Summary of Contents for Minka Group minkaAire ORB F623L
- Page 2 2019...
- Page 4 F623L...
- Page 5 INSTALLING THE GLASS SHADE INSTALLING THE LIGHT KIT PLATE...
- Page 8 Light kit plate 12.7 Glass Shade...
- Page 15 CENTER HOUSING Step 1: Insert the blade through the slot on the center housing. Secure the blade with three blade screws and three fiber washer provided.(Fig 14) BLADE Step 2: Repeat for the remaining three blades.(Fig.15) FIBER WASHER BLADE SCREW...
-
Page 16: Installing The Light Kit Plate
INSTALLING THE LIGHT KIT PLATE Step 1: Remove one of three screws from the mounting ring on the fan motor assembly and loosen,but do not remove, the other two screws. MOUNTING PLATE Step 2 : Place the key holes from the light kit plate over the two screws previously loosened from the mounting ring. - Page 17 LIGHT KIT PLATE Step 2 .Remove one of three screws from the light kit plate and loosen,but do not remove, the other two screws.(Fig.17) WIRE CONNECTION PLUGS Step 3 . Place the key holes from 16W LED assembly over the two screws 16W LED ASSEMBLY previously loosened from the light kit plate.
-
Page 18: Installing The Glass Shade
INSTALLING THE GLASS SHADE Raise the glass shade up against light kit plate and secure it to fan by turning it clockwise until snug. DO NOT OVERTIGHTEN.(Fig 18) GLASS SHADE LIGHT KIT PLATE... - Page 21 REVERSE SWITCH WARM COOL WEATHER WEATHER...
- Page 27 0.26 15.91 7.08 8.34 1.509 59.62...
- Page 28 2257 15.91 3,707 4985 59.62...
