Page 2: Trademark Acknowledgments
Trademark Acknowledgments PageWorks is a trademark of Minolta in the U.S.A. and Canada. Minolta is a registered trademark of Minolta Co., Ltd. Macintosh is a registered trademarks of Apple Computer Inc. MS-DOS, Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and/or other countries. All other products or name brands are trademarks or registered trademarks of their respective holders. -
Page 3: Customer Support
Hard Disk Drive. Before reading this Hard Disk Drive Set-up Guide, we recommend that you read the User’s Manual for PageWorks 20. It explains how to set up and operate the printer. No part of this document may be reproduced, transmitted, tran-... - Page 4 Foreword Hard Disk Drive Warranty Warranty Term The Hard Disk Drive has a (1) One Year Warranty. The Hard Disk Drive must be returned to Minolta for repair or replacement at Minolta’s discretion. Warranty Coverage Minolta Corporation warrants this product to be free from defects in workmanship and materials for a period of one year from the date of receipt of the unit.
-
Page 5: Table Of Contents
HardWare Set-Up Setting Up ... 1 Formatting the Hard Disk Drive Formatting via Windows OS... 7 Formatting via Macintosh OS ... 10 Downloading Fonts Windows... 11 Macintosh ... 11 CONTENTS Contents... - Page 6 Memo...
-
Page 7: Hardware Set-Up
CAUTION • Before opening and handling the Hard Disk Drive, touch a metal part of the printer to avoid an electrostatic charge. • When the Hard Disk Drive is taken out of the conductive bag or off the mat, hold it by its edges to avoid touching the terminals or the patterned surfaces. - Page 8 Hardware Set-Up 2. Pressing the upper cover lock release button, open the upper unit. 3. Loosen two screws to remove the right side cover. (Use a plus screwdriver.) 4. Remove the right side cover. 5. Remove four screws. (Use a plus screwdriver.)
- Page 9 Hardware Set-Up 6. Open the metal cover. 7. Attach the Hard Disk Drive and tighten four screws. (Use a plus screwdriver.) 8. Connect the Hard Disk Drive cable to the Hard Disk Drive connector on the controller board. Hard Disk Drive connector PS-DIMM socket SIMM slot 1 SIMM slot 2...
- Page 10 Attach the right side cover. Tighten two screws. 11. Close the upper cover. 12. Connect the power cord to the printer and then turn the printer on. The printer is ready to print approxi- mately 70 seconds after the power switch is turned on.
- Page 11 15. Press the Menu key as many times as TEST PRINT 16. Press the Item key once to select the CONFIG PRINT Hardware Set-Up on the message display and the On Line indicator is lit. the printer off-line. necessary to select the Test Print. Config Print.
-
Page 12: Installed Options
PostScript ROM Hard Disk Add SIMM Memory (MB) 17. Press the Enter key to start printing the Config Print sheet. The printer returns on-line automatically. 18. Make sure that under Installed Options the Hard Disk is “Installed”. = Not Installed... -
Page 13: Formatting The Hard Disk Drive
Formatting via Windows OS NOTES • Make sure that the printer is connected to your computer with the recommended parallel cable. • Make sure that “PS” is shown in the message display on the printer’s control panel. If not, be sure to change the Language in the System Menu to “PS”. - Page 14 Make sure that “READY” is shown on the message display and the On Line indicator is lit. Press the On Line key once to take the printer off-line. Press the Menu key as many times as necessary to select the Test Print.
-
Page 15: Formatting Hard Disk
Press the Item key 5 times to select the PS Font List item. Press the Enter key to start printing. The printer returns on-line automatically. Make sure that there are no fonts in the Hard Disk Downloaded Fonts list. MINOLTA PageWorks 20... -
Page 16: Formatting Via Macintosh Os
Formatting the Hard Disk Drive Formatting via Macintosh OS Format the Hard Disk Drive using the utilities included in any Font package available on the market. For details, see the user’s guide for the utilities. Example of utilities: Apple LaserWriter Utility, Adobe Font Downloader and so on. Print out the PS Font List to see whether the Hard Disk Drive has been formatted correctly. -
Page 17: Downloading Fonts
Downloading Fonts Windows Use the utilities included in any Font package available on the market. For details, see the user’s guide for the utilities. Example of utilities: Adobe Font Downloader and so on. Macintosh Use the utilities included in any Font package available on the market. For details, see the user’s guide for the utilities. - Page 18 Memo...
