RF Measurements

Overview

The displays in the RF Measurements folder (Displays > Folders > RF Measurements) are:
CCDF

Channel Power and ACPR

MCPR
Occupied Bandwidth
Phase Noise (Option 11)
Spurious
The RF Measurements power measurements and signal statistics help you characterize components and
systems. With Option 11, the RF Measurements also includes Phase Noise and Jitter Measurements.
Power Measurements
Measurement
Channel Power
Adjacent Channel Power Ratio
Multi-Carrier Power Ratio
Peak/Avg Ratio
CCDF
xxx
132
Description
The total RF power in the selected channel (located in the ACPR display).
Measure of the signal power leaking from the main channel into adjacent channels.
The ratio of the signal power in the reference channel or group of channels to the power
in adjacent channels.
Ratio of the peak power in the transmitted signal to the average power in the transmitted
signal (located in the CCDF display).
The Complementary Cumulative Distribution Function (CCDF). CCDF shows how much
time a signal spends at or above a given power level relative to the average power of
a measured signal.
