E. ELECTRIC HEAT OPERATION (if equipped with heat strip or heat pump)
Electric Heat symbol
1. Select electric heat by pressing the "MODE" button until the heat symbol is
displayed.
2. Set temperature to the desired level by pushing the up (+) or down (-) button.
3. In electric heat mode, if the electric heat appliance is unable to satisfy the
setpoint, the gas heat output is energized with the AUX HEAT red LED on at
5°F below setpoint. Both gas heat and electric heat appliances will run
simultaneously until the setpoint is satisfied for auxiliary heat.
F.

SLEEP OPERATION

Sleep symbol
1. In order for the sleep mode to function properly, you must select either a heat
or cool mode of operation.
2. With the room set to a desired temperature, select the sleep mode by pointing
to the receiver and pressing the "SLEEP" button, the sleep symbol will
display and a beep will sound indicating that the unit is in sleep mode.
(Note: In sleep mode the temperature will be offset by 2°F of set point after a
2 hour delay, which means, if the set point was 75°F at ten o'clock (for
cooling operation) then in sleep mode it will automatically change to 77°F at
twelve o'clock.)
G.

FAN ONLY OPERATION

Fan symbol
1. Fan only operation is selected by pressing the "MODE" button until the fan
symbol is displayed.
2. Fan high or low speeds are then selected by pressing the fan button located
above the "MODE" button. Fan will run continually at the selected speed; it is
not controlled by the set point.
7
