Settling Time Settings - Tektronix RSA6100A Series Help Manual

RF Measurements > Settling Time Displays
Frequency settling time display after setting the measurement length

Settling Time Settings

The settings for the Frequency and Phase Settling Time displays are shown in the following table.
Settings tab
Define (see page 190)
Time Params (see page 192)
Mask (see page 193)
Trace (see page 193)
Scale (see page 203)
Prefs (see page 204)
xxx
RSA6100A Series Real-Time Spectrum Analyzers Help
Description
Sets the measurement parameters that characterize the settling time measurement.
Sets measurement end-time and minimum settled duration parameters.
Enable or disables mask testing and sets the parameters that specify the three zones
used for mask testing.
Specifies trace display characteristics and which traces are displayed.
Sets vertical and horizontal scale and position parameters.
Specifies whether or not to show certain display elements, the maximum number of points
in the exported trace, and the displayed precision of the settling time measurement.
