Room Temperature Display; F°/C° Display; Receiver Unit - Airxcel RVP INFRARED REMOTE CONTROL SYSTEM Operating Instructions Manual

J.

ROOM TEMPERATURE DISPLAY

Room Symbol
ROOM
Press the "ROOM" button to display room temperature at the remote.
K. F° /C° DISPLAY
F°/C°
Press the "F°/C°" button to display temperature in either degrees Fahrenheit or
Celsius.
1. Cool override operation
a) By pressing the "COOL" button on the receiver, the system automatically
defaults to the "cool" setting of 78°F and the SYSTEM green LED will
flash.
b) This mode of operation is useful in the event the remote battery goes low
or the remote is misplaced.
c) Pressing the "COOL" button a second time will turn the unit off and the
SYSTEM green LED will turn off.

RECEIVER UNIT

COOL
OVERRIDE
HEAT
10
SYSTEM
AUX.HEAT
