- Page 1 Quick Start Guide STEVAL-BCN002V1B - BlueTile kit www.st.com/bluetile...
-
Page 2: What Do You Want To Do
What do you want to do? Unpack and run Start designing the default demo your application Go to page 8 Go to page 10 ST BLE Sensor www.st.com/bluetile... - Page 3 Step 2 Step 3 Discover, connect and see the To power the system, slide Download and run the ST BLE Sensor data in real time; swipe for more the battery inside the holder. app from the iOS or Android store ST BLE Sensor www.st.com/bluems...
- Page 4 Run the preloaded Demo ST BLE Sensor www.st.com/bluetile References for libraries embedded in the demo • UM2220 Getting started with MotionFX sensor fusion library • UM2382 / UM2196 Getting started with BlueVoice full/single duplex Environmental Inertial sensor and Accelerometer LED control...
- Page 5 Start designing your application Software setup Hardware setup SDK & IDE Flash & Debug Go to page 11 Go to page 12 Flash only Flash & Debug using the host board using the host board and ST-Link on a Nucleo...
- Page 6 BLE_Beacon to advertise programmable data • BLE_HID_Peripheral to emulate a wireless keyboard or mouse • BLE_SensorDemo to stream sensor data to the reference app ST BLE Sensor • DTM to enable BlueNRG-2 control in real-time using STSW-BNRGUI software tool BLE_SensorDemo is the default...
- Page 7 Remove the battery and plug the BlueNRG-Tile on its Step 1 host board, move switch SW2 and SW3 in position 2-3 host board, plug the host board on any Nucleo ST-Link 10 pin SWD/UART connector 5 pin SWD connector Remove...
- Page 8 Connect the USB of the host board to the laptop Connect the USB of the host board to the laptop, also Step 1 connect the USB of the Nucleo ST-Link to the laptop Download and install STSW-STM32102 Flash & Debug using supported IDEs (IAR, Keil, Atollic...
- Page 9 If BlueNRG-2 is in deep sleep • It is not possible to Flash & Debug with STSW-BNRG1STLINK: the SWD interface is shut down and the ST-Link will not detect BlueNRG-2 • Use STSW-BNRGFLASHER to Flash then Debug with supported IDEs •...
- Page 10 More information...
- Page 11 (STEVAL-BCN002V1D) is also provided as part of the kit; it features: • a USB connector to Flash, • SWD connectors for debugging with external ST-LINK or a NUCLEO ST-LINK or an ST-LINK Stamp V3 module (when soldered on-board) FCC ID S9NSTEBCN2V1...
- Page 12 FCC ID S9NSTEBCN2V1 IC ID 8976C-STEBCN2V1 BlueTile- STEVAL-BCN002V1 32kHz crystal -network SMD antenna BALF-NRG-02D3 To enable lowest power (not populated) Integrated balun and matching BLE sleep mode network RFTEST Cortex-M0 32 MHz Inductor BlueNRG-2 256 kB Flash 24 kB RAM Up to +8dB, 96 dB link budget To enable lowest power Bluetooth 5.0 network and...
-
Page 13: Block Diagram
BlueTile- STEVAL-BCN002V1 block diagram Test points Integrated The integrated SMD antenna needs clearance area and passives for proper tuning (FT1 FT2 and MT). antenna RFTEST TEST SDA SCL VDD GND The -network is included only for flexibility and to -network RFTEST facilitate testing. - Page 14 BlueTile host board - STEVAL-BCN002V1D 20 pin JTAG/SWD BCN002V1 for ext. ST-Link V2 BCN002V1D BlueTile (not connected in BlueTile host board this picture) Nucleo (can be detached) STM32L151 USB of ST-LINK Stamp V3 (also power source for target microcontroller) 5 pin JTAG/SWD for...
- Page 15 VDD connector SW2 for UART RX Stamp SW3 for UART TX to BOOT RESET Force user button to RESET to GND 1-2 for ST-Link V3 2-3 for STM32L1 Blue UART UART USBLC6-2P6 10 pin ESD protection connector STM32L151 Tile...
- Page 16 Blue ST Link Tile Nucleo Stamp V3 ST Link STSW-BNRG1STLINK (or any supported IDE) ST-Link Stamp V3, Nucleo ST-Link, ST-Link V2 will not detect BlueNRG-2 if it is in deep sleep. Host board Plug to ST Link Blue power Tile...
- Page 17 Thanks...
