MAX98050 Evaluation System
General Description
The MAX98050 evaluation system (MAX98050EVSYS#)
evaluates the MAX98050, a low-power, high-performance
audio CODEC with integrated low-latency digital filters
for wireless hearables, headsets, and headphones. The
EV system is comprised of two MAX98050 Development
Boards (DEV boards), Maxim's Audio Interface Board III
(AUDINT3), Maxim's Dual EVKit Adapter board, and a
USB cable. In addition to the hardware, the MAX98050
Evaluation Software and Hearable Sound Studio Basic
software are available for download.
It is recommended that the DEV boards be evaluated with
the AUDINT3 board as an EV system. The EV system can
be configured as Mono Hardware Setup (1 DEV board)
or Stereo Hardware Setup (2 DEV boards). MAX98050
2
supports standard I
S, left-justified, and TDM digital audio
2
interfaces, as well as I
C for control.
The AUDINT3 board provides all of the necessary supply
voltages for proper operation of MAX98050. In addition,
the AUDINT3 provides the USB-to-PCM and USB-to-I
interfaces that are needed to evaluate the system. The
Simplified EV System Block Diagrams show details of the
DEV boards, Dual EVKit Adapter board and connection
with the AUDINT3 board.
Simplified EV System Block Diagram for MAX98050: Mono Hardware Setup
S3
S2
S1
J2
USB
INTERFACE
AUDIO INTERFACE BOARD 3
Windows is a registered trademark and registered service mark
of Microsoft Corporation.
319-100629; Rev 0; 11/20
JU2
D1
MBVDD
MBVDD
AVDD2
AVDD2
AVDD1
DVDD
SCL
J1
J1
SDA
DOUT
DIN
LRCLK
BCLK
N/C
DVDDIO
JU1
For GUIs, there is the MAX98050 Evaluation Software,
which provides complete access to all hardware registers.
There is also the Hearable Sound Studio Basic software,
which facilitates the tuning of the onboard 5 band play-
back equalizer, digital filter channels, and the digital filter
dynamic range compression (DRC).
Benefits and Features
● Complete Hardware System with Easy Setup, No
Tools or Special Equipment Required
● Easy-to-Use Graphical User Interfaces Software
®
(Windows
• MAX98050 Evaluation Software Provides Complete
Access to All Hardware Registers
• Hearable Sound Studio Basic for Digital Filter
Design and Acoustic Hardware Evaluation
EV System Contents
● Two MAX98050 Development Boards (DEV Boards)
● Audio Interface Board III (AUDINT3)
2
C
● Dual EVKit Adapter Board
● Micro-USB cable
Ordering Information
AVDD1
DMIC1
PGND
MAX98050 DEVELOPMENT BOARD
IRQ
SCL
SDA
DOUT
DIN
LRCLK
BCLK
I2C ADDRESS
0x62
J2
0x68
0x66
JMP1
ENABLE
0x64
HW_EN
DVDD
DISABLE
Evaluates: MAX98050
10 Compatible)
appears at end of data sheet.
J13
TIP
RING1
RING2
DMIC2
DMIC3
SLEEVE
TIP
RING1
RING2
SLEEVE
TIP
RING1
RING2
SLEEVE
MAX98050
U1
OUTP
OUTN
J14
DVDDIO
AVDD2 / AVDD3
AMIC1 /
AMIC1+AMIC2
J6
J10
AMIC2
J7
J11
AMIC3
J8
J12
HEADPHONE
OUTPUT
J9
