Ihse Kvm-Tec USBFLEX KT-6032L Quick Installation

kvm-tec
First Aid
Your Extender....
No Power USB is not
(No LED) working
Are the USB
Check the
Devices plugged
powerplug
in correctly?
Is the USB cable on
Is the power
the Local side plug-
supply ok? Try
ged into the PC?
another Unit.
Try reprogramming Are the USB
Devices working
the Unit by using a
directly on the PC?
JTAG programmer
Replace the USB
Contact kvm-tec
cable from PC to
support
the Local Extender
Check if local and
remote Unit have
the same firmware
Check if the local
or the remote
Unit is causing
the problem by
swaping first the
local and than the
remote Unit to
another Unit
Contact kvm-tec
Misprints, errors and technical changes reserved
Update with USB-Stick
Plug the USB stick with update file into USB Flex.
2. press the button on the back left (if PtP, the USB channel will be
disconnected) ~ 4 sec
3. wait until LED flashes orange (USB stick is scanned for updates) ~
10-20 sec
4. LED lights up specifically for 3 seconds
LED red -> no update on stick found (remove stick and start at step 1)
LED green -> Update found, ready to start
5. press button again
6. wait until the update is completed or an error occurs (for PtP local is
updated first) ~ 2-3 min (PtP ~ 5-6 min)
While update is running, LED flashes green, if data is transferred or
copied, LED flashes very fast.
At the end of the update, the LED flashes orange 4 more times and then
starts the reboot process (the Extender must not be disconnected from
the power supply during this process!)
support
KT-6032L CPU/LOCAL
KT-6032R CON/REMOTE
Check out
our Installation Channel:
www.kvm-tec.com
kvm-tec
Quick
Installation
