD-ROM drive or you wish to download the updated printer driver, it can be downloaded from the Minolta Web site at http://www.minoltaprinters.com...
Page 86: Installing The Printer Driver Under Windows 95/98
Installing the Printer Driver Under Windows 95/98 This section provides information on installing the printer driver under Windows 95/98. It also tells you how to uninstall the printer driver when necessary. We recommend that the printer driver be installed using the CD-ROM’s installer.
Page 87 CD-ROM. Install.exe • The printer driver must be installed using the CD-ROM’s installer. Do not use the Add Printer wizard from the Printers folder. Installation through the Add Printer wizard will prevent the printer from perform- ing properly.
Page 88 Installing the Printer Driver Under Windows 95/98 When the following dialog appears, check the option(s) that are installed onto your printer. If you want to install the status dis- play, check the “Install Status Display” box. Then click display the next step.
Page 89 The following dialog appears on the desktop of the computer. Make sure that the Minolta PageWorks/Pro 18 displayed in the Printers dialog. Click and then click Printers This completes the installation of the printer driver. printer icon is , point to Start to display the Printers dialog. Settings...
Page 90: To Uninstall The Printer Driver
, and then click ties Click to proceed with the uninstall operation or Note • This uninstall operation will delete all of the printer driver(s) that are currently installed in the Minolta Printer Utilities group. Programs Minolta Printer Utili- Uninstall.
Page 91 Installing the Printer Driver Under Windows 95/98 Click to delete the directory that contains the Minolta Printer Utilities program. In the next dialog that appears, click to restart the computer.
Page 92: Installing The Printer Driver Under
If the screen does not appear, double- click Install.exe from the CD-ROM. • The printer driver must be installed using the CD-ROM’s installer. Do not use the Add Printer wizard from the Printers folder. CD-ROM into your computer’s CD- is the name of the CD-...
Page 93 Installing the Printer Driver Under Windows NT 4.0 Follow the instructions that appear on your computer screen to complete the installation. Select Local Printer Click the button to display the next dialog. Select the installation options.
Page 94 • If your printer is connected to a Network, we recommend consulting your network administrator and referring to the Network Interface Card Manual. If you plan to use the printer as a network printer, type in a name Share Name Example: PW_18 Note •...
Page 95 When the name is as you want it, click When the following dialog appears, check the option(s) that are installed onto your printer. If you want to install the status dis- play, check the “Install Status Display” box. Then click display the next step.
Page 96 Installing the Printer Driver Under Windows NT 4.0 After the installation is completed, the following dialog appears. Printing a test page is recommended to confirm that the printer driver is correctly installed on your computer. The following dialog appears on the desktop of the computer.
Page 97 Additional Options designated as a “Network Printer” tion procedure. • The printer driver must be installed using the CD-ROM’s installer. Do not use the Add Printer wizard from the Printers folder. Start , point to to display the Printers dialog.
Page 98: To Uninstall The Printer Driver
, and then click ties Click to proceed with the uninstall operation or Note • This uninstall operation will delete all of the printer driver(s) that are currently installed in the Minolta Printer Utilities group. 4-14 Programs Minolta Printer Utili- Uninstall to abort.
Page 99 Installing the Printer Driver Under Windows NT 4.0 Click to delete the directory that contains the Minolta Printer Utilities program. In the next dialog that appears, click to restart the computer. 4-15...
Page 100: Installing The Printer Driver Under Windows 3.1
Installing the Printer Driver Under Windows 3.1 Installing the Printer Driver Under Windows 3.1 This section provides information on installing the computer running Windows 3.1. It also tells you how to uninstall the printer driver when necessary. To Install the Printer Driver Turn on your computer and start up Windows 3.1.
Page 101 Printers dialog box. Note • An error message may appear during installation of the printer driver informing you that a required UNIDRV.DLL file cannot be found. Should this occur, install a UniTool Driver such as HP LaserJet from...
Page 102 Installing the Printer Driver Under Windows 3.1 Click to finish the installation procedure. Close 4-18...
Page 103: To Uninstall The Printer Driver
MINOLTA PageWorks/Pro 18 menu and click Remove confirm your selection. Click to remove the printer driver. The Printers dialog box reappears after the printer driver is removed. Main to display the Con- Control Panel to display the Printers dialog box.
Page 104 Installing the Printer Driver Under Windows 3.1 Click to close the Printers dialog box. Close 4-20...
Page 105: Displaying The Driver Setup Dialog (Windows 95/98/Nt 4.0)
Displaying the Driver Setup Dialog (Windows 95/98/NT 4.0) Displaying the Driver Setup Dialog (Windows 95/98/NT 4.0) Use the following procedure to display the driver setup dialog under Windows 95, Windows 98 or Windows NT 4.0. To Display the Driver Setup Dialog Under Windows 95/98 Click , point to...
Page 106 Displaying the Driver Setup Dialog (Windows 95/98/NT 4.0) On the 32-bit SuperDriver Setup the following window appears. See “Using the Printer Driver Under Windows 95/98/NT 4.0” on page 4-25 to enter driver settings. 4-22 tab of the Properties dialog,...
Page 107: To Display The Driver Setup Dialog Under Windows Nt 4.0
Displaying the Driver Setup Dialog (Windows 95/98/NT 4.0) To Display the Driver Setup Dialog Under Windows NT 4.0 Click Start , point to the Printers dialog. In the Printers dialog, click the In the Printers dialog, select menu Settings , and then click Printers Minolta PageWorks/Pro 18 Document Defaults…...
Page 108 Displaying the Driver Setup Dialog (Windows 95/98/NT 4.0) The following window appears. See “Using the Printer Driver Under Windows 95/98/NT 4.0” on page 4-25 to enter driver set- tings. 4-24...
Page 109: Using The Printer Driver Under
Using the Printer Driver Under Windows 95/98/NT 4.0 Using the Printer Driver Under Windows 95/98/NT 4.0 The features of the printer driver allow you to control a wide variety of printer parameters from your computer. The following sections provide an overview of the printer driver’s properties.
Page 110 Paper your printed documents. Paper Size The various sizes of paper that are supported by your printer are displayed in the drop-down list. Select the appropriate size or add a custom size (see Edit Custom…). Paper...
Page 111: Edit Custom
Using the Printer Driver Under Windows 95/98/NT 4.0 Envelopes COM10 4 1/8 9 1/2 inches Monarch 3 7/8 7 1/2 inches Edit Custom… Click this button to open a dialog that allows you to modify your printer to support custom paper sizes.
Page 112: Fit To Paper
Auto Continue When Auto Continue is on, the printer automatically resumes printing after most errors. When it is off, the printer waits for you to press the printer button on the front of the printer before it resumes printing. Orientation This setting allows you to determine how your document is positioned on the printed page (see Portrait and Landscape).
Page 113: Paper Source
Paper Source from the printer. To change this setting, just select the desired paper source from the drop-down list. If the desired tray is an option and does not appear as a paper source, make sure that it has been added in the tab.
Page 114 The default setting for this feature is appears in the Jogging Paper installed option during the installation procedure of the printer driver. Default Click the button to reset the functions of the tab to their Default original values.
Page 115: Paper
Using the Printer Driver Under Windows 95/98/NT 4.0 Page Layout tab contains a realtime graphic mirror of most driver Page Layout settings as well as the following features. N-up The N-up settings allow you to print multiple documents on a single page.
Page 116 Watermark have been entered into the printer’s memory. You can add and delete watermarks from this list through the Watermark pop-up dialog. 4-32 button to open a dialog that will allow features of the printer driver cannot be documents.
Page 117 Using the Printer Driver Under Windows 95/98/NT 4.0 Watermarks can be specified to appear on the first page only of a multi- page document by clicking the watermark that is specified to appear will be placed on every page of the multi-page document.
Page 118 Using the Printer Driver Under Windows 95/98/NT 4.0 String The contents of the watermark that you wish to create are entered here. Shading The density of the watermark that will appear on the document is specified here. Style These settings can be used to specify the style of the watermark’s font.
Page 119 Using the Printer Driver Under Windows 95/98/NT 4.0 Scaling Note • The feature of the printer driver cannot be used when printing Scaling documents. N-up You can adjust the area of a document through the feature. The Scaling maximum percentage of enlargement is 200. The maximum percentage of reduction is 50.
Page 120: Quality
Set to , all print Graphics Mode TrueType Mode data is “rasterized” before being sent to the printer. Toner Save This option helps to reduce your printing costs by conserving toner when printing rough drafts or sample documents. Normal amounts of toner are consumed during printing.
Page 121: Graphics Mode
Vector setting should be ideal for most printing applications. Enabling rasters sends graphic images to the printer as bitmaps. Longer printing time may be noticed when difference in the image that appears in the monitor and the image that is...
Page 122: Emulation Mode
Using the Printer Driver Under Windows 95/98/NT 4.0 Emulation Mode Enhanced This mode provides PCL6 compatibility. Standard This mode provides PCL5 compatibility. Note • All Raster Graphics Mode is set to Emulation Mode Default Click the button to reset the functions of the tab to their Default original values.
Page 123 Using the Printer Driver Under Windows 95/98/NT 4.0 Detail of Quality... Click this button to open the Graphics (pop-up dialog) dialog contains two advanced settings, Graphics Adjustment Dither Pattern Dithering can be used to improve the texture of graphics. Changing the dither pattern will affect the gray tones and shadowing of an image.
Page 124: Device Option
To remove an option from the Installed Options list, select the option and click the button. Remove Removed options can be reinstalled using the previous procedure. About This tab displays version and copyright information about this printer driver. 4-40...
Page 125: Displaying The Driver Setup Dialog (Windows 3.1)
In the Control Panel dialog, double-click Printers dialog box. In the Installed Printers item to select it. Pro 18 Click , which displays the Setup dialog for the printer Setup... you selected. icon which is located in the Printers list, click the MINOLTA PageWorks/...
Page 126 Displaying the Driver Setup Dialog (Windows 3.1) Use the procedure under “Using the Printer Driver Under Win- dows 3.1” on page 4-43 to enter PageWorks/Pro 18 driver settings. 4-42...
Page 127: Using The Printer Driver Under Windows 3.1
Using the Printer Driver Under Windows 3.1 Using the Printer Driver Under Windows 3.1 The Minolta PageWorks/Pro 18 printer driver lets you control a number of printer parameters from your computer. The following describes how to use the PageWorks/Pro 18 driver under Windows 3.1 and provides brief explanations on the settings you can make.
Page 128: Settings
Using the Printer Driver Under Windows 3.1 Settings Resolution This item displays the resolution setting of the printer driver as measured in dots per inch (DPI). Paper Size This item allows you to specify the sizes of paper and envelopes that you are using.
Page 129 Monarch 3 7/8 7 1/2 inches Paper Source This item specifies the tray from which paper is fed from the printer. To change this setting, just select the desired paper source from the drop- down list. By setting the paper source to automatically select the paper source according to the paper size to be printed in the priority order of Tray 1, Tray 2, Tray 3.
Page 130 Using the Printer Driver Under Windows 3.1 Orientation This setting allows you to determine how your document is positioned on the printed page (see Portrait and Landscape). Portrait Portrait documents are printed lengthwise (vertically), relative to the page. Landscape Landscape documents are printed widthwise (horizontally), relative to the page.
Page 131 Using the Printer Driver Under Windows 3.1 Options... Click this button to display the dialog shown below. Dithering Dithering can be used to improve the texture of graphics. Changing the dither settings will affect the gray tones and shadowing of an image.
Page 132 Duplex Printing Duplex printing allows you to generate documents utilizing both the front and back sides of a sheet of paper. It is necessary to install the optional Duplex Unit onto the printer in order to perform duplex printing. None Duplex printing is not enabled.
Page 133: Dos Printing Utilities
Installing the Printer Driver Under DOS Use the following procedure to install the DOS Printing Utilities. Connect your printer to the parallel port of your computer. Turn on your computer and start up DOS. Turn on your printer and make sure it is online.
Page 134 DOS Printing Utilities The installer will automatically execute and the following mes- sage will be displayed: Setup will install DOS Utility in the following directory. C:\PP18 1. To install to this directory. 2. To install to a different directory. 3. Exit Setup. Enter a choice : 1 Select item under...
Page 135: Loading And Unloading The Status Display
To Load the Status Display From the DOS Prompt Type the following at the DOS prompt to display the Status Display screen: Change to the directory you created under “Installing the Printer Driver Under DOS” on page 4-49. Type: cd c:\PP18 •...
Page 136: Accessing The Printer Control Panel
Type the following command at the DOS prompt. Type: dospanel After the Printer Control Panel finishes reading the printer profile, the Page Setup window appears. See page 4-53 for details on getting around in the Printer Control Panel windows. To Exit the Printer Control Panel Select...
Page 137: Using The Printer Control Panel
Panel and make the settings you want. • Use the key to move the selection cursor to the control buttons on the left side of the Printer Control Panel Screen. Once the selec- tion cursor is in place, use the < press the desired button.
Page 138: To Print A Test Page Or Demo Page
Device Option from the Options Menu to register or update the options that have been installed on your printer. Installed options must be registered in order for them to become available at the host computer. Printer Control Panel Screens This section describes the settings that are available in the Printer Control Panel Screens.
Page 139: Paper Screen
Priority Feed Use this setting to specify Tray 1, Tray 2 or Tray 3 as the priority tray. The priority tray is the one that the printer feeds from when the paper source setting is or if the same size paper is loaded in all Automatic trays.
Page 140 Paper Time Out During manual feeding of paper, the printer pauses during printing to wait for you to feed the next sheet. The “paper time out” condition exists when the printer is paused and nothing happens for about 10 minutes. Setting Proceed Paper is automatically fed from another paper tray.
Page 141: Font Selection Screen
DOS Printing Utilities Font Selection Screen Typeface Select the typeface you want to use from this list. Pitch/Point Specify the type size you want to use, either by scrolling the value in the upper box or by selecting a value from the lower box. The values indicate points for proportional fonts and inches for fixed pitch fonts.
Page 142: Output Quality Screen
Some graphics that include gray shading or a screen pattern are improved by turning Fine ART off. Print Language The printer language defines how the computer communicates with the printer. If you select Automatic automatically.
Page 143: Counter Screen
Counter Screen Total Counter This value shows how many pages have been printed throughout the life of the printer. This value cannot be reset. Tray 2 Counter This value shows how many pages have been printed from Tray 2. This...
Page 144: Configuration Screen
Configuration Screen Printer Name This box shows the name assigned to the connected printer. Total Memory This box shows how much memory is installed on the printer. Additional Accessories This box shows any additional accessories installed on the printer. 4-60...
Page 145: Printer Setting Screen
Power Save Specify for the Power save setting. Turning power save on causes the printer to enter a “sleep” mode whenever it is idle for the period of time specified by the power save interval. Power Save Interval Specify the amount of time in minutes that the printer should wait before entering its “sleep”...
Page 146: Auto Continue
The fuser will not warm up immediately after receiving a print job when is selected. I/O Timeout Select when the printer is connected directly to the computer Parallel using a parallel cable. If the printer is being operated in a network environment, select Network 4-62...
Page 147: Using The Status Display
DOS Printing Utilities Using the Status Display This section describes how to display the Status Display and make changes in the operating environment of the Status Display. To Display the Status Display After the Status Display is loaded, perform the required hot key combination (a combination of keys you press at the same time to perform an operation) to display the Status Display.
Page 148: Status Display Screen
DOS Printing Utilities Status Display Screen The following describes each of the buttons and the commands on the Status Display menu. Setup Set Display Mode Command (Setup Menu) In the dialog that appears when you execute this command, click the checkbox next to the Enable Popup on (checked) and off (unchecked).
Page 149: Close (Button)
DOS Printing Utilities Close (button) Select this button to close the Status Display screen. The Status Display remains in memory when you return to the DOS prompt. It can be removed by typing the following: status /d Help (button) Select this button to display online help about the Status Display. 4-65...
Page 150 MEMO...
Page 151: Chapter 5: Printer Status Display And Control Panel
Chapter Printer Status Display and Control Panel...
Page 153: Using The Printer Status Display
Opening the Printer Status Display Before opening the Printer Status Display, make sure that the printer is connected to your computer with the parallel interface cable. Use the procedure below to open the Printer Status Display.
Page 154: To Close The Printer Status Display
This area provides you with explanations of what you need to do in order to correct problems and recover from error conditions. Printer Status figure This area shows a graphic representation of the printer and indicates where there is a problem.
Page 155: Switching Between The Expanded And Reduced Views
Expand • The expanded view is the normal size shown under “Using the Printer Status Display” on page 5-2. The reduced view is shown below. On-line Help Use the menu to display online help about the Status Display.
Page 156: Using The Control Panel
Using the Control Panel Using the Control Panel The Control Panel displays the current settings of the printer on separate tabs. Click on a tab to view its contents or to change its settings. The following sections show the contents of each of the tabs and provide brief explanations of each setting available.
Page 157: Common Buttons
Using the Control Panel Common Buttons The following buttons appear at the bottom of all the tabs. Click to exit the Control Panel, saving any changes made. Cancel Click to exit the Control Panel, discarding any changes made. Set Default Click to return Control Panel settings to their defaults.
Page 158: Paper
Paper Time Out During manual feeding of paper, the printer pauses during printing to wait for you to feed the next sheet. The “paper timer out” condition exists when the printer is paused and nothing happens for about 10 minutes. Setting Proceed Paper is automatically fed from another paper tray.
Page 159 Using the Control Panel Tray1 Setting Specify whether Tray 1 is a multi-purpose ( ) tray or a Multiple Size fixed-size tray. When is selected, a size mismatch error Multiple Size (Load XX) does not occur regardless of the size of paper loaded in Tray is a convenient setting for printing documents on Multiple Size various sizes of paper from Tray 1.
Page 160: Printer Setting
1 to 60 minutes. Detect Size Error This setting enables the printer to automatically detect if paper of a size that is not currently specified has been loaded into the currently selected tray. Select...
Page 161: Print Language
The fuser will not warm up immediately after receiving a print job when is selected. Print Language Select the desired language of the printer from this drop-down list. You can select from PCL, PS (optional) and Auto.
Page 162: Test Print
Demo Page Print Click this button to print a Demo Page. Configuration Print Click this button to print a page that shows the printer’s current configuration. Print the List of PCL Resident Fonts Click this button to print a list of the PCL resident fonts that are installed on your printer.
Page 163: Counter
Counter Total Counter This value shows how many pages have been printed throughout the life of the printer. This value cannot be reset. Tray2 Counter This value shows how many pages have been printed from Tray 2. This value can be reset to zero by clicking the Tray3 Counter This value shows how many pages have been printed from Tray 3.
Page 164: Configuration
Using the Control Panel Configuration Printer Name This box shows the name assigned to the printer. Total Memory This box shows how much memory is installed on the printer. Additional Accessories This box shows any additional accessories installed on the printer. 5-12...
Page 165: Chapter 6: Maintenance
Chapter Maintenance...
Page 167: Replacing The Imaging Cartridge
To use as much of the remaining toner as possible, remove the imaging cartridge, shake it 2 or 3 times and reinstall it in the printer. If print quality is not satisfactory, you should replace the imaging cartridge with a new one according to the following procedure.
Page 168: To Replace The Imaging Cartridge
To Replace the Imaging Cartridge Caution • The fusing unit inside the printer can become very hot during opera- tion. Do not touch the area to avoid injury. Turn the printer off and then disconnect the power cord and interface...
Page 169 Note • Be sure to close the face-down tray before opening the top cover to prevent injuries. Remove the old imaging cartridge. Note • Do not touch the shutter of the imaging cartridge to avoid causing damage to the drum unit. When handling the imaging cartridge, always use the handle.
Page 170 Holding it with both hands, shake it 4 or 5 times in the direction of the arrows to distribute the toner evenly. Install the imaging cartridge securely into the printer by sliding the pins on each side of the cartridge along the grooves of the car-...
Page 171 Replacing the Imaging Cartridge Close the top cover and press it down gently but firmly until it locks into place.
Page 172: Cleaning The Printer
Dust, dirt, and paper debris on the outer surfaces and inside the printer can interfere with printer performance. Clean the printer regularly. Note • Use a soft cloth to clean the printer. Never use abrasives or corrosive detergents. Caution • The fusing unit can become very hot during operation. Do not touch the area to avoid injury.
Page 173: Cleaning The Paper Transport Roller
Cleaning the Paper Transport Roller Turn off the printer and unplug the power cord. Close the face-down tray and press the top cover release button to open the top cover. Note • Be sure to close the face-down tray before opening the top cover to prevent injuries.
Page 174 Remove the imaging cartridge. Note • Immediately wrap the imaging cartridge with a cloth to protect it from overexposure to light. Pull back on the cover that protects the paper transport roller located at the bottom of the printer chamber.
Page 175 Use a soft cloth to wipe the paper transport roller. Reinstall the imaging cartridge as shown on page 6-4 and 6-5. Cleaning the Printer...
Page 176 Cleaning the Printer Close the top cover and press it down gently but firmly until it locks into place. 6-10...
Page 177: Chapter 7: Troubleshooting
Chapter Troubleshooting...
Page 179: Technical Support
Technical Support Technical support for all Minolta PageWorks printer products is available 24 hours a day, seven days a week by calling within North America). Minolta also maintains a Web site which provides printer driver downloads, Frequently Asked Questions and handles all e-mail requests for technical assistance at: http://www.minoltaprinters.com.
Page 180: Clearing A Paper Misfeed
Use the following procedure to remove a misfed paper from inside the printer. Caution • The fusing unit inside the printer can become very hot during opera- tion. Do not touch the area to avoid injury. Close the face-down tray and press the top cover release button to open the top cover.
Page 181 Clearing a Paper Misfeed Remove the imaging cartridge. Note • Immediately wrap the imaging cartridge with a cloth to protect it from overexposure to light.
Page 182 Clearing a Paper Misfeed Pull the end of the paper that is visible straight out of the printer. Caution • Do not touch the image transfer roller.
Page 183 Reinstall the imaging cartridge as shown on page 6-4 and 6-5. Close the top cover and press it down gently but firmly until it locks into place. Clearing a Paper Misfeed...
Page 184: Paper Output Misfeed
Clearing a Paper Misfeed Paper Output Misfeed Pull the misfed paper straight out of the printer.
Page 185: Paper Input Misfeed (From Tray 1)
Clearing a Paper Misfeed Paper Input Misfeed (from Tray 1) Remove the tray cover and pull the misfed paper straight out of the printer. Paper Input Misfeed (from Manual Feed Tray) Pull the misfed paper straight out of the printer.
Page 186: Paper Input Misfeed (From Second/Third Paper Cassette Unit)
Press down on the stack of paper until the paper lifting plate locks. Tray 2 Remove the stack of paper from the tray and pull the misfed paper straight out of the printer. Tray 2 Tray 3 Tray 3...
Page 187: Paper Misfeed In The Duplex Unit
Clearing a Paper Misfeed Paper Misfeed in the Duplex Unit Upper Misfeed Open the duplex upper cover and pull out the misfed paper. Duplex upper cover Lower Misfeed Open the duplex lower cover and remove the misfed paper. Duplex lower cover...
Page 188: Print Quality Problems
(page 6-2). • The imaging cartridge may be defective. Remove the imaging cartridge and check it for damage. Replace the imaging cartridge if necessary (page 6-2). • Your printer may require servic- ing. Contact Minolta Technical Support.
Page 189: Printout Too Light
Printout too light Printout too dark Print Quality Problems • The toner save setting of the printer driver may be “On”. Change the setting and try print- ing again. • The imaging cartridge may be running out of toner. Remove the imaging cartridge...
Page 190: Blurred Background
Print Quality Problems Blurred background Uneven print density Irregularities 7-12 • The imaging cartridge may be defective. Remove the imaging cartridge and check it for damage. Replace the imaging cartridge if necessary (page 6-2). • The toner may be unevenly dis- tributed inside the imaging car- tridge.
Page 191: White Or Black Line
White or black line Toner smudges Print Quality Problems • The imaging cartridge may be defective. Remove the cartridge and check it for damage. Replace the cartridge if necessary. • The toner may be unevenly dis- tributed inside the imaging car- tridge.
Page 192: No Output
Save the data you are trying to print and close all the applications currently open on your computer. Next, reset your computer to send a break signal to the printer. Now check your printer cable against the specifications in Chapter 8 of this User’s Manual.
Page 193: Chapter 8: Specifications
Chapter Specifications...
Page 195: Pageworks 18N Printer
Paper feeding: Input capacity: Output capacity: Warm-up time: PageWorks 18N Printer Desktop laser beam printer Electrostatic dry powder imaging system Laser diode + polygon mirror scanning 1200 600 dpi, 600 600 dpi + Fine-ART One sided: 18 pages per minute...
Page 196 67 dB(A) max. (operating); 33 dB(A) max. (power saving mode) 14-3/4" (374 mm) 17-5/32" (436 mm) 20" (511 mm) Printer: Approx. 28-3/4 lbs. (13 kg) Imaging cartridge: Approx. 3-1/4 lbs. (1.5 kg) Parallel Centronics (IEEE 1284/ECP) Power PC 403GCX/66MHz 4 MB (expandable up to 64 MB) Power cord, User’s Manual,...
Page 197 PageWorks 18N Printer Options: Third paper cassette unit; Duplex unit; DRAM SIMM; Adobe PostScript ROM-SIMM (options available from local dealer)
Page 198: Second Paper Cassette Unit
Second Paper Cassette Unit Second Paper Cassette Unit Paper feeding system: One-way system (multi-feed tray) Paper types: Paper cassettes: Tray capacity: Operating temperature: 10 to 35 C Operating humidity: External dimensions: Height: Width: Depth: Weight: Ordinary plain paper (60 to 90 g/m 24 lbs.);...
Page 199: Third Paper Cassette Unit (Option)
Third Paper Cassette Unit (Option) Paper feeding system: One-way system (multi-feed tray) Paper types: Paper cassettes: Tray capacity: Operating temperature: 10 to 35 C Operating humidity: External dimensions: Height: Width: Depth: Weight: Third Paper Cassette Unit (Option) Ordinary plain paper (60 to 90 g/m 24 lbs.);...
Page 200: Duplex Unit (Option)
Duplex Unit (Option) Duplex Unit (Option) Paper feeding system: One-way system Paper types: Paper size: Operating temperature: 10 to 35 C Operating humidity: External dimensions: Height: Width: Depth: Weight: Ordinary plain paper (64 to 90 g/m 24 lbs.); recycled paper (64 to 90 g/m to 24 lbs.) A4, A5, JIS B5, Letter, Legal, Executive 15% to 85%...
Page 201: Interface Connector And Cable
• Minolta does not warrant the use of any particular cable. The user assumes all responsibility as to the quality and performance of the cable. Interface Connector and Cable Less than 10 feet (3 meters) Printer: Parallel 36-pin connector EIA 25-pin connector Shielded. Each signal and ground pair should be twisted.
Page 202: Simm (Option)
SIMM (Option) SIMM (Option) You can expand printer memory by adding a single in-line memory module (SIMM). SIMMs are available from Minolta Technical Support. Capacity: Parity: Type: Access speed: Number of Pins: 1, 2, 4, 8, 16, 32 MB Non-parity...
Page 203 Appendix Glossary...
Page 205 To press and release a mouse button quickly. Often used to select an object. SEE double-click. control panel A bank of indicators that show the current status of the printer. Panel buttons that are located on the control panel make it possible to perform a variety of different operations.
Page 206 This port is used to connect the printer to an Ethernet. face down tray This tray receives the printed documents, face down, as they are output from the printer. The tray can hold up to 100 sheets of paper. 500-sheet second cassette SEE Tray 2.
Page 207 Network Interface Card (NIC) Facilitates the network connection of the printer. off line A state in which the printer cannot receive data or perform any other operation. on line A state in which the printer can receive data and operate.
Page 208 A connector that enables the transfer of data between the printer and the computer. peripheral device Any device that can be attached to the computer, such as a printer. PostScript Developed by Adobe Systems, PostScript is one of the most well known page description languages.
Page 209 A typeface that can be displayed on the computer’s monitor. second paper cassette unit A tray unit that feeds an additional 500 sheets of paper to the printer. SIMM Acronym for single in-line memory module. hird paper cassette unit (option) An available option for your printer that expands printing capacity.
Page 210 Glossary Tray 2 Five types of Tray 2 cassettes can be installed into the second paper cassette unit (SEE second paper cassette unit). Each cassette can hold up 500 sheets of one of the following paper sizes: A4, JIS B5, Legal, Letter and Executive.
Page 211 Appendix Index...
Page 213 DOS Printing Utilities Duplex Printing Duplex Unit Ethernet interface connector (10/100BaseT) Face-Down Tray Features Font Selection Screen Fusing unit Getting Around in the Printer Control Panel Glossary Grounding Help (button) Image transfer roller Imaging cartridge Indicator Lights Installation Precautions Installing the Face-Down...
Page 214: Interface Connector And Cable
Loading Paper onto Tray 2/Tray 3 Manual feed tray Manual Paper Feed 3-11 Network Interface Card (NIC) 1-3, 2-18 No output 7-14 On-line Help Opening the Printer Status Display Operating Environment Operational Precautions Options 2-19 Output Quality Screen Page Layout 4-31 Paper...
Page 215 Technical Support Test Print 5-10 Testing the Printer 2-15 Third Paper Cassette Unit 1-2, 2-27, 8-5 To Access the Printer Control Panel 4-52 To Close the Printer Status Display To Display the Driver Setup Dialog Under Windows 95/98 4-21 To Display the Driver Setup Dialog Under Windows NT 4.0...
Page 216 MEMO...
Page 217 MEMO...
Page 218 MEMO...
Page 219 Copyright 1999 MINOLTA CO., LTD Printed in Japan The information contained in this manual is subject to change without notice to incorporate improvements made on the product or products the manual covers. Minolta CO., LTD. Image Information Products Marketing Headquarters, 3-13, 2-chome, Azuchi-machi, Chuo-ku, Osaka. 541-8556, Japan 1999.

This manual is also suitable for:

Pageworks 18n

Minolta PageWorks Pro 18N User Manual

Chapter 1: Introduction

Features

Printer Parts and Accessories

Control Panel

Chapter 2: Setting-Up

Installation Precautions

Operational Precautions

Setting-Up

Options

Chapter 3: Using the Printer

Paper

Loading Paper

Chapter 4: Printer Driver

Introduction

System Requirements

Installing the Printer Driver under Windows 95/98

Installing the Printer Driver under

Windows NT 4.0

Installing the Printer Driver under Windows 3.1

Displaying the Driver Setup Dialog (Windows 95/98/NT 4.0)

Using the Printer Driver under

Windows 95/98/NT 4.0

Displaying the Driver Setup Dialog (Windows 3.1)

Using the Printer Driver under Windows 3.1

DOS Printing Utilities

Installing the Printer Driver under DOS

Loading and Unloading the Status Display

Accessing the Printer Control Panel

Using the Printer Control Panel

Printer Control Panel Screens

Using the Status Display

Chapter 5: Printer Status Display and Control Panel

Using the Printer Status Display

Using the Control Panel

Chapter 6: Maintenance

Replacing the Imaging Cartridge

Cleaning the Printer

Chapter 7: Troubleshooting

Clearing a Paper Misfeed

Print Quality Problems

Chapter 8: Specifications

Pageworks 18N Printer

Second Paper Cassette Unit

Third Paper Cassette Unit (Option)

Duplex Unit (Option)

Quick Links

Related Manuals for Minolta PageWorks Pro 18N

Summary of Contents for Minolta PageWorks Pro 18N
