Advanced Bionics Marvel CI Quick Reference Manual

Marvel CI sound processors (Naída CI M90, Naída CI M30 and Sky CI M90) offer your patients a powerful hearing experience with
excellent sound quality in a variety of situations and comes with built-in connectivity solutions. This guide provides the basic information
needed to get started with the fitting, maintenance and troubleshooting.
COMPATIBILITY
Marvel CI sound processors are programmed in the Advanced Bionics Target CI fitting software and are compatible with the following
implant type: HiRes Ultra 3D, HiRes Ultra, HiRes 90K Advantage, HiRes 90K and CII.
PRODUCT HIGHLIGHTS
• AutoSense OS™ 3.0 operating system automatically senses the surroundings and adjusts the signal processing to provide optimum
clarity and comfort in different listening situations.
• Integrated Bluetooth®
1 and RogerDirect technology
Recipients can stay connected with loved ones with truly hands-free phone calls.
• Unique ergonomic processor and headpiece design
discreet, comfortable, and secure fit.
• M Waterproof Battery ideal for swimming and outdoor activities.
COMPONENTS
M T-Mic™ microphone with cover
1.
Sound processor
2.
Front microphone
3.
Multi-function button with status LED
4.
5. Back microphone
6. M Battery
Slim HP with integrated cable
7.
To turn the sound processor either on or off, simply attach or remove the battery.
Multi-function Button
The multi-function button is programmable in Target CI and can be customized to
meet the needs of each recipient. For example, it can be disabled completely for
pediatric use, or set as a volume and/or program control.
Listening Need
Standard listening
During Audio Streaming
During Phone Calls
Remote Control Options
For convenient and discreet device management, the AB Remote app or Phonak RemoteControl allows the recipient to make program
and volume adjustments effortlessly. The AB Remote app also helps to perform a simple device check.
1. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sonova AG is under license.
2. Pressing the button up or down has the same function.
3. When the multi-function button is used to change programs, whether pressing the top or the bottom part of the rocker, the programs toggle forward. To go backwards, please use the AB Remote app
or toggle through the sequence.
allow recipients to stream audio and media wirelessly from their favorite devices.
for a
Short Press (< 2 seconds)
Volume up or down
Streaming volume up or down
Accept phone call (while ringing) or phone
call volume up or down (during call)
Marvel CI
QUICK REFERENCE GUIDE
Long Press (> 2 seconds
Program change 3
Program change
Reject phone call (while ringing) or end phone
call (during call)
)
2
