Page 1 Fiery X3 for Pi5500 CONFIGURATION GUIDE...
Page 3 Copyright © 2001 Electronics For Imaging, Inc. All rights reserved. This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics For Imaging, Inc., except as expressly permitted herein.
Page 4 FCC Information Declaration of Conformity Trade Name: Fiery Server Model Number: MXI-01 for Minolta Di550 Compliance Test Report Number: M00829A1 Compliance Test Report Date: September 11, 2000 Responsible Party (in USA): Electronics For Imaging, Inc. Address: 303 Velocity Way, Foster City, CA 94404...
Page 5 CE Marking (Declaration of Conformity) We declare under our sole responsibility that the copier and options to which this declaration relates is in conformity with the speciﬁcations below. This declaration is valid for the area of the European Union (EU) only. Product Type Digital Copier with Printer Controller System Product...
Page 6 You may: a. use the Software solely for your own customary business purposes and solely with Pi5500; b. use the digitally-encoded machine-readable outline and bitmap programs (“Font Programs”) provided with Pi5500 in a special encrypted format (“Coded Font Programs”) to reproduce and display designs, styles, weights, and versions of letters, numerals, characters and symbols (“Typefaces”) solely for your own customary business purposes on the display window of the Pi5500 or monitor used with Pi5500;...
Page 7 Limitation Of Liability IN NO EVENT WILL ELECTRONICS FOR IMAGING OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOST PROFITS, COST OF COVER OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING FROM THE USE OF THE SOFTWARE, CODED FONT PROGRAMS OR ACCOMPANYING DOCUMENTATION, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY.
Page 9: Table Of Contents
Contents Introduction Network administration features xiii About this manual Organization About the documentation Chapter 1: Connecting to the Network Pi5500 on the network Stages of installation on the network Quick path to installation Before you begin 1-11 Ethernet cable connection 1-12 Back view of the Pi5500 1-12...
Page 10 x Contents Printer Setup options 2-40 PS Setup options 2-42 PCL Setup options 2-44 Administrative functions in the Setup menu 2-46 Job Log Setup options 2-47 Change Password 2-48 Clear Server 2-49 Factory Defaults 2-49 Exit Setup 2-49 Printing the Conﬁguration page 2-50 Chapter 3: Setting up the Pi5500 from a Windows Computer Accessing Setup...
Page 11 xi Contents PServer Setup (Bindery Setup) 3-21 Service Setup (Windows Printing Service) 3-23 Service Setup (Enable LPD Printing Service) 3-24 Service Setup (Enable Port 9100) 3-24 Service Setup (Enable Web Services) 3-24 Printer Setup 3-27 Printer Setup 3-28 Paper Setup 3-30 Exiting Setup 3-31...
Page 12 xii Contents Chapter 5: Administering the Pi5500 Administrator functions Maintaining optimal performance Troubleshooting Troubleshooting during Setup Runtime error messages Appendix A: Token Ring Network Option Pi5500 Token Ring option Connecting Token Ring hardware IPX/SPX installations TCP/IP installations Setting up Token Ring on the Pi5500 Setting up NetWare Windows clients Index...
Page 13: Introduction
xiii Network administration features This manual is intended for anyone who is responsible for integrating the Fiery X3 for Introduction Pi5500 ™ into a business environment that includes networked personal computers. After setting up the Fiery X3 for Pi5500 and client workstations, as described in this manual and in Getting Started, individual users can print to the Fiery X3 for Pi5500 as a high-performance printer.
Page 14: About This Manual
xiv Introduction • Support for PCL and PostScript PCL (Printer Control Language) and PostScript are both page description languages— computer languages that control the transfer of information from the computer to the controller. Both PCL and PostScript, along with separate sets of fonts, are standard with the Pi5500.
Page 15: About The Documentation
xv About the documentation • Chapter 3 describes Pi5500 conﬁguration from a Windows computer. • Chapter 4 offers guidelines for setting up Windows NT and Novell network servers and UNIX systems for printing to the Pi5500. • Chapter 5 summarizes some administrative features of Pi5500 software that are available for IPX/SPX, TCP/IP, and AppleTalk networks, and also offers some troubleshooting hints.
Page 17: Chapter 1: Connecting To The Network
1-1 Pi5500 on the network This chapter summarizes the stages in setting up the Pi5500 and includes diagrams Chapter 1: that refer you to other chapters or other manuals for completing your installation. Connecting to the Network Pi5500 on the network When the Pi5500 is connected to a network, it behaves as a networked PCL or PostScript printer.
Page 18: Stages Of Installation On The Network
1-2 Connecting to the Network Stages of installation on the network Installation can be performed by a network or printing administrator. The stages of a successful installation are: • Physically connecting the Pi5500 to a functioning network Prepare a network node for the Pi5500—obtain cable and route it to the location where the Pi5500 will be installed, and attach the cable to the network interface of the Pi5500.
Page 19 1-3 Stages of installation on the network Summary of Pi5500 network installation ONNECTION Pi5500 Prepare a network node. Connect the Pi5500 to the copier and the network. ETWORK ERVER Conﬁgure UNIX, Windows NT 4.0, and Network server ONFIGURATION Netware (Novell) servers to specify Pi5500 print queues and Pi5500 users.
Page 20: Quick Path To Installation
1-4 Connecting to the Network Quick path to installation The diagrams in the following pages show typical systems that can be used for printing and for using remote utilities. To use the diagrams, ﬁnd the page with your preferred platform and network type. Then look up the setup procedures in the pages and books referred to in the keys.
Page 21 1-5 Quick path to installation Mac OS environment with AppleTalk Key to setup: 1 Pi5500 Setup Chapter 2 2 Mac OS computer Getting Started Another supported protocol Pi5500 connected to copier AppleTalk Mac OS computer Mac OS computer Mac OS computers can print Mac OS computer directly and use Fiery utilities.
Page 22 1-6 Connecting to the Network Windows computers in a Novell environment Key to setup: 1 NetWare server page 4-4 2 Pi5500 Setup Chapter 2 3 NetWare client Getting Started Another supported protocol 4 Windows computer with SPX page 4-10, Getting Started Pi5500 connected to copier NetWare server SPX for using Fiery utilities...
Page 23 1-7 Quick path to installation Windows NT Server environment Key to setup: 1 Windows NT 4.0 Server page 4-12 2 Pi5500 Setup Chapter 2 3 Windows NT 4.0 client page 4-15 Another supported protocol Pi5500 connected to copier Windows NT Workstation or Windows NT Server acting as print server LAN with...
Page 24 1-8 Connecting to the Network Windows computers using Windows (SMB) printing Key to setup: 1 Pi5500 Setup Chapter 2 2 Windows computer Getting Started Another supported protocol Pi5500 connected to copier TCP/IP (nbt) Windows computer Windows computer Windows computer For Windows printing Windows computers Windows (SMB) printing enabled TCP/IP (nbt) protocol...
Page 25 1-9 Quick path to installation UNIX workstations and Windows NT 4.0 computers on a TCP/IP network Key to setup: 1 UNIX server/host page 4-19 2 Pi5500 Setup Chapter 2 Another supported 3 UNIX workstation page 4-19 protocol 4 TCP/IP client Getting Started, page 4-15 5 Windows NT 4.0 client page 4-15...
Page 26 1-10 Connecting to the Network Pi5500 parallel port connection Key to setup: 1 Pi5500 Setup Chapter 2 2 Windows computer Getting Started A supported network protocol Parallel input Pi5500 connected to copier With the parallel port enabled, the Pi5500 can accept and print jobs sent to Protocol not directly its parallel port.
Page 27: Before You Begin
1-11 Before you begin Before you begin The following steps should be completed before you conﬁgure the Pi5500 and the workstations that will print to the Pi5500. A service technician will have performed some initial installation. 5500 O PREPARE FOR CONFIGURATION 1.
Page 28: Ethernet Cable Connection
1-12 Connecting to the Network Ethernet cable connection The Pi5500 supports Ethernet cabling with Unshielded Twisted Pair (UTP) cable, deﬁned as Category 5 for use with 100BaseT or deﬁned as Category 3 or Category 5 for use with 10BaseT. The cable plugs into the RJ-45 socket on the Pi5500. The 100BaseT type supported by the Pi5500 is 100BaseTX, also known as Fast Ethernet.
Page 29: Parallel Cable Connection
1-13 Parallel cable connection When you connect the Pi5500 to the network, do not touch the pins of the Pi5500 connectors with your ﬁngers or any metal object. Such contact can cause a discharge of static electricity that will damage the Pi5500. 100B O USE CABLE FOR...
Page 31: Chapter 2: Setting Up The Pi5500
2-1 About Pi5500 Setup The Pi5500 ﬁts into a variety of work environments. To prepare for printing at your Chapter 2: site, you need to do some initial conﬁguration to specify the network environment and Setting up the kind of printing you will do. the Pi5500 About Pi5500 Setup When the copier is turned on after new system software is loaded, you (or the service...
Page 32: Pi5500 Setup From The Control Panel
2-2 Setting up the Pi5500 Pi5500 Setup from the Control Panel Setup performed from the Control Panel after turning on or restarting the Pi5500 conﬁgures the Pi5500 to communicate with other devices and manage print jobs sent to it. Setup provides the following groups of options: •...
Page 33: Accessing Setup Options
2-3 Pi5500 Setup from the Control Panel Accessing Setup options The Control Panel on the front of the Pi5500 enables you to set options and view information about jobs printed to the Pi5500. The Control Panel comprises the following parts: •...
Page 34: About The Control Panel Setup Interface
2-4 Setting up the Pi5500 5500 O ACCESS ETUP FROM THE 1. When the Pi5500 displays the Idle screen, press the Menu button on the Control Panel to go to the Functions menu. 2. Scroll the menu and press the line selection button to choose Run Setup. Run Setup Run Diagnostics If an Administrator password has been set on the Pi5500, you are prompted to...
Page 35: Types Of Setup Screens
2-5 Pi5500 Setup from the Control Panel Types of Setup screens The two Setup options are: Multiple choice You are given choices (for example, Yes or No, or a list of questions options from which to choose). Only one choice is displayed at a time, in highlighted text.
Page 36 2-6 Setting up the Pi5500 Example: Multiple choice Publish Print Queue Publish Print Queue Printer Setup Printer Setup Press up or down to When the setting you display the other option want is displayed, press or options. the button beside OK to continue.
Page 37: Server Setup Options
2-7 Server Setup options If you make a mistake during Setup, you can always use the Menu button to cancel without saving changes. If you are viewing a Setup screen, pressing the Menu button cancels what you are doing in the current screen to bring you to the next higher-level menu.
Page 38 2-8 Setting up the Pi5500 System Time Use this option to change the system time. Enter the time based on the 24-hour clock in the form HH:MM (Hours:Minutes). The time is used on the cover page and in Job Logs. Time Zone Specify the correct time zone.
Page 39: Network Setup Options
2-9 Network Setup options Clear Each Scan Job After 1 day/After 1 week/Manually/Now [After 1 day] Specify how you want to remove scanned data from the HDD. If you select Manually, the scanned data remains on the HDD until speciﬁcally deleted, or until all scanned jobs are cleared by the Administrator.
Page 40 2-10 Setting up the Pi5500 The available network types, and the Setup areas that pertain to them, are summarized in the following tables. For this Network or Use this Use this Use this Connection Type Port Setup Protocol Setup Service Setup AppleTalk over Ethernet Ethernet Setup AppleTalk Setup...
Page 41: Port Setup Options
2-11 Network Setup options 4. To use Ethernet, choose Ethernet Setup from the Port Setup menu, and enter the appropriate settings. 5. If the Token Ring option is installed, choose Token Ring Setup and enter the appropriate settings. 6. To print to the parallel port, choose Parallel Port Setup from the Port Setup menu, and enter the appropriate settings.
Page 42 2-12 Setting up the Pi5500 Network Setup Port Setup Ethernet Setup Enable Ethernet Yes/No [Yes] Select Yes if you have Ethernet cabling connected to the Pi5500. Ethernet Speed Auto Detect/100 Mbps/10 Mbps [Auto Detect] Select Auto Detect if your network environment is mixed, or select the speed of the network to which the Pi5500 is attached.
Page 43 2-13 Network Setup options Source Routing Respond All Route Yes/No [No] This option appears only if you answered No to the previous option. Select Yes if you want the Response packet to return by all routes to the originating computer. Parallel Port Setup options You must enable the parallel port in order to enter the Parallel Port Setup options and print to the parallel port.
Page 44: Protocol Setup Options
2-14 Setting up the Pi5500 When you have configured the port options, choose another port type, or choose Exit Port Setup and proceed to Protocol Setup. Protocol Setup options To conﬁgure the Pi5500, choose each protocol and enter the settings for that protocol. Exit Protocol Setup AppleTalk Setup You can enable AppleTalk, TCP/IP, and IPX/SPX communication simultaneously.
Page 45 2-15 Network Setup options TCP/IP Setup options To conﬁgure the Pi5500 for TCP/IP, choose TCP/IP Setup. Exit Protocol Setup AppleTalk Setup TCP/IP Setup IPX/SPX Setup Protocol Setup Enter the appropriate settings for the network type you use (Ethernet or Token Ring). Exit TCP/IP Setup Ethernet Setup Token Ring Setup appears as an option only if you have enabled Token Ring in Port...
Page 46 2-16 Setting up the Pi5500 TCP/IP Setup with Ethernet Network Setup Protocol Setup TCP/IP Setup Ethernet Setup Enable TCP/IP for Ethernet Yes/No [Yes] Select Yes if you have a TCP/IP network connected to the Pi5500 over Ethernet cabling. You must enable TCP/IP for Ethernet to use the Fiery WebTools over Ethernet.
Page 47 2-17 Network Setup options IP Address [127.0.0.1] Enter the Pi5500 IP address for Ethernet. This IP address, unlike an IP address set automatically, remains the same if you restart the Pi5500. You must change the default to a valid address for your network. Subnet Mask [255.255.255.0] This option lets you modify the subnet mask for printing with TCP/IP over Ethernet.
Page 48 2-18 Setting up the Pi5500 TCP/IP Setup with Token Ring Enable TCP/IP for Token Ring, and enter the IP address and subnet mask. If your TCP/IP network has a gateway, and users outside the gateway plan to print to the Pi5500 using TCP/IP, enter the gateway address.
Page 49 2-19 Network Setup options IP Address [127.0.0.1] Enter the Pi5500 IP address for Token Ring. This IP address, unlike an IP address set automatically, remains the same if you restart the Pi5500. You must change the default to a valid address for your network. Subnet Mask [255.255.255.0] This option lets you modify the subnet mask for printing with TCP/IP over Token...
Page 50 2-20 Setting up the Pi5500 Enable IPX Auto Frame Type Yes/No [No] Choose Yes to select all available frame types, whether or not they are appropriate. To determine the frame types that were successfully bound, save your changes, exit Setup, and print a Conﬁguration page.
Page 51: Service Setup Options
2-21 Network Setup options Service Setup options Exit Service Setup LPD Setup Network Service Setup has options for TCP/IP and IPX/SPX networks, as well as for PServer Setup Windows Setup local area Windows printing. Service Setup • LPD Setup enables lpd printing on TCP/IP networks. •...
Page 52: Queues
2-22 Setting up the Pi5500 PServer Setup Network Setup Service Setup PServer Setup Enable PServer Yes/No [No] Select Yes if you have a Novell network connected to the Pi5500. Choose NDS Setup if your network uses NetWare 4.x/5.x in native mode. Choose Exit PServer Setup NDS Setup Bindery Setup if your network uses NetWare 3.x or NetWare 4.x/5.x in bindery...
Page 53 2-23 Network Setup options Enable NDS Yes/No [No] Select Yes if the NetWare servers you will use to print to the Pi5500 are running NetWare 4.x/5.x in native mode. Select NDS Tree List of trees Use the arrow keys to browse the list of NDS trees available to the Pi5500. Choose OK when you have displayed the tree that contains the Printer, Print Server, and print queue objects you have previously deﬁned for the Pi5500.
Page 54 2-24 Setting up the Pi5500 NDS Tree name Object list, “..” Browsing to ﬁnd the User Login object begins with the NDS tree that you selected previously (with Select NDS Tree). Use the Up and Down arrow buttons to scroll a list of objects in the tree beneath the [Root] in the hierarchy, or use the navigation symbol “..”...
Page 55 2-25 Network Setup options Enter Print Server Password Enter the Print Server password, using the Up and Down arrow buttons to enter characters, and the left and right arrow buttons to move the cursor. Choose OK. (If no password is required, choose OK.) Server should look for print queues in: Entire NDS Tree/Specified Subtree [Entire NDS Tree]...
Page 56 2-26 Setting up the Pi5500 With an object selected, choose OK to travel down the tree, or choose “..” to go up the tree. When you select an object and choose OK, that object is then displayed on the top line, and the second line lists objects contained within. When the container that contains print queues is displayed in the second line, choose OK.
Page 57 2-27 Network Setup options Bindery Setup menu Because you can set up more than one Novell server to handle Pi5500 print jobs, an Exit Bindery Setup Add File Server additional menu is displayed for this purpose. The options are: View Server List Edit Connection •...
Page 58 2-28 Setting up the Pi5500 If you change your mind about any of the menus you have selected, use the Menu button to escape and return to the main Bindery Setup menu. To cancel all changes, you must exit Network Setup. Network Setup Service Setup PServer Setup...
Page 59 2-29 Network Setup options File Server Login administrator/supervisor/Enter Login Name [supervisor] This option appears only if a password is required for login, or if there is no unrestricted guest account. Choose Enter Login Name to enter your own login name and password or to log in as a guest.
Page 60 2-30 Setting up the Pi5500 Network Setup Service Setup PServer Setup Bindery Setup View Server List Supported Servers This option lets you view the list of ﬁle servers currently connected to the Pi5500, that is, servers you have added in Bindery Setup. You are notiﬁed if there are none. When you choose OK, you return to the Bindery Setup menu.
Page 61 2-31 Network Setup options The Bindery Setup menu is displayed again. You can edit other connections, choose another Bindery Setup option, or choose Exit Bindery Setup. Network Setup Service Setup PServer Setup Bindery Setup Remove File Server Remove support for File server name Allows you to select a NetWare ﬁle server from a list of connected ﬁle servers and remove the connection to it.
Page 62 2-32 Setting up the Pi5500 Polling Interval options Whether you are using NDS or Bindery services, you may choose Polling Interval from the main PServer Setup menu. If you do not reset the interval, the default value of 15 seconds is used. Network Setup Service Setup PServer Setup...
Page 63 2-33 Network Setup options Be sure the administrator conﬁgures the printer driver defaults before Windows NT 4.0 clients install the printer driver with Point and Print. The Pi5500 Adminstrator name and Password are required during Point and Print installation if you want to change defaults for the Windows NT 4.0 printer driver.
Page 64 2-34 Setting up the Pi5500 Set Domain name Select from list/Enter Manually [Select from list] This option provides two ways to specify the workgroup or domain in which you want the Pi5500 to appear. If you selected If you selected Select from list Enter manually Choose Domain...
Page 65 2-35 Network Setup options Port 9100 Setup Network Setup Service Setup Port 9100 Setup Enable Port 9100 Yes/No [No] This option allows applications to open a TCP/IP socket to the Pi5500 at Port 9100 to download a print job. Port 9100 Queue Direct/Print Queue/Hold Queue [Print Queue] Specify the Pi5500 print connection for downloading jobs to Port 9100.
Page 66 2-36 Setting up the Pi5500 RD Admin Domain Name yourdomain.com This options appears only if you have selected Yes to Enable Remote Diagnostics. Enter the name of the Fiery domain where the administrator has an account. This is typically the part of the e-mail address that follows the @ symbol. For example, in the address pat@test.com , the domain name is...
Page 67 2-37 Network Setup options Fiery E-mail Domain Name Enter the name of the Fiery domain where the user has an account. This is typically the part of the e-mail address that follows the @ symbol. For example, in the address , the domain name is pat@test.com test.com...
Page 68 2-38 Setting up the Pi5500 Timeout (sec) 30...300 [60] Enter the length of time in seconds that the Pi5500 should try to connect to each e-mail server before determining that the connection is unsuccessful. Polling Interval (sec) 5...3600 [15] Enter the interval in seconds at which the Pi5500 should automatically check for new e-mail.
Page 69 2-39 Pi5500 print connections Pi5500 print connections In Pi5500 Printer Setup, you decide how the Pi5500 manages print jobs by deciding which printing connections should be “published” to users over the network. All published connections are constantly checked for the presence of jobs. If you do not want users to print to a connection, do not publish it.
Page 70: Printer Setup Options
2-40 Setting up the Pi5500 The Pi5500 hard disk supports up to three queues (Print, Hold, and Printed). Users may print to two of them (Print and Hold). • —This is the standard Pi5500 queue. The Pi5500 prints jobs from the Print queue Print queue in the order in which they were received.
Page 71 2-41 Printer Setup options In the list of options that follows, default values, where applicable, appear in square brackets. Publish Direct Connection Yes/No [Yes] This option enables users to print (or download) jobs to the Pi5500 without spooling. Jobs printed to the Direct connection are not saved in the Printed queue. If you plan to download fonts to the Pi5500, you must publish the Direct connection.
Page 72: Ps Setup Options
2-42 Setting up the Pi5500 Personality Auto/PCL/PostScript [Auto] In PCL or PostScript mode, the Pi5500 is restricted to PCL or PostScript jobs, respectively. Jobs sent to the Pi5500 that do not match the personality selected on the Pi5500 are not printed. In Auto mode, the Pi5500 switches to the appropriate page description language for each job.
Page 73 2-43 PS Setup options Print Cover Page Yes/No [No] Use this option to specify whether the Pi5500 prints a cover (job summary) page at the end of each print job. If you select Yes, each print job is followed by a page containing the name of the user who sent the job, the document name, the server name, the time the job was printed, the number of pages printed, and the status of the job.
Page 74: Pcl Setup Options
2-44 Setting up the Pi5500 PCL Setup options PCL (Printer Control Language) printer drivers are provided with the Pi5500 on the User Software CD. PCL Setup allows you to set defaults to control printer output. These defaults can be overridden by the user from within an application, but they determine how a job will be printed in the absence of other information.
Page 75 2-45 PCL Setup options Font Pitch (char/in) [10.00] When the number selected in Font Number represents a ﬁxed pitch scalable font, the Font Pitch (char/in) option appears, allowing you to determine the width of scalable type. Pitch is measured by characters per inch, so 10-pitch type ﬁts 10 characters per inch.
Page 76: Administrative Functions In The Setup Menu
2-46 Setting up the Pi5500 Administrative functions in the Setup menu The remaining options in the Setup menu allow you manage print jobs, but are not required for printing: • allows you to specify whether the Pi5500 prints and clears its log of Job Log Setup printed jobs automatically.
Page 77: Job Log Setup Options
2-47 Administrative functions in the Setup menu Job Log Setup options The Job Log is a record of all jobs processed or printed on the Pi5500, whether they originate from a user workstation, a networked server, the Pi5500, or a computer attached to the parallel port.
Page 78: Change Password
2-48 Setting up the Pi5500 In addition to Auto Clearing or manual clearing through Fiery WebSpooler, the Job Log (together with all queued jobs) is also cleared when you choose Clear Server from the main Setup menu, when system software is reinstalled, or when a new version of system software is installed on the Pi5500.
Page 79: Clear Server
2-49 Administrative functions in the Setup menu 5500 O CHANGE THE PASSWORD 1. Scroll the main Setup menu and choose Change Password. 2. Enter and conﬁrm the password, as described in the following section. New Password The password can be any combination of letters and numbers up to 19 characters. Choose OK when you are done.
Page 80: Printing The Conﬁguration Page
2-50 Setting up the Pi5500 Printing the Conﬁguration page The Conﬁguration page lists all the settings in effect for the current Setup. After you have performed Setup, print a Conﬁguration page to conﬁrm your settings. O PRINT THE ONFIGURATION PAGE 1.
Page 81: Accessing Setup
3-1 Accessing Setup After you have performed initial Setup (Server, Network, and Printer Setup) from the Chapter 3: Control Panel, you can complete or change most Setup options from a Windows Setting up the computer. Pi5500 from a Windows Accessing Setup Computer You can access Pi5500 Setup from Fiery WebSetup or Command WorkStation.
Page 82 3-2 Setting up the Pi5500 from a Windows Computer Regardless of how you access Setup remotely, the following window appears. The interface of remote Setup from Command WorkStation and Fiery WebSetup is identical. The remote Setup illustrations in this chapter are from Command WorkStation.
Page 83: Server Setup
3-3 Server Setup Server Setup From this window, you can access Server Setup, Passwords, Job Log Setup, and Support. Server Setup —Specify a name for the Pi5500. This is the name that appears in the Server Name Chooser on an AppleTalk network. Do not use the device name (55BW-M) as the server name.
Page 84: Passwords
3-4 Setting up the Pi5500 from a Windows Computer —Specify whether to enable the Printed Queue, a storage Enable Printed Queue location on the Pi5500 disk for recently printed jobs. You can reprint jobs from the Printed queue without sending them to the Pi5500 again. If the Printed queue is not enabled, jobs are deleted from the Pi5500 disk immediately after they are printed.
Page 85 3-5 Server Setup O SET OR CHANGE A PASSWORD 1. Select the password you want to change. 2. Type the password in both the Enter New Password and Verify New Password ﬁelds. Passwords are case-sensitive and can be any combination of letters and numbers up to 19 characters.
Page 86: Job Log Setup
3-6 Setting up the Pi5500 from a Windows Computer If you forget the Administrator password, contact your authorized service representative to reinstall Pi5500 system software. This clears the Administrator password and allows you to set a new one. Job Log Setup —Specify whether the Pi5500 prints the Job Log Auto Print Job Log Every 55 Jobs after every 55 jobs.
Page 87: Support
3-7 Server Setup Support Use the Support tab to enter names, phone numbers, and e-mail addresses of contact people at your organization who provide support for the Pi5500 and the copier.
Page 88: Network Setup
3-8 Setting up the Pi5500 from a Windows Computer Network Setup Network Setup conﬁgures the Pi5500 to receive print jobs over the networks that are used at your site. If the Pi5500 is conﬁgured to enable more than one protocol, it automatically switches to the correct protocol when it receives a print job.
Page 89: Ethernet (Port Setup)
3-9 Network Setup O CONFIGURE NETWORK PORTS • Click the Port tab in the Network Setup dialog box. You can adjust settings, as detailed in the following sections. Ethernet (Port Setup) —Select if the Pi5500 is to be connected to an Ethernet network. Enable Ethernet —This option is set to Auto Detect, which will detect the speed of Transmission Speed...
Page 90: Token Ring (Port Setup)
3-10 Setting up the Pi5500 from a Windows Computer —Available only if Enable Parallel Port is selected, this option Ignore EOF Character speciﬁes that the Pi5500 should ignore end-of-ﬁle (EOF) messages. Select this check box to print PostScript ﬁles in binary format (not ASCII); under normal circumstances, the option should be cleared.
Page 91 3-11 Network Setup TCP/IP O CONFIGURE THE PROTOCOL • Click the Protocol1 tab in the Network Setup window. You can change AppleTalk, IPX/SPX, and TCP/IP protocol settings for the Pi5500 on the Protocol1 and Protocol2 tabs. The Pi5500 can accept jobs via TCP/IP (over either Ethernet or Token Ring), AppleTalk, and IPX/SPX simultaneously.
Page 92: Protocol Setup (Tcp/Ip)
3-12 Setting up the Pi5500 from a Windows Computer Protocol Setup (TCP/IP) —Select this option if you have a TCP/IP network connected to the Enable on Ethernet Pi5500 over Ethernet cabling. You must enable TCP/IP for Ethernet to use the Fiery WebTools over Ethernet. If you are using TCP/IP for printing from Windows NT 4.0 workstations, enabling TCP/IP here also enables you to use Fiery utilities from Windows NT 4.0 workstations using TCP/IP protocols.
Page 93: Protocol Setup (Token Ring)
3-13 Network Setup Protocol Setup (Token Ring) —Select if you have a TCP/IP network connected to the Pi5500 Enable on Token Ring over Token Ring. If you use Token Ring, enabling TCP/IP for Token Ring is required for enabling the Fiery WebTools. If you are using TCP/IP for printing from Windows NT 4.0 workstations, enabling TCP/IP here also enables you to use Fiery utilities from Windows NT 4.0 workstations using TCP/IP protocols.
Page 94: Gateway
3-14 Setting up the Pi5500 from a Windows Computer —If you need to set the subnet mask, enter one of the Subnet Mask (Token Ring) following values: • 255.0.0.0 if the IP address starts with a number less than 128 •...
Page 95: Protocol Setup (Appletalk)
3-15 Network Setup O CONFIGURE PPLE • Click the Protocol2 tab in the Network Setup window. Protocol Setup (AppleTalk) —Select to enable Apple Talk if you have an AppleTalk network Enable AppleTalk connected to the Pi5500. This setting enables the Pi5500 to communicate over AppleTalk networks.
Page 96 3-16 Setting up the Pi5500 from a Windows Computer O CONFIGURE FRAME TYPES • Click the Protocol2 tab in the Network Setup window. The Pi5500 supports these following Ethernet frame types for IPX/SPX: Ethernet 802.2, Ethernet 802.3, Ethernet II, and Ethernet SNAP. For Token Ring, the supported frame types are Token Ring and Token Ring SNAP.
Page 97: Protocol Setup (Ipx Frames)
3-17 Network Setup Protocol Setup (IPX Frames) —Click Auto Select to specify all supported IPX frames, whether or not Auto Select they are supported on your network. To determine the frame types that were successfully bound, save your settings, restart the Pi5500, and print a Conﬁguration page.
Page 98 3-18 Setting up the Pi5500 from a Windows Computer O CONFIGURE ERVER ETUP • Click the Service1 tab in the Network Setup window. You can modify NetWare 3.x (Bindery), and NetWare 4.x or 5.x (NDS) conﬁgurations from Command WorkStation. Select the Enable NDS option if your network uses NetWare 4.x or 5.x in native mode.
Page 99: Pserver Setup (Netware Services)
3-19 Network Setup PServer Setup (NetWare Services) The Enable PServer mode option must be selected if you have a Novell server connected. You can, however, change the PServer polling interval and then modify either Bindery Setup or NDS Conﬁguration. The terms NetWare server, Novell server, and IPX server are in common use and are used here interchangeably to mean the server on an IPX network running Novell NetWare networking software.
Page 100 3-20 Setting up the Pi5500 from a Windows Computer Select User Login 1. Select the User Login object from the display in the Select User Login window. 2. Enter a password, if necessary. 3. Click Next. The Select Print Server window appears. Select Print Server 1.
Page 101: Pserver Setup (Bindery Setup)
3-21 Network Setup PServer Setup (Bindery Setup) Use Bindery Setup if you have already conﬁgured one or more bindery servers (ﬁle servers running NetWare 3.x, or NetWare 4.x or 5.x in bindery emulation) with a Print Server and a Print Queue for Pi5500 jobs (see page 4-7). Before entering bindery settings, be sure the Pi5500 is connected to the network and the NetWare ﬁle server is running.
Page 102 3-22 Setting up the Pi5500 from a Windows Computer , LPD, O CONFIGURE INDOWS PRINTING EB SERVICES • Click the Service2 tab in the Network Setup window. The Service2 tab provides the following: • Windows Printing Service enables the Microsoft SMB protocol, which supports installing printer drivers with Point and Print, and peer-to-peer printing, also known as Windows or SMB printing.
Page 103: Service Setup (Windows Printing Service)
3-23 Network Setup Service Setup (Windows Printing Service) For setting up the Windows printing service, these characters are allowed in the text ﬁelds: uppercase letters, numerals, space, and the following characters: - _ . ~ ! @ # $ % ^ & ( ) { } \ ' , Lowercase letters are not allowed, except in the Comment ﬁeld.
Page 104: Service Setup (Enable Lpd Printing Service)
3-24 Setting up the Pi5500 from a Windows Computer Service Setup (Enable LPD Printing Service) —Select to allow lpd printing. Enable LPD Printing Service Service Setup (Enable Port 9100) —This option allows application programs to open a Enable Port 9100 Print Services TCP/IP socket to the Pi5500 at Port 9100 to download a print job.
Page 105 3-25 Network Setup E-mail Setup —This option allows the Pi5500 to use e-mail as a means of Enable E-mail Services communication for a variety of purposes. The Pi5500 serves as a messenger between the copier and the e-mail recipient —The IP address of the server on your network that handles Incoming Mail Server incoming e-mail.
Page 106 3-26 Setting up the Pi5500 from a Windows Computer —Enter the length of time in seconds that the Pi5500 should try to Timeout (seconds) connect to each e-mail server before determining that the connection is unsuccessful. —Enter the interval in seconds at which the Pi5500 should Polling Interval (seconds) automatically check for new e-mail.
Page 107: Printer Setup
3-27 Printer Setup Printer Setup From this window, you can access two tabs: Printer Setup and Paper Setup. In the following illustration, “Device name” represents the model of the copier connected to the Pi5500, which is 55BW-M O PUBLISH PRINT CONNECTIONS •...
Page 108: Printer Setup
3-28 Setting up the Pi5500 from a Windows Computer Printer Setup —Select to enable users to print (or download) jobs to the Publish Direct Connection Pi5500 without spooling. When the Direct connection is published, users can print jobs to the Direct connection and download and delete printer fonts. Jobs printed to the Direct connection are not available to be reprinted from the Printed queue.
Page 109 3-29 Printer Setup O SET APER OPTIONS • Click the Paper Setup tab in the Printer Setup window. In the following illustration, “Device name” represents the model of the copier connected to the Pi5500, which is 55BW-M...
Page 110: Paper Setup
3-30 Setting up the Pi5500 from a Windows Computer Paper Setup On the Paper Setup tab, you can set most of the same options that appear on the Pi5500 Control Panel for PS Setup. —Specify whether to print on US paper sizes (for example, Letter, Default Paper Sizes Legal, Tabloid), or Metric paper sizes (for example, A4 or A3) by default.
Page 111: Exiting Setup
3-31 Exiting Setup Exiting Setup When you have ﬁnished specifying Setup options, click OK and close the Setup dialog box. You are notiﬁed that the server must be restarted for the new settings to take effect. You are given the choice to restart now or later. If Command WorkStation is running, the connection to the Server is lost and you must log in again when the Server has ﬁnished restarting.
Page 113: Pi5500 On A Netware 5.X Network With Ndps
4-1 Pi5500 on a NetWare 5.x network with NDPS This chapter describes environments that typically include one or more network Chapter 4: servers—Novell NetWare servers and Windows NT 4.0 servers—that will share Setting up printing to the Pi5500. It describes setting up servers that use IPX/SPX or TCP/IP Network Servers protocols for communicating with the Pi5500.
Page 114: Tips For Experts—Netware 5.X Networks
4-2 Setting up Network Servers NDPS is not like the earlier queue-based versions of NetWare printing. Instead, you use an NDPS Manager and a Printer Agent, which control the tasks previously handled by a print queue, print server, and spooler. You can also make the printer driver available for clients to download from Windows 95/98/Me and Windows NT 4.0 computers.
Page 115 4-3 Pi5500 on a NetWare 5.x network with NDPS In Pi5500 Setup, make sure you have enabled TCP/IP (page 2-16) and LPD printing (page 2-21) on the Pi5500. You can ping the Pi5500 (page 4-21) to verify that TCP/IP communication is successful. Setting up the Pi5500 on a NetWare 5.x network Depending on the security needs at your organization, you can set up the Pi5500 as a Public Access printer or a Controlled Access printer.
Page 116: Pi5500 On A Netware 3.X, 4.X, Or 5.X Network
4-4 Setting up Network Servers 6. In the Conﬁgure Novell PDS for Printer Agent dialog box, select “((NONE))”, and click OK. 7. In the Conﬁgure Port Handler dialog box, choose “Remote LPR on IP” as the connection type, and click Next. 8.
Page 117: Tips For Experts—Ipx Networks
4-5 Pi5500 on a NetWare 3.x, 4.x, or 5.x network The Pi5500 can receive print jobs from NetWare clients over Ethernet or Token Ring network topologies. (Appendix A describes the Token Ring option.) During Pi5500 setup, you select the frame type or types that will be used for communication between the Pi5500 and network servers.
Page 118: Overview Of Ipx Printing To The Pi5500
4-6 Setting up Network Servers Overview of IPX printing to the Pi5500 NetWare ﬁle servers support the creation of print queues, which are storage areas for print jobs. When a client on a remote computer decides to print, the job is directed to a print queue on the NetWare ﬁle server and spooled to the NetWare server disk, freeing up the client workstation.
Page 119: Conﬁguring A Netware Server For Printing
4-7 Pi5500 on a NetWare 3.x, 4.x, or 5.x network Conﬁguring a NetWare server for printing The following sections explain how to set up a NetWare ﬁle server so that networked users can print to the Pi5500 from their workstations, and the Pi5500 can obtain print jobs from the NetWare server.
Page 120 4-8 Setting up Network Servers Conﬁguring an NDS connection Abbreviations: FS = ﬁle server PS = print server PQ = print queue (on the NetWare server) On Pi5500 On NDS FS On client workstation Control Panel In NETADMIN: Port Setup Install user software Create NDS PQs Ethernet Setup or Token Ring...
Page 121: Setting The Netware 4.X Bindery Context
4-9 Pi5500 on a NetWare 3.x, 4.x, or 5.x network Setting up an NDS connection In NDS, all NetWare entities (objects) are organized in a hierarchical tree structure. Objects have a name, properties, and a context that deﬁnes the location of the object in the directory tree.
Page 122 4-10 Setting up Network Servers Setting up a Pi5500 print queue for bindery For NetWare 3.x and NetWare 4.x in emulation mode, the NetWare print server and print queue for Pi5500 are created and conﬁgured from NetWare Print Console (PCONSOLE), a NetWare utility that is stored in NetWare’s PUBLIC directory. As with NDS, ﬁrst you create several NetWare entities on a Novell server, then you select them in Network Setup on the Pi5500 Control Panel.
Page 123: Pi5500 On A Tcp/Ip Network With Windows Nt 4.0
4-11 Pi5500 on a TCP/IP network with Windows NT 4.0 Pi5500 on a TCP/IP network with Windows NT 4.0 When a Windows NT 4.0 computer is conﬁgured to connect to the Pi5500 using TCP/IP, it can print directly to the Pi5500. If the computer shares the printer over the network, it is acting as a print server to Windows NT 4.0 clients.
Page 124: Conﬁguring A Windows Nt 4.0 Server To Support The Pi5500
4-12 Setting up Network Servers Conﬁguring a Windows NT 4.0 server to support the Pi5500 To conﬁgure a Windows NT 4.0 server to communicate with the Pi5500, follow these general steps. More detail is provided in subsequent sections. • Load the TCP/IP network protocol on the server and conﬁgure it with an IP address, subnet mask, and gateway.
Page 125 4-13 Pi5500 on a TCP/IP network with Windows NT 4.0 Adding the Pi5500 to the TCP/IP network If your TCP/IP network consists of Windows NT 4.0 servers and Windows NT 4.0 clients, use the directions in this section. If the network includes UNIX workstations, also check the directions on page 4-19.
Page 126 4-14 Setting up Network Servers Installing the Pi5500 as a shared PostScript printer The ﬁrst step in creating a printer is installing the Windows NT PostScript printer driver and the Pi5500 PostScript printer description file (PPD), which gives your applications access to some printer features. The installation instructions in Getting Started can be used for every workstation that will print directly and independently to the Pi5500.
Page 127 4-15 Pi5500 on a TCP/IP network with Windows NT 4.0 Conﬁguring clients of a Windows NT 4.0 server Each client of a Windows NT 4.0 server is already using a network protocol to communicate with the server. Each client can print to the Pi5500 if it has been shared by a Windows NT 4.0 Server or Windows NT 4.0 Workstation computer.
Page 128: Conﬁguring The Pi5500 And Clients For Fiery Webtools
4-16 Setting up Network Servers Conﬁguring the Pi5500 and clients for Fiery WebTools The Fiery WebTools offer access to many Pi5500 functions via the Internet (or your company’s intranet), providing additional ﬂexibility in remote management. You can access Fiery WebTools from a Mac OS or Windows computer. Fiery WebSetup is supported on Windows computers only.
Page 129 4-17 Conﬁguring the Pi5500 and clients for Fiery WebTools O SET UP IERY OOLS ON A COMPUTER 1. Enable TCP/IP networking. 2. Assign the workstation has a valid, unique IP address, and then set the subnet mask. Set a gateway address, if necessary. 3.
Page 130: Setting The Weblink Destination
4-18 Setting up Network Servers Setting the WebLink destination The pre-set WebLink destination can be changed; this function requires the Administrator password if one has been set. O CHANGE THE INK DESTINATION 1. Start your Internet browser. 2. Enter the IP address or the DNS name of the Pi5500. The Pi5500 home page appears.
Page 131: Pi5500 On A Network With Unix Workstations
4-19 Pi5500 on a network with UNIX workstations Pi5500 on a network with UNIX workstations When a UNIX workstation is conﬁgured with the lpd protocol and connected to the Pi5500 over a TCP/IP network, it can print directly to the Pi5500. Setting up UNIX workstations requires an administrator with root privileges.
Page 132: Important Note About The Remote Printer Name
4-20 Setting up Network Servers Important note about the remote printer name Whichever UNIX system you use, the name used for remote printer (or in the /etc/printcap ﬁle) in conﬁguring the Pi5500 must be one of the following print hold The remote printer or name is also used when setting up your Windows NT 4.0 workstation or server to connect to the Pi5500 over TCP/IP.
Page 133 4-21 Pi5500 on a network with UNIX workstations 5500 UNIX O SET UP PRINTING ON SYSTEMS 1. Specify the appropriate settings in Pi5500 Server Setup. To access Pi5500 Setup, see page 2-1. 2. Specify the appropriate settings in Pi5500 Network Setup. Run the setups listed in the table on page 2-10 and enter a valid IP address, subnet mask, and gateway address for the Pi5500.
Page 134 4-22 Setting up Network Servers 5500 O PRINT TO THE • On a UNIX system running SunOS 4 or other BSD-based variant, use the lpr command to send a job to the Pi5500. • On a UNIX system running Solaris 2 or any System V implementation of UNIX, use the lp command to send a job to the Pi5500.
Page 135: Administrator Functions
5-1 Administrator functions This chapter gives tips on managing Pi5500 printing, and includes some Chapter 5: troubleshooting hints. Administering the Pi5500 Administrator functions Administration features are provided in the user software package and are built into the Pi5500 itself. The following table tells you where to ﬁnd information on these features. Page references refer to this manual.
Page 136: Maintaining Optimal Performance
5-2 Administering the Pi5500 For these operations And these tasks Controlling the job ﬂow Using the Fiery utilities for managing job priorities, tracking Job Management Guide current jobs, canceling jobs, printing jobs in the Hold queue, reprinting from the Printed or Hold queue Job accounting Viewing, printing, and exporting the Job Log, user notes Job Management Guide...
Page 137 5-3 Maintaining optimal performance • Leave some jobs that are less urgent to times when there is less network trafﬁc or printing Recurring print jobs or jobs that are not urgent can be printed to the Hold queue. At low-trafﬁc times, the administrator can move (or copy) all the Hold queue jobs to the Print queue for printing.
Page 138: Troubleshooting
5-4 Administering the Pi5500 Troubleshooting Startup diagnostics are described in the Installation and Service Guide, which is the documentation for service technicians. Contact your authorized service/support center if you see any startup error messages on the Pi5500 Control Panel, or if the Pi5500 does not reach Idle status.
Page 139 5-5 Troubleshooting After this Setup screen This message Means Select NDS Tree Warning! Selecting a new NDS You have previously connected the Pi5500 to a different tree deletes Bindery setup. NDS tree. NetWise supports only a single NDS tree (Network Setup> connection.
Page 140 5-6 Administering the Pi5500 After this Setup screen This message Means View Server List>Edit No file server is selected. No ﬁle server has been added in Bindery Setup. Connection (Network Setup> Service Setup> PServer Setup>Bindery Setup) Add File Server All connections used. You have added the maximum number of bindery servers, Remove server? which is eight.
Page 141 5-7 Troubleshooting In Network Setup, when you are conﬁguring your IPX (Novell) connection, the Pi5500 queries the network for Novell ﬁle servers and print servers, and attaches to them temporarily. If a guest login is enabled, it will be used. If not, you are prompted to log in from the Pi5500 Control Panel.
Page 142 5-8 Administering the Pi5500 Novell error screens Novell error Cause Suggested action or exit The guest account, which you have chosen for Enable a guest account on the NetWare server initial login, has expired or has been disabled by for the purpose of setup. Guest account not the NetWare supervisor.
Page 143: Runtime Error Messages
5-9 Troubleshooting Novell error Cause Suggested action or exit Indicates other network errors when the Notify the Novell administrator and report the Pi5500 is already connected to a ﬁle server. error number. Notify IPX (Novell) Something unexpected has happened and the Administrator.
Page 144 5-10 Administering the Pi5500 Printer not found—TCP/IP or IPX networks Most failures to ﬁnd a printer on the network are due to conﬂicting or missing name or address settings for the Pi5500. You must enter particular names in certain places. The required names are: •...
Page 145 5-11 Troubleshooting Refer to the following table for the appropriate name. IPX/SPX TCP/IP In this location For this item networks networks Server Setup on Pi5500 Control Server Name option Deﬁned by Deﬁned by page 2-7 Panel administrator administrator Windows NT hosts ﬁle host name —...
Page 146 5-12 Administering the Pi5500 Cannot connect to Pi5500 with Fiery utilities If clients cannot connect to the Pi5500 with Fiery utilities, check the following: • Pi5500 Setup—the appropriate network protocol must be enabled, with the correct parameters (for example, for TCP/IP, the IP address), and you must have published the Print queue.
Page 147: Pi5500 Token Ring Option
A-1 Token Ring Network Option Token Ring is an alternative network architecture to Ethernet architecture. Token Ring Appendix A: networks offer a high resistance to failure and are commonly used in large or Token Ring high-trafﬁc network installations. Network Option Token Ring networks operate by passing a network token around the electronic equivalent of a ring.
Page 148 A-2 Token Ring Network Option Back view of the Pi5500 with the Token Ring option installed Connectors for Token Ring option Turn off the Pi5500 before connecting it to any network device. Do not attach cable to both Token Ring connectors. 5500 O CONNECT CABLE TO THE 1.
Page 149: Ipx/Spx Installations
A-3 Token Ring Network Option IPX/SPX installations If your network uses IPX/SPX protocols with Token Ring, conﬁgure at least one printer, one Pi5500 Print Server, and one Pi5500 Print Queue on the NetWare server as described in “Conﬁguring a NetWare server for printing” on page 4-7. You can conﬁgure up to eight bindery servers and one NDS tree connection to the Pi5500.
Page 151 Index Numerics Auto Clear Job Log Every 55 Jobs option 2-47, 3-6 100BaseT connector 1-12 Auto Print Job Log Every 55 Jobs 10BaseT connector 1-12 option 2-47, 3-6 accessing Setup 2-3 to 2-4, 2-7 binary data, printing via parallel from Windows computer 3-1 port 2-13, 3-10 Account Name option, E-mail Setup 2-37 Bindery...
Page 152 I-2 Index choosing a Bindery Server to Convert Paper Sizes option 2-43, 3-30 connect 2-28, 3-21 copier interface cable 1-11 Clear Each Scan Job option 2-9 Courier font, substitution with 2-43, 3-30 Clear Frame Types, IPX/SPX Setup 2-20 cover page, printing at end of job 2-43, 3-30 Clear Server 2-46, 2-49 clearing date, setting 2-7, 3-4...
Page 153 I-3 Index Enable Port 9100 Print Services option 3-24 Ethernet Setup Enable Printed Queue option 2-8, 3-4 Ethernet Speed 2-12 Enable PServer option 2-22 Port Setup 2-12, 3-9 Enable Source Routing option 2-12, 3-10 Protocol Setup 2-16, 3-12 Enable TCP/IP for Ethernet Ethernet Speed option 2-12, 3-9 option 2-16, 3-12 Exit Bindery Setup 2-27, 2-31...
Page 154 I-4 Index IPX/SPX Setup 2-19 selecting frame types 2-20 Hold queue 2-40, 2-41, 3-28 summary 2-10 host name 4-11, 4-12, 4-13, 4-21 http protocol 3-22 Job Log clearing 2-46, 2-49 Ignore EOF Character option 2-13, 3-10 clearing automatically 2-47 improving server performance 5-2 default options 2-47 Incoming Server option, E-mail printing automatically 2-47...
Page 155 I-5 Index Microsoft SMB protocol 3-22 NetWare Print Console 4-10 multiple Bindery servers, connecting 2-27 NetWare Print Server poll interval 2-32 NetWare Print Server, Bindery 2-29 changing the selection 2-27, 2-30 naming the server 2-7, 3-3, 5-10 connecting 2-29, 2-30 NDPS (Novell Distributed Print editing your choice 2-30 Services) 4-1...
Page 156 I-6 Index parallel port preferences for the Job Log 2-47 cable (Centronics-type) 1-13 print connections 2-39 connecting 1-13 Print Cover Page option 2-43, 3-30 diagram 1-10 Print queue 2-8, 2-40, 2-41 end-of-ﬁle setting 2-13 print queues Setup 2-13 Bindery, selecting in Network summary of Setup 2-10 Setup 2-28 timeout setting 2-13...
Page 157 I-7 Index PS (PostScript) Setup 2-42, 3-30 PServer Setup 2-21, 3-18 Save Changes PServer, deﬁned 2-21 Job Log Setup 2-48 Publish Direct Connection Network Setup 2-11, 2-38 option 2-41, 3-28 PCL Setup 2-45 Publish Hold Queue option 2-41, 3-28 Printer Setup 2-42 Publish Print Queue option 2-41, 3-28 PS Setup 2-43 publishing...
Page 158 I-8 Index Service Setup TCP/IP Setup conﬁguring 3-22 for Ethernet 2-16 from Control Panel 2-21 for Token Ring 2-18 Setup 2-2 to 2-49 summary 2-10 accessing 2-3 to 2-4, 2-7 TCP/IP with Ethernet, frame type 2-20 administrative functions 2-46 TCP/IP with Token Ring, frame type 2-20 Control Panel menu 2-4 terminology, Novell 2-26, 3-19 Network Setup 2-9...
Page 159 I-9 Index View Server List option, Bindery Setup 2-27, 2-30 viewing list of connected Bindery servers 2-30 Web Services Setup 2-34, 3-22, 3-24 WebLink, setting destination address 4-18 WebSpooler 2-8, 2-39, 2-40, 2-47 WebTools 4-16 to 4-18 enabling 2-16, 2-18, 2-34 Windows (SMB) printing xiv Windows NT network environment 1-7...
