Overview
1: Door Lever
7: Strike and Strike box
2: Latch Assembly
8: Outside Handle
3: Wood Screws
9: Spacer
4: Mounting Screws
10: Inside Screw
5: Inside Knob
11: Decorative cover
6: Screw holes
Press the Opening button or turn the
Inside Knob right to open the door.
Specifications
Item
Description
Model Name
TL121
Net Weight
1.79 lb
Dimensions
11.6 x 6.41 x 2.75 in
Material
Zinc alloy
Installation
Intermediate (tools not included)
Water Rating
IP65 (dust and splash proof)
Assembled Diameter
2.71 in
2
3
1
7
4
6
5
8
9
11
10
In order to continue serving our customers and providing the best products, our product information including our user manuals may
receive updates from time to time. Please check our website for the latest user manuals and product materials. Version 1.0 11/28/19
