Summary of Contents for Airxcel RVP INFRARED REMOTE CONTROL SYSTEM
- Page 1 OPERATING INSTRUCTIONS INFRARED REMOTE CONTROL SYSTEM DESIGNED BY THE MAKERS OF THE MACH® AIR CONDITIONERS...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Warnings………………………………………………………………….. 3 General Information………………………………………………………. 3 Handheld Remote…………………………………………………………. 4 Cooling Operation………………………………………………………… 5 Gas Heat Operation……………………………………………………….. 6 Dry-Air Operation………………………………………………………… 6 Auto Change Over Operation…………………………………………….. 6 Electric Heat Operation…………………………………………………… 7 Sleep Operation…………………………………………………………… 7 Fan Only Operation……………………………………………………….. 7 “I Feel” Operation………………………………………………………… 8 Timer Operation…………………………………………………………... -
Page 3: Warnings
WARNINGS IMPORTANT NOTICE This system must be installed or serviced The use of components not tested in by qualified individuals specially trained combination with these units will void the and experienced in installation and service warranty, may make the equipment in of this type of equipment and related violation of state codes, may create a system components. -
Page 4: Handheld Remote
HANDHELD REMOTE Note: 1. All communications between the remote and receiver are validated only when you hear a beep coming from the receiver. 2. The operation of the unit is updated when the unit is “on” and you hear a beep coming from the receiver. -
Page 5: Cooling Operation
COOLING OPERATION Cool symbol Using the handheld remote, select the cool symbol by pressing the “MODE” button until the cool symbol is displayed. Select a fan speed that best satisfies your need by pressing the fan button located above the “MODE” button: High speed - Continuous high fan speed operation - Selected when maximum cooling is required. -
Page 6: Gas Heat Operation
GAS HEAT OPERATION (If gas heat appliance is connected to upper unit) Gas Heat symbol Select gas heat by pressing the “MODE” button until the gas heat symbol is displayed. Set temperature to the desired level by pushing the up(+) or down(-) button. DRY-AIR OPERATION Dry-air symbol Select the dry-air mode by pressing the “MODE”... -
Page 7: Electric Heat Operation
ELECTRIC HEAT OPERATION (if equipped with heat strip or heat pump) Electric Heat symbol Select electric heat by pressing the “MODE” button until the heat symbol is displayed. Set temperature to the desired level by pushing the up (+) or down (-) button. In electric heat mode, if the electric heat appliance is unable to satisfy the setpoint, the gas heat output is energized with the AUX HEAT red LED on at 5°F below setpoint. -
Page 8: I Feel" Operation
"I FEEL” OPERATION "I FEEL" symbol For this mode to operate, the system would have to be selected for electric heat, cool, gas heat or auto change over. Select the "I FEEL" mode by pressing "I FEEL" button, the "I FEEL" symbol will display, a beep will indicate that the unit is in "I FEEL"... - Page 9 Setting the clock When new batteries are installed, the clock will display 0:00 This clock displays military/aviation time (24 hour format) only. See page 12 for a table to convert 24 hour to 12 hour format. Press the “CLOCK” button, the clock "display" should blink, press the up or down button to set the clock e.g.
-
Page 10: Room Temperature Display
ROOM TEMPERATURE DISPLAY Room Symbol ROOM Press the "ROOM" button to display room temperature at the remote. F° /C° DISPLAY F°/C° Press the “F°/C°” button to display temperature in either degrees Fahrenheit or Celsius. RECEIVER UNIT COOL SYSTEM OVERRIDE HEAT AUX.HEAT 1. - Page 11 2. Heat override operation (Note: With gas heat appliance connected to the upper unit) a) By pressing the “HEAT” button on the receiver, the system automatically defaults to the "heat" setting of 68°F and the AUX. HEAT red LED will flash.
-
Page 12: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE TROUBLESHOOTING Symptom Remedy Remote does not turn on system Check and replace remote batteries if the display fades while any button is activated or no display is present. Point remote towards IR receiver during transmission. system does not turn on, no green LED & no beep Check wiring. - Page 14 RV Products A Division of Airxcel, Inc. P.O. Box 4020 Wichita, KS 67204 Web: www.rvcomfort.com Support: rvpsupport@airxcel.com Sales: rvpsales@airxcel.com 1976-405(2-05)
