Hardware Kit - Sim-Lab GT1-EVO Instruction Manual

GT1-EVO DIRECT DRIVE MOUNT
PROFILE KIT
# Part
P1 80X40 Length=120mm

HARDWARE KIT

A2 Corner bracket 40x40
A3 Corner bracket 40x40 cap
A4 Profile 80x40 end-cap
A5 Bolt M8 X 16 DIN 912
A6 Washer M8 DIN 125-A
A7 Slot-Nut M8
QTY Note
2
4
4
2
12
12
12
SERVO MOTOR HOLDER
HARDWARE KIT
# Part
B1 Servo Motor Holder
B2 Servo Motor Holder LEFT
B3 Servo Motor Holder RIGHT
B4 Bolt M8 X 40 DIN 912
B5 Bolt M8 X 20 DIN 912
B6 Bolt M8 X 16 DIN 912
B7 Washer M8 DIN 125-A
B8 Slot-Nut M8
B9 Lock-Nut M8
Disclaimer: for some entries on this list, we supply more than required as spare
materials. Don't worry if you have some leftovers, this is intentional.
QTY Note
1
1
1
4
4
4 When used standalone
16
4 When used standalone
8
9
9 10 |
