Airxcel Aqua-Hot GEN1 Series Use And Care Manual
Hide thumbs
Also See for Aqua-Hot GEN1 Series:
- Installation manual (140 pages) ,
- User manual (124 pages) ,
- Use and care manual (24 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Airxcel Aqua-Hot GEN1 Series
Summary of Contents for Airxcel Aqua-Hot GEN1 Series
- Page 1 Use and Care Guide GEN1 Series GEN-1 DIESEL...
- Page 2 Journey in Comfort Thank you for equipping your RV, coach, or caravan with an Aqua-Hot hydronic heating system! We deeply value your business and we are grateful for the trust you have placed with Aqua-Hot Heating Systems, LLC. Our customers are our top priority and we are committed to providing best-in-class products, service, and support.
-
Page 3: Table Of Contents
Introduction Contents Caution Notes As you read this information, take particular note of the NOTICE, Caution Notes ............2 CAUTION, WARNING, and DANGER symbols when they appear. Safety Features ............3 This information is important for safe and efficient use of the Aqua-Hot system. -
Page 4: Safety Features
Safety Instructions System Overview Read and understand all instructions before using the Aqua- Hot system. Aqua-Hot Heating Systems is not liable for damage resulting from failing to follow instructions contained in this, The Aqua-Hot Gen-1 Heater is a Heating System that can and any other Aqua-Hot documentation relevant to this unit. - Page 5 Safety Instructions Safe Operation Intended Use Intended Use The Aqua-Hot Heating system consists of an electric This manual explains the operation and care of the Aqua-Hot This manual explains the operation and care of the Aqua-Hot heating element and a diesel burner. The heater with heating system.
-
Page 6: Component Callouts
Component Callouts Aqua-Hot GEN-1 Heater 1. Heater 2. Air Intake Inlet 3. Exhaust Outlet 4. Controller Cover 5. Plastic Frame Feet 6. Aluminum Frame Feet Circulated Air Intake 8. Cold Water Connection (Inlet) 9. Diesel Fuel Connection 10. Hot Water Connection (Outlet) 11. -
Page 7: System Features
Aqua-Hot System Features System Features The Aqua-Hot Gen-1 Heater is a Heating System that can provide interior heat and hot water using a built-in electric heating element and a diesel burner. The heater can be used while driving. For full details and installation requirements, please see installation and owners manuals. -
Page 8: Operational Overview
Activating the Aqua-Hot Operational Overview Operational Overview The heating features are powered by the DC diesel burner and/ or the AC electric element. These maintain the temperature of the Aqua-Hot’s tank to provide supplementary hot water and interior heat. Diesel Burner & Electric: The diesel burner is the Aqua-Hot’s primary and most powerful heat source. -
Page 9: Operating The Lcd
Activating the Aqua-Hot Operating the LCD Operating the LCD Power ON: Hold the rotary button for 3seconds to turn on LCD. After a few seconds, the time is displayed as 00:00. Click the rotary button to display the initial options in the display. Clock setting (current time setting) •... - Page 10 Activating the Aqua-Hot Operating the LCD Shutdown Press the rotary button for more than 3s at the initial interface to shut down. When the LCD switch is turned off, the heating process and any connected equipment are also automatically turned off. The parameters before shutdown are retained. Adjustment of Interior Temperature •...
- Page 11 Activating the Aqua-Hot Operating the LCD .This icon will flash until the predetermined water Heating Start temperature is reached. After the setting is finished, press the return key or wait for 10s to enter the clock interface, and the heating starts. The clock In the "heating and hot water mode", the water temperature and set temperature are displayed alternately.
- Page 12 Activating the Aqua-Hot Operating the LCD Enter the End Time Select Fan Speed Level • Use the rotary button to set the end time. • Use the rotary button to set the desired fan speed • Click the rotary button to confirm and proceed to the next •...
- Page 13 Activating the Aqua-Hot Operating the LCD Voltage Inquiry Switching Temperature Units • Click the rotation button to display the voltage: 12.0V. Use the knob to switch between Celsius and Fahrenheit, then click to confirm Air Pressure and Temperature Inquiry • Click the rotation button to select the at ATMOS icon.
- Page 14 Activating the Aqua-Hot Operating the LCD Fast Pump Settings Select pump oil icon GoOil with rotary button. • Click on the rotary button to enter the fast pump oil. The default fast pump time is 90 seconds. The remaining time can be adjusted with a knob.
-
Page 15: Aqua-Hot Layout
Activating the Aqua-Hot Aqua-Hot Layout NOTE: The illustrations below are just samples for the layout of the Aqua-Hot heating system. Actual placement may vary on the individual design of the RV. For questions or assistance, contact us at 574-AIR-XCEL (574-247-9235) . Heater Installation Layout (RV) 1. -
Page 16: Maintenance & Storage
Maintenance Maintenance & Storage It is recommended to have the following service done once a year: • Replace the fuel filter DO NOT operate the diesel burner and/or electric • Check the air ducting, air intake and exhaust outlet for heating element in an enclosed space such as a blockages or damage garage, shop, or while refueling. -
Page 17: Winterizing The Aqua-Hot
Winterization Winterization Disinfecting the Domestic Water System To avoid freeze damage to the system, the heater must be drained through the drain valve completely. If water is left in the system in below freezing temperatures, it can cause severe damage to the system that is not covered under warranty. The Aqua-Hot Heating components are not compatible to •... -
Page 18: General Troubleshooting
General Troubleshooting Use and Operation Troubleshooting • Ensure that the system is supplied with electrical power and there are no blown fuses. • Ensure that there is at least ¼ tank of fuel in the vehicle fuel supply and the fuel filter is not clogged. •... -
Page 19: Owner's Service Log
Service Log DATE SERVICE PERFORMED SERVICE CENTER p. 18 ©Aqua-Hot® GEN1 Diesel Use and Care Guide REV 230313... - Page 20 Service Log DATE SERVICE PERFORMED SERVICE CENTER p. 19 ©Aqua-Hot® GEN1 Diesel Use and Care Guide REV 230313...
-
Page 21: Warranty
Warranty 2-YEAR LIMITED WARRANTY AQUA-HOT® HEATING SYSTEM Aqua-Hot Heating Systems Inc. warrants the Aqua-Hot Heater to be free from defects in material and workmanship under normal use and service for a period of two years on both parts and labor commencing upon the original date of registration of the vehicle. Replacement parts are warranted for the remainder of the Heater’s standard warranty coverage or for six months, whichever is greater. - Page 22 Operation Manual GEN1 SERIES GEN-1 DIESEL Aqua-Hot Heating Systems, LLC 7501 Miller Drive, Frederick, CO 80504 Visit us online at www.aquahot.com Call us at 574-AIR-XCEL (574-247-9235) ©2023 Aqua-Hot Heating Systems, LLC. Printed in the USA...
