User's Guide
AM243x LaunchPad™ Development Kit User's Guide
The AM243x LaunchPad
the Texas Intruments Sitara
start developing on the AM243x MCUs with on-board emulation for programming and debugging as well as
buttons and LEDs for a simple user interface. The LaunchPad also features two independent BoosterPack XL
expansion connectors, on-board Controller Area Network (CAN) transciever, two RJ45 Ethernet ports, and an
on-board XDS110 debug probe.
1 Preface: Read This
First.........................................................................................................................................................3
1.1 If You Need Assistance......................................................................................................................................................
1.2 Important Usage Notes......................................................................................................................................................
2 Kit Overview............................................................................................................................................................................
Contents........................................................................................................................................................................5
Features......................................................................................................................................................................5
2.3 Component Identification...................................................................................................................................................
2.4 BoosterPacks.....................................................................................................................................................................
2.5 Compliance........................................................................................................................................................................
Setup.............................................................................................................................................................................7
Requirements..........................................................................................................................................................7
3.1.3 Power Tree................................................................................................................................................................
Sequence........................................................................................................................................................11
3.2 Push Buttons....................................................................................................................................................................
3.3 Boot Mode Selection........................................................................................................................................................
Description...........................................................................................................................................................13
4.1 Functional Block Diagram................................................................................................................................................
4.2 BoosterPack Headers......................................................................................................................................................
4.2.1 Pinmux for BoosterPack............................................................................................................................................
4.3 GPIO Mapping.................................................................................................................................................................
4.4
Reset................................................................................................................................................................................27
4.5 Clock................................................................................................................................................................................
4.6 Memory Interface.............................................................................................................................................................
4.6.1 QSPI Interface...........................................................................................................................................................
4.6.2 Board ID
EEPROM....................................................................................................................................................30
4.7 Ethernet
Interface.............................................................................................................................................................31
4.7.1 Ethernet PHY Strapping............................................................................................................................................
4.7.2 Ethernet PHY - Power, Clock, Reset,
4.7.3 LED indication in Ethernet RJ45 Connector..............................................................................................................
4.8 USB 2.0
Interface.............................................................................................................................................................35
4.9 I2C
Interface.....................................................................................................................................................................35
4.10 Industrial Application LEDs............................................................................................................................................
4.11 UART
Interface...............................................................................................................................................................37
4.12 eQEP
Interface...............................................................................................................................................................38
4.13 CAN
Interface.................................................................................................................................................................40
4.14 FSI
Interface...................................................................................................................................................................41
4.15 JTAG Emulation.............................................................................................................................................................
4.16 Test Automation Interface..............................................................................................................................................
4.17 SPI Interface..................................................................................................................................................................
SPRUJ12B - AUGUST 2021 - REVISED OCTOBER 2022
Submit Document Feedback
™
development kit is a simple and inexpensive hardware evaluation module (EVM) for
™
AM243x series of microcontrollers (MCUs). This EVM provides an easy way to
Table of Contents
Connector.................................................................................................................7
....................................................................................................................................................9
Interrupt..........................................................................................................34
Copyright © 2022 Texas Instruments Incorporated
ABSTRACT
AM243x LaunchPad™ Development Kit User's Guide
Table of Contents
3
3
4
6
7
7
10
11
12
13
14
16
25
28
29
29
32
34
36
43
44
46
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments LaunchPad AM243 Series
Summary of Contents for Texas Instruments LaunchPad AM243 Series
-
Page 1: Table Of Contents
Interface................................38 4.13 CAN Interface.................................40 4.14 FSI Interface...................................41 4.15 JTAG Emulation................................4.16 Test Automation Interface.............................. 4.17 SPI Interface.................................. SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 2 Table 4-9. Net Name in Schematic and Package Signal Name for J6/J8 Connector..............Table 4-10. GPIO Mapping Table...............................25 AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 3 (only allowing data transfer from side B to A). The signals that not able to propagate to the BoosterPack headers include: UART2_RTSn, EHRPWM2_A, EHRPWM2_B, as well as any GPIO signals on the listed pins. SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 4: Kit Overview
Kit Overview www.ti.com 2 Kit Overview Figure 2-1. AM243x LaunchPad Board AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 5: Kit Contents
Four push buttons: – PORz Reset – MCU warm reset – SoC warm reset – User interrupt SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 6: Component Identification
2.3 Component Identification Figure 2-3. AM243x LaunchPad Top Component Identification Figure 2-4. AM243x LaunchPad Bottom Component Identification AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 7: Boosterpacks
AM243x LaunchPad. You can also build your own BoosterPack by following the design guidelines on TI’s website. Texas Instruments even helps you promote your BoosterPack to other members of the community. TI offers a variety of avenues for you to reach potential customers with your solutions. - Page 8 Two DC-DC buck regulators (TPS62822) are used to generate the 3.3 V main supply and VDD_CORE_0V85 from the 5 V input supply. AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 9: Power Status Led's
Power indicator for voltage - VDD_CORE_0V85 LD11 XDS110_PROG_STAZ1 LED will glow after XDS configuration LD10 XDS110_PROG_STAZ2 Figure 3-3. Power Status LED's SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 10: Power Tree
Board Setup www.ti.com 3.1.3 Power Tree Figure 3-4. Power Tree Diagram of AM243x LaunchPad AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 11: Power Sequence
PORz Reset input MCU_RESETz MCU warm reset input SoC_RESET_REQz SoC warm reset input USER_INTn User interrupt input SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 12: Boot Mode Selection
USB -DFU No Boot Figure 3-6. Boot-Mode DIP Switch Note SW4.8 of the DIP switch remains unused. AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 13: Hardware Description
Hardware Description 4 Hardware Description 4.1 Functional Block Diagram Figure 4-1. AM243x LaunchPad Functional Block Diagram SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 14: Boosterpack Headers
MMC1 • ADC0 • EHRPWM0_A/B and EHRPWM1_A/B • GPIO's • 5 V and 3.3 V power supplies AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 15 Power to BoosterPack sourced from LaunchPad ✔ Power to BoosterPack sourced from the BoosterPack Figure 4-3. Site #2 BoosterPack Header SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 16 Hardware Description www.ti.com 4.2.1 Pinmux for BoosterPack Figure 4-4. 80 Pin BoosterPack Pinout AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 17 J1.10 I2C1_SDA CPTS0_HW2TSPU TIMER_IO1 SPI2_CS2 DDR0_IO_PLL_REFCLK_TES DDR0_IO_PLL_REFCLK_TES GPIO1_6 J3.30 MCAN0_RX UART4_TXD TIMER_IO3 SYNC3_OUT SPI4_CS2 GPIO1_6 EQEP2_S UART0_RIn SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 18: Table 4-3. Net Name In Schematic And Package Signal Name For J1/J3 Connector
GPIO1_18 PRG0_PRU0_GPO18 J3.28 BP_ADC0_AIN7 ADC0_AIN7 J1.9 SOC_I2C1_SCL I2C1_SCL J3.29 SYNC2_OUT MCAN0_TX J1.10 SOC_I2C1_SDA I2C1_SDA J3.30 SYNC3_OUT MCAN0_RX AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 19 PRG0_PRU0_G PRG0_PRU0_G PRG0_PRU0_G PRG0_RGMII1_ PRG0_PWM2_ GPIO1_2 GPMC0_A0 UART2_RTSn J2.11 GPIO1_20 PRG0_PRU1_G PRG0_PRU1_G PRG0_PRU1_G PRG0_RGMII2_ GPIO1_20 EQEP0_A UART5_CTSn SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 20: Table 4-5. Net Name In Schematic And Package Signal Name For J2/J4 Connector
GPIO1_0 PRG0_PRU0_GPO0 J2.13 GPIO1_5 PRG0_PRU0_GPO5 J4.32 GPIO1_1 PRG0_PRU0_GPO1 J2.12 SPI3_CS1 PRG0_PRU0_GPO15 J4.31 GPIO1_2 PRG0_PRU0_GPO2 J2.11 GPIO1_20 PRG0_PRU1_GPO0 AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 21 PRG0_PRU1_GPO6 PRG0_PRU1_GPI6 PRG0_RGMII2_RXC GPIO1_26 EQEP2_A GPMC0_A19 UART4_CTS J5.50 I2C0_SDA UART6_RTSn GPIO1_65 J7.70 PRG0_PRU1_GPO1 PRG0_PRU1_GPI1 PRG0_RGMII2_TD0 GPIO1_31 EQEP2_I UART4_RXD SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 22: Table 4-7. Net Name In Schematic And Package Signal Name For J5/J7 Connector
GPIO1_6 PRG0_PRU0_GPO6 J7.68 GPIO1_22 PRG0_PRU1_GPO2 J5.49 SOC_I2C0_SCL_BP I2C0_SCL J7.69 GPIO1_26 PRG0_PRU1_GPO6 J5.50 SOC_I2C0_SDA_BP I2C0_SDA J7.70 GPIO1_31 PRG0_PRU1_GPO11 AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 23 GPMC0_A1 J8.71 PRG0_PRU1_GPO PRG0_PRU1_GPI13 PRG0_RGMII2_TD2 PRG0_PWM1_B GPIO1_3 EQEP0_I GPMC0_A8 UART5_RXD J6.51 PRG0_PRU0_GPO PRG0_PRU0_GPI8 PRG0_PWM2_A1 GPIO1_8 GPMC0_A2 UART4_RTSn SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 24: Table 4-9. Net Name In Schematic And Package Signal Name For J6/J8 Connector
GPIO1_78 MMC1_SDWP J6.53 GPIO1_40 PRG0_MDIO0_MDIO J8.72 GPIO1_32 PRG0_PRU1_GPO12 J6.52 GPIO1_41 PRG0_MDIO0_MDC J8.71 GPIO1_33 PRG0_PRU1_GPO13 J6.51 GPIO1_8 PRG0_PRU0_GPO8 AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 25: Table 4-10. Gpio Mapping Table
Interrupt signal from both RGMII1 & RGMII2 Ethernet PHY's GPIO0_50 PRG1_PRU0_GPO5 GPIO0_50 GPIO connected to BoosterPack header SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 26 Default State Function VPP_1V8_REG_EN PRG1_PRU0_GPO8 GPIO0_53 Output Active High To enable the VPP Regulator for eFUSE Programming AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 27 Upon Power on Reset, all peripheral devices connected to MCU domain get reset by MCU_RESETSTATz. One User input interrupt is connected to one of the GPIO of SoC. SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 28: Figure 4-6. Clock Architecture
The 16 MHz clock will only become active after power is supplied to the micro-B USB connector after insertion of a cable into the micro-B USB port. AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 29 VCCQ pins of the flash memory. The OSPI0 interface of the SoC is powered by the VDDSHV_3V3 supply. Figure 4-7. QSPI Interface SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 30 VendorID 0028 CHAR 1 is Mistral Build_Week 002A CHAR Filled in by Mistral Build_Year 002C CHAR 2021 AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 31 The LaunchPad supports two Ethernet PHYs that are terminated to RJ45 connectors with integrated magnetics for external communication. Figure 4-9. Ethernet Connection SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 32 Both PHY modes are selected as RGMII to copper with auto-negotiation advertised for 1000 Base-T, 100 Base-Tx, and 10 Base-Te speeds. AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 33 4-12. Figure 4-11. Ethernet PHY Strapping for RGMII1 PHY Figure 4-12. Ethernet PHY Strapping for RGMII2 PHY SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 34 LED1 is connected to RJ45 LED (orange) to indicated 1000 MHz link or receive error. • LED2 is connected to RJ45 LED (green) to indicate transmit/receive activity. AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 35 – Test automation header (687140183622 from Wurth) – I2C1 is also connected to the BoosterPack (J1.9, J1.10) expansion connector Figure 4-14. I2C Interface SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 36 The other green LED, as well as the red and two bi-color LEDs, are connected to SoC GPIO's such that they can be toggled based on the application. Figure 4-15. Industrial Application LEDs AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 37 One UART port from the main domain of the SoC (Main_UART0) is connected to a buffer (SN74AVC4T245PW) isolated between the SoC and the on-board emulator XDS110 (TM4C1294NCPDTT3R) Figure 4-16. UART Interface SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 38 (B13). Mux channel selection is done using SoC GPIO. Figure 4-17. eQEP Interface Figure 4-18. eQEP1 Header AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 39 Hardware Description Figure 4-19. eQEP2 Header Figure 4-20. eQEP2 or MCAN0 Mux Selection Circuit SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 40 CAN transceiver’s high and low are connected to the 3-pin header (J11). Figure 4-21. CAN Interface Figure 4-22. MCAN Transceiver and Header AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 41: Figure 4-23. Fsi Interface
J16.2 FSI_TX0_CLK J16.3 J16.4 J16.5 FSI_RX0_D0 J16.6 FSI_TX0_D0 J16.7 FSI_RX0_D1 J16.8 FSI_TX0_D1 J16.9 No connection J16.10 VSYS_3V3 SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 42 Hardware Description www.ti.com Figure 4-24. FSI Header Figure 4-25. FSI or BoosterPack Mux Selection Circuit AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 43 IEC 61000-4-2. Figure 4-26. JTAG Interface Figure 4-27. Micro-B USB Connection for JTAG SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 44 AM243x. Boot mode for the AM243x can be controlled by either the DIP switch or the test automation header through the I2C IO expander. AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 45: Figure 4-28. Test Automation Header
Data signal for SoC I2C Bidirectional BOOTMODE_I2C_SDA Data signal for I2C IO expander for boot mode Ground DGND Ground DGND SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 46 The SPI connections between the SoC and the BoosterPack connectors are show in Figure 4-29. Figure 4-29. SPI Connection From SoC to BoosterPack Connector AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 47 MMC1 • ADC0 • EHRPWM0_A/B and EHRPWM1_A/B • GPIO's • 5 V and 3.3 V power supplies SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 48 Power to BoosterPack sourced from LaunchPad ✔ Power to BoosterPack sourced from the BoosterPack Figure 4-3. Site #2 BoosterPack Header AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 49 Hardware Description 4.2.1 Pinmux for BoosterPack Figure 4-4. 80 Pin BoosterPack Pinout SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 50 J1.10 I2C1_SDA CPTS0_HW2TSPU TIMER_IO1 SPI2_CS2 DDR0_IO_PLL_REFCLK_TES DDR0_IO_PLL_REFCLK_TES GPIO1_6 J3.30 MCAN0_RX UART4_TXD TIMER_IO3 SYNC3_OUT SPI4_CS2 GPIO1_6 EQEP2_S UART0_RIn AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 51 GPIO1_18 PRG0_PRU0_GPO18 J3.28 BP_ADC0_AIN7 ADC0_AIN7 J1.9 SOC_I2C1_SCL I2C1_SCL J3.29 SYNC2_OUT MCAN0_TX J1.10 SOC_I2C1_SDA I2C1_SDA J3.30 SYNC3_OUT MCAN0_RX SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 52 PRG0_PRU0_G PRG0_PRU0_G PRG0_PRU0_G PRG0_RGMII1_ PRG0_PWM2_ GPIO1_2 GPMC0_A0 UART2_RTSn J2.11 GPIO1_20 PRG0_PRU1_G PRG0_PRU1_G PRG0_PRU1_G PRG0_RGMII2_ GPIO1_20 EQEP0_A UART5_CTSn AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 53 GPIO1_0 PRG0_PRU0_GPO0 J2.13 GPIO1_5 PRG0_PRU0_GPO5 J4.32 GPIO1_1 PRG0_PRU0_GPO1 J2.12 SPI3_CS1 PRG0_PRU0_GPO15 J4.31 GPIO1_2 PRG0_PRU0_GPO2 J2.11 GPIO1_20 PRG0_PRU1_GPO0 SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 54 PRG0_PRU1_GPO6 PRG0_PRU1_GPI6 PRG0_RGMII2_RXC GPIO1_26 EQEP2_A GPMC0_A19 UART4_CTS J5.50 I2C0_SDA UART6_RTSn GPIO1_65 J7.70 PRG0_PRU1_GPO1 PRG0_PRU1_GPI1 PRG0_RGMII2_TD0 GPIO1_31 EQEP2_I UART4_RXD AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 55 GPIO1_6 PRG0_PRU0_GPO6 J7.68 GPIO1_22 PRG0_PRU1_GPO2 J5.49 SOC_I2C0_SCL_BP I2C0_SCL J7.69 GPIO1_26 PRG0_PRU1_GPO6 J5.50 SOC_I2C0_SDA_BP I2C0_SDA J7.70 GPIO1_31 PRG0_PRU1_GPO11 SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 56 GPMC0_A1 J8.71 PRG0_PRU1_GPO PRG0_PRU1_GPI13 PRG0_RGMII2_TD2 PRG0_PWM1_B GPIO1_3 EQEP0_I GPMC0_A8 UART5_RXD J6.51 PRG0_PRU0_GPO PRG0_PRU0_GPI8 PRG0_PWM2_A1 GPIO1_8 GPMC0_A2 UART4_RTSn AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 57 GPIO1_78 MMC1_SDWP J6.53 GPIO1_40 PRG0_MDIO0_MDIO J8.72 GPIO1_32 PRG0_PRU1_GPO12 J6.52 GPIO1_41 PRG0_MDIO0_MDC J8.71 GPIO1_33 PRG0_PRU1_GPO13 J6.51 GPIO1_8 PRG0_PRU0_GPO8 SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 58 Interrupt signal from both RGMII1 & RGMII2 Ethernet PHY's GPIO0_50 PRG1_PRU0_GPO5 GPIO0_50 GPIO connected to BoosterPack header AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 59 Default State Function VPP_1V8_REG_EN PRG1_PRU0_GPO8 GPIO0_53 Output Active High To enable the VPP Regulator for eFUSE Programming SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 60 Upon Power on Reset, all peripheral devices connected to MCU domain get reset by MCU_RESETSTATz. One User input interrupt is connected to one of the GPIO of SoC. AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 61 The 16 MHz clock will only become active after power is supplied to the micro-B USB connector after insertion of a cable into the micro-B USB port. SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 62 VCCQ pins of the flash memory. The OSPI0 interface of the SoC is powered by the VDDSHV_3V3 supply. Figure 4-7. QSPI Interface AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 63: Figure 4-8. Board Id Eeprom
VendorID 0028 CHAR 1 is Mistral Build_Week 002A CHAR Filled in by Mistral Build_Year 002C CHAR 2021 SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 64: Figure 4-9. Ethernet Connection
The LaunchPad supports two Ethernet PHYs that are terminated to RJ45 connectors with integrated magnetics for external communication. Figure 4-9. Ethernet Connection AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 65: Figure 4-10. Cpsw Or Prg Rgmii1 Ethernet Data Mux
Both PHY modes are selected as RGMII to copper with auto-negotiation advertised for 1000 Base-T, 100 Base-Tx, and 10 Base-Te speeds. SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 66: Figure 4-11. Ethernet Phy Strapping For Rgmii1 Phy
4-12. Figure 4-11. Ethernet PHY Strapping for RGMII1 PHY Figure 4-12. Ethernet PHY Strapping for RGMII2 PHY AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 67: Table 4-13. Ethernet Phy Strapping Values
LED1 is connected to RJ45 LED (orange) to indicated 1000 MHz link or receive error. • LED2 is connected to RJ45 LED (green) to indicate transmit/receive activity. SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 68: Figure 4-13. Usb 2.0 Interface
– Test automation header (687140183622 from Wurth) – I2C1 is also connected to the BoosterPack (J1.9, J1.10) expansion connector Figure 4-14. I2C Interface AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 69: Figure 4-15. Industrial Application Leds
The other green LED, as well as the red and two bi-color LEDs, are connected to SoC GPIO's such that they can be toggled based on the application. Figure 4-15. Industrial Application LEDs SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 70: Figure 4-16. Uart Interface
One UART port from the main domain of the SoC (Main_UART0) is connected to a buffer (SN74AVC4T245PW) isolated between the SoC and the on-board emulator XDS110 (TM4C1294NCPDTT3R) Figure 4-16. UART Interface AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 71: Figure 4-17. Eqep Interface
(B13). Mux channel selection is done using SoC GPIO. Figure 4-17. eQEP Interface Figure 4-18. eQEP1 Header SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 72: Figure 4-19. Eqep2 Header
Hardware Description www.ti.com Figure 4-19. eQEP2 Header Figure 4-20. eQEP2 or MCAN0 Mux Selection Circuit AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 73: Figure 4-21. Can Interface
CAN transceiver’s high and low are connected to the 3-pin header (J11). Figure 4-21. CAN Interface Figure 4-22. MCAN Transceiver and Header SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 74: Table 4-14. Fsi Header Pin Description
J16.2 FSI_TX0_CLK J16.3 J16.4 J16.5 FSI_RX0_D0 J16.6 FSI_TX0_D0 J16.7 FSI_RX0_D1 J16.8 FSI_TX0_D1 J16.9 No connection J16.10 VSYS_3V3 AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 75 Hardware Description Figure 4-24. FSI Header Figure 4-25. FSI or BoosterPack Mux Selection Circuit SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 76 IEC 61000-4-2. Figure 4-26. JTAG Interface Figure 4-27. Micro-B USB Connection for JTAG AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 77 AM243x. Boot mode for the AM243x can be controlled by either the DIP switch or the test automation header through the I2C IO expander. SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 78: Table 4-16. Test Automation Header Pinout
Data signal for SoC I2C Bidirectional BOOTMODE_I2C_SDA Data signal for I2C IO expander for boot mode Ground DGND Ground DGND AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 79 The SPI connections between the SoC and the BoosterPack connectors are show in Figure 4-29. Figure 4-29. SPI Connection From SoC to BoosterPack Connector SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
- Page 80 Changes from Revision A (September 2021) to Revision B (October 2022) Page • (E3 Design Changes): Added section to detail revision changes from E2 → E3..........AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
-
Page 81: Table A-1. E3 Rj45 Connector
The following Ethernet PHY signals were not connected to the AM243x GPIO in the E2 Revision: • PRG1_CPSW_ETH1_LED_LINK • PRG1_CPSW_ETH2_LED_LINK • PRG1_CPSW_ETH1_LED_1000/RX_ER • PRG1_CPSW_ETH2_LED_1000/RX_ER • PRG1_CPSW_ETH1_LED_ACT SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 AM243x LaunchPad™ Development Kit User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... -
Page 82: Table A-3. E3 Ethernet Phy Signal Mapping
Interface Mount CPSW_RGMII1_TX_CTL & CPWS_RGMII1_TD1 (Default) R595, R597 R594, R596 PRG1_CPSW_ETH1_LED_ACT & PRG1_CPSW_ETH2_LED_ACT R594, R596 R595, R597 AM243x LaunchPad™ Development Kit User's Guide SPRUJ12B – AUGUST 2021 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated... - Page 83 TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for TI products. TI objects to and rejects any additional or different terms you may have proposed. IMPORTANT NOTICE Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2022, Texas Instruments Incorporated...
