GP Digital Modulation > Trellis Diagram

Trellis Diagram Display

The Trellis Diagram display

To show an Trellis Diagram display:

1. Press the Displays button or select Setup > Displays. This shows the Select Displays dialog box.

2. From the Folders box, select GP Digital Modulation.

3. Double-click the Trellis Diagram icon in the Available Displays box. This adds the Trellis Diagram

icon to the Selected displays box.

4. Click the OK button. This displays the Trellis Diagram view.

Elements of the Display

RSA6100A Series Real-Time Spectrum Analyzers Help

Trellis Diagram Display
