FCC Part 15.247
Transmitter Certification
Frequency Hopping Spread Spectrum Transmitter
Test Report
FCC ID: SK9C3A-1L
FCC Rule Part: 15.247
ACS Report Number: 06-0013-15C
Manufacturer: Itron Electricity Metering Inc.
Trade name: CENTRON® IMAGE
Model: C3A1L
Manual
5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for ITRON CENTRON CP1S
Summary of Contents for ITRON CENTRON CP1S
- Page 1 Frequency Hopping Spread Spectrum Transmitter Test Report FCC ID: SK9C3A-1L FCC Rule Part: 15.247 ACS Report Number: 06-0013-15C Manufacturer: Itron Electricity Metering Inc. Trade name: CENTRON® IMAGE Model: C3A1L Manual 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598...
- Page 2 CENTRON® Polyphase Meter Technical Reference Guide Effective Date: January 2006 DRAFT...
-
Page 3: Trademarks Used In This Manual
Proprietary Rights Notice This manual contains the trade secrets and confidential information of Itron, Inc., which are not to be divulged to third parties and may not be reproduced or transmitted in whole or part, in any form or by any means, electronic or mechanical for any purpose, without the express written permission of Itron, Inc. -
Page 4: Compliance With Fcc Regulations
Connect the equipment and the affected receiver to power outlets on separate circuits. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Itron, Inc. could void the user’s authority to operate the equipment. -
Page 5: Rf Exposure Information
Repair of Meters Under Warranty If the meter is under warranty, then Itron, Inc. will repair the meter at no charge if the meter has failed due to components or workmanship. A return authorization number must be obtained before the equipment can be sent back to the factory. -
Page 6: Recycling Information
Recycling Information The product you have purchased contains a battery (or batteries), circuit boards, and switches. The batteries are recyclable. At the end of the meter’s useful life, under various state and local laws, it may be illegal to dispose of certain components into the municipal waste system. -
Page 8: Table Of Contents
Table of Contents Proprietary Rights Notice ..................ii Trademarks Used in This Manual ....................ii Compliance With FCC Regulations....................iii FCC Part 15, Class B......................iii FCC Part 15, Subpart C...................... iii RF Exposure Information ....................iv Canadian Interference Causing Equipment Regulations............ iv Factory Repair of Meters....................... - Page 9 Table of Contents Registers ............................18 Kilowatt Hours........................18 Resetting Values........................19 LCD Display Function........................19 Non-Detented Register ................... 20 Detented Register....................20 Net Register......................20 Segment Check ...................... 21 Factory Programming Options................21 Testing, Troubleshooting and Maintenance .................22 Chapter 5 Operation: CP1SR Version ..............23 Standard Consumption Message (SCM) ..................24 Interval Data Message (IDM) .......................24 Physical Description ........................25...
- Page 10 Table of Contents Energy Data Display Items ....................41 Demand Data Display Items ....................41 Instantaneous Data Display Items ..................42 Informational Data Display Items..................42 Magnetic Switch.........................44 Scroll Lock .........................44 Changing Display Modes ....................44 Mode Timeout ........................44 Normal Display Mode......................44 Alternate Display Mode......................45 Toolbox Display Mode .......................45 Test Display Mode ......................46 Test Alternate Display Mode....................47...
- Page 11 Table of Contents SiteScan Meter Self-Diagnostic Checks ................62 SiteScan Toolbox Mode.....................62 SiteScan System and Installation Diagnostic Checks ............66 SiteScan Diagnostic #1......................72 Current Angle Tolerance..................72 Cross-Phase, Polarity, and Energy Flow Check ............ 72 SiteScan Diagnostic #2......................74 Phase Voltage Deviation Check ................75 SiteScan Diagnostic #3......................76 Inactive Phase Current Check................
- Page 12 Table of Figures Figure 1: CENTRON Polyphase Meter Metrology .................3 Figure 2: CENTRON Personality Module Assembly..............3 Figure 3: Dimensions ........................6 Figure 4: Removing the Board-to-Board Connector ..............9 Figure 5: Circuit Board Notches ....................10 Figure 6: Board-to-Board Connector, Bottom ................10 Figure 7: Board-to-Board Connector, Top ...................11 Figure 8: CENTRON Polyphase Metrology .................13 Figure 9: Sampled Waveform ......................14 Figure 10: Voltage and Current Measurement................15...
-
Page 14: Chapter 1 General Information
Specifications......................4 This technical reference guide explains the installation, operation, and maintenance of the Itron CENTRON Polyphase meter family. Itron urges you to read the entire manual before attempting installation, testing, operation, or maintenance of a meter. To operate the Itron PC-PRO+ Advanced Programming Software and the PRO-READ handheld reader programmer discussed in this manual, refer to their respective user manuals. -
Page 15: General Description
General Information General Description The CENTRON meter family is a solid-state, polyphase meter used for measuring electrical energy consumption. The CENTRON incorporates a two-piece design combining a base metrology with a variety of personality modules that snap on the standard meter base. Utilizing the Hall Effect technology for accurate power measurement, the metrology portion of the meter contains all measurement circuitry and calibration information, while the personality modules contain the register functionality and communication mediums. -
Page 16: Personality Modules
General Information Meter bases are built specific to the metering form and are available in Form 9S CL20 and Form 16S CL200 configurations. All meter forms are auto-voltage ranging from 120 to 480 volts. An example of the metrology is shown below. Figure 1: CENTRON Polyphase Meter Metrology Personality Modules All of the personality modules in the CENTRON Polyphase meter family snap into the... -
Page 17: Product Availability
General Information Product Availability The current offerings for the CENTRON are: Metrology Class 20, 120-480V, Form 9S Class 200, 120-480V, Form 16S Personality Modules CP1S—LCD (5x1 or 4x10) CP1SR—R300C (Radio Frequency) CP1SD/T/L—Demand/TOU/LP CP1SR2/R3—R300CD/R300CD3 Outputs The CP1SD, CP1ST, and CP1SL personality modules are available input/output-ready (I/O-ready). -
Page 18: Operating Environment
General Information Operating Environment Temperature -40°C to +85°C Humidity 0% to 95% non-condensing Accuracy ± 0.2% @ unity power factor ± 0.3% @ 50% power factor Transient/Surge ANSI C37.90.1 - 1989 Suppression IEC 61000-4-4 ANSI C62.45 - 1992 Characteristic Data Temperature Rise Meets ANSI C12.1 Section 4.7.2.9 Technical Data... -
Page 19: Dimensions
General Information Dimensions The following dimensional measurements are shown in inches and (centimeters). Figure 3: Dimensions Polycarbonate 6.29 (16.00) 6.95 (17.70) 2.70 3.16 4.53 (6.90) (8.00) (11.50) CENTRON® Polyphase Meter Technical Reference Guide... -
Page 20: Chapter 2 Installation
H A P T E R Installation In This Chapter Inspection ......................7 Storage........................7 Unpacking......................7 Selecting a Site ......................7 Installing the Meter into Service................8 Retrofitting with Personality Modules..............8 Inspection Perform the following inspections when you receive the meter: Inspect for obvious damage to the cover, base, and meter assembly. Compare the meter and register nameplates to the record card and invoice. -
Page 21: Installing The Meter Into Service
Installation Installing the Meter into Service Install the meter base using standard meter installation practices. The current and potential terminals extend as blades, or bayonets, from the back of the meter. The meter is plugged into the socket so that the bayonets engage the main socket jaws that connect to the service lines. -
Page 22: Figure 4: Removing The Board-To-Board Connector
Installation Remove the black board-to-board connector ( in the figure below) between the circuit board and the metrology board by pulling it by its middle while moving it side- to-side. To maintain the integrity of the connector, only remove it when you are upgrading the meter. -
Page 23: Figure 5: Circuit Board Notches
Installation Replace the board-to-board connector by aligning the top of the connector with the notches in the circuit board and pressing gently at the bottom of connector to mate the connector to metrology board. Then, gently press the top of the connector to mate it to the register module. -
Page 24: Figure 7: Board-To-Board Connector, Top
Installation Ensure the board-to-board connector is fully seated by pressing firmly in on the middle of the connector. Figure 7: Board-to-Board Connector, Top Carefully replace the inner protective cover. Engage the top snaps first, taking care to place the slot at the top of the cover over the IR light pipe. Failure to do so could break the light pipe. -
Page 26: Chapter 3 Operation: Base Metrology
H A P T E R Operation: Base Metrology In This Chapter Metrology ......................13 Surge Protection ....................14 Sampling......................14 Voltage and Current Measurement ..............15 Metrology The CENTRON Polyphase meter is a solid-state meter which uses the Hall Effect (one per phase) to measure metered current and voltage dividers (one per phase) to measure metered voltage as indicated in block diagram below. -
Page 27: Surge Protection
Operation: Base Metrology Surge Protection Surge protection for the electronics in the CENTRON POLYPHASE meter is provided by Metal Oxide Varistors (MOVs). MOVs are clamping devices that allow voltage up to a limit, and then increasingly conduct current to prevent the voltage from exceeding the limit. -
Page 28: Voltage And Current Measurement
Operation: Base Metrology Voltage and Current Measurement Figure 10: Voltage and Current Measurement CENTRON® Polyphase Meter Technical Reference Guide... -
Page 30: Chapter 4 Operation: Cp1S Version
H A P T E R Operation: CP1S Version In This Chapter Physical Description ....................18 Registers ......................18 LCD Display Function..................19 Testing, Troubleshooting and Maintenance............22 The kWh only version of the CENTRON Polyphase meter is available with an LCD personality module to register energy accumulation. Figure 11: CP1S LCD Personality Module The LCD module may be ordered with a 5x1 or 4x10 register for self-contained meters, and a 5xTR or 4xTR register for transformer-rated meters. -
Page 31: Physical Description
Operation: CP1S Version Physical Description The CENTRON Polyphase meter Personality Modules snap into the meter register mounting brackets to ease installation of the board. The LCD module is connected to the metrology board using the board-to-board connector. The following information is sent to the LCD module from the metrology board: Reference voltages Energy data Basic status information... -
Page 32: Resetting Values
Operation: CP1S Version Resetting Values The ZRO-C2A resets the energy register through a direct connection to the connector at the 12 o'clock position on the LCD and R300 modules. Figure 12: ZRO-C2A Resetter Connected to the CENTRON The ZRO-C2A is a pocket-sized handheld device for resetting the electronic meter readings in the CENTRON Polyphase LCD kWh meter (CP1S) and the R300 meter (CP1SR). -
Page 33: Non-Detented Register
Operation: CP1S Version Non-Detented Register The Non-Detented Register displays the delivered energy plus received energy. Figure 13: Non-Detented Register (kWhd + kWhr) Detented Register The Detented Register addresses applications requiring the reading of delivered kWh only. Received energy is discarded. Figure 14: Delivered kWh with Detent Enabled (kWhd) Net Register The Net (kWh) Register addresses applications requiring residential net metering points. -
Page 34: Segment Check
Operation: CP1S Version Segment Check The Segment Check Register addresses applications requiring display scrolling between 21 for factory programming kWh and a full segment check. See Display Timing (on page options. Figure 16: Segment Check Factory Programming Options Display Timing The display will scroll between the billing register and the segment check mode based on the factory programming option. -
Page 35: Testing, Troubleshooting And Maintenance
Operation: CP1S Version Testing, Troubleshooting and Maintenance Diagnostic Display OFF Period Notes Metrology message stopped for Error Missing message with greater than 15 seconds and diagnostic flag also less than 10 minutes written to the memory Power up with Phase A, B, and noSEr C voltage equal to 0 degrees CENTRON®... -
Page 36: Chapter 5 Operation: Cp1Sr Version
H A P T E R Operation: CP1SR Version In This Chapter Standard Consumption Message (SCM)..............24 Interval Data Message (IDM) ................24 Physical Description ....................25 Registers ......................25 Transmission Scheme ..................27 Tamper Detection ....................28 Retrofitting the CP1SR Personality Module............29 Testing, Troubleshooting and Maintenance............30 The CP1SR module is a one-way, unlicensed radio frequency (RF) personality module that attaches to the CENTRON Polyphase meter base (See the figure below). -
Page 37: Standard Consumption Message (Scm)
(OMR), a vehicle-based Mobile AMR unit such as the Mobile Collector, or a network data collection solution such as the Itron Fixed Network or MicroNetwork. In addition, the R300 IDM is also capable of delivering the Interval Data Message to the Itron Fixed Network AMR system to calculate ANSI standard demand, time-of-use, and load profiling information. -
Page 38: Physical Description
LCD, for resetting the energy register and tamper counters. This can be accomplished with the ZRO-C2A Resetter. The CP1SR uses a unique module identification number, provided by Itron. This ID number is contained in each message transmission and is used by the handheld and billing system to determine meter identity and location. -
Page 39: Electronic Detent
Operation: CP1SR Version The transformer rated meters can be programmed to display either a 5xTR or 4xTR. In order to determine the actual energy consumption, the display reading needs to be multiplied by the transformer ratio (TR). If the transformer ratio is 1, then the reading on the display is the actual energy consumption. -
Page 40: Net Metering
Operation: CP1SR Version Net Metering The CP1SR module is available with the option of net metering capability. When the net option is enabled, received energy is subtracted from delivered energy. The net energy value is then displayed on the register. Resetting Values The ZRO-C2A Resetter zeros both the energy registers and tamper counters by direct connection to the CP1SR module. -
Page 41: Fcc Regulations
Tamper Detection The CENTRON Polyphase CP1SR features the Itron patented method of tamper detection that senses both meter removal and meter inversion. The removal tamper (RTPR) increments a counter each time the meter is abruptly removed from a live meter socket. The tamper counter utilizes a tilt switch to detect when the meter is removed from a meter socket. -
Page 42: Retrofitting The Cp1Sr Personality Module
Operation: CP1SR Version ReadOne Pro Tamper Count: Binary Tamper Count Inversion Removal 0000 0001 0010 0011 0100 0101 0110 0111 1000 1001 1010 1011 1100 1101 1110 1111 Retrofitting the CP1SR Personality Module The CENTRON R300 is a one-way radio frequency personality module that transmits within the unlicensed 910-920 MHz frequency band governed by the US Code of Federal Regulations (CFR) Title 47, Part 15 Radio Frequency Devices, Sub Part C Paragraph 249 Intentional Radiator. -
Page 43: Testing, Troubleshooting And Maintenance
Operation: CP1SR Version Recent revisions to the CP1SR module include placing the FCC ID on the module itself. Changes or modifications not expressly approved by Itron could void the user's authority to operate the equipment. To retrofit an existing meter with an R300 module, see Retrofitting with Personality Modules (on page 8). -
Page 44: Chapter 6 Operation: Cp1Sd/T/L Version
H A P T E R Operation: CP1SD/T/L Version In This Chapter Controls and Indicators..................31 Factory Reset .......................37 Application of Power and Power-up..............37 Power Down Procedures..................38 Operating Modes ....................39 Display Modes.....................40 Registers ......................47 Interrogation and Programming................49 Time-of-Use (TOU).....................50 Load Profile ......................53 Event Log ......................56 Security Codes.....................58 Firmware Upgrades .....................60... -
Page 45: Demand Reset Button
Operation: CP1SD/T/L Version Callout Description Optical Port Infrared Test LED Nameplate Demand Reset Button The demand reset button is located at the 6 o’clock position on the meter face. The demand reset mechanism is used to initiate a demand reset. The demand reset cover mechanism can be physically locked with a meter seal, or disabled by the meter programming software. -
Page 46: Power Flow
Operation: CP1SD/T/L Version Static Indicators Indicator Description VA, VB, VC Indicators for phase voltages being present Reactive Load Indicator: No arrow for unity PF for positive [delivered] (lag) for negative [received] (lead) 120 240 277 480 Nominal Voltage Indicator (one value appears at a time) End of Interval (Registers - Dmd) Scroll Lock (indicates temporary scroll lock of a display Scr Loc... -
Page 47: Load Emulator
Operation: CP1SD/T/L Version Load Emulator The Load Emulator follows the Infrared Test LED. For each pulse of the Test LED, the Load Emulator increments one segment. The operation of the Load Emulator depends on the quantity being pulsed. If the quantity being pulsed is “Delivered-Only”, then the Load Emulator scrolls to the right when energy is being delivered and lights the left arrow when energy is being received. -
Page 48: Figure 23: Load Emulator Segment Progression For Received Power
Operation: CP1SD/T/L Version Figure 23: Load Emulator Segment Progression for Received Power Several uni-directional quantities are available. When these quantities are programmed to LED, both the LED and the load emulator will function for delivered and received quantities. CENTRON® Polyphase Meter Technical Reference Guide... -
Page 49: Power Circle Quadrants
Operation: CP1SD/T/L Version Power Circle Quadrants The following power circle diagram shows the quadrants for watts and vars delivered and received. The directional calculations in the CENTRON Polyphase meter are as follows:· • Watts delivered = (wattsQ1) + (wattsQ4)· • Watts received = (wattsQ2) + (wattsQ3)· •... -
Page 50: Test Mode Button
Operation: CP1SD/T/L Version Test Mode Button The Test Mode button is located at the 3 o'clock position under the meter cover. Pressing the button activates Test Mode. Test Mode is indicated by the “TEST” annunciator on the lower left of the LCD. Pressing the button a second time activates Test Alternate Mode, enabling the user to test a different energy quantity with the IR LED. -
Page 51: Power Down Procedures
Operation: CP1SD/T/L Version Power Down Procedures To de-energize all electronics, remove power from the meter. A power outage is recognized any time the line voltage drops 20 percent below the lowest nominal point of the voltage range. With a standard single phase power supply, a power outage occurs when line voltage drops below 96 volts;... -
Page 52: Interval Make-Up
Operation: CP1SD/T/L Version Interval Make-up Interval Make-up applies only to Load Profile meters. During power-up processing, the Load Profile component checks if the duration of the outage exceeds the configured minimum duration time. If it does, then at least one interval will be tagged with an outage status. -
Page 53: Test Mode Timeout
Operation: CP1SD/T/L Version To exit Test Mode, press the TEST button. The meter will change display mode to Test Alternate. Press the TEST button again. The LCD will display “nor diSP” signifying the exit of Test Mode and entry into Normal Mode operation. Test Mode Timeout If the meter is left in Test Mode, the meter will automatically exit after a user-configurable Mode Timeout. -
Page 54: Energy Data Display Items
Operation: CP1SD/T/L Version The following tables show items programmable for display in the modes indicated. All of the display items in the next two tables may be selected by TOU Rate. They also may be selected from the four Self Read buffers, the two Demand Reset Snapshot buffers, and Last Season Self Read buffer. -
Page 55: Instantaneous Data Display Items
Operation: CP1SD/T/L Version Display Mode Demand Data Display Item Normal Alternate Test Toolbox2 Var Received [lead: Q3+Q4] (Max, Present, Previous, Projected, Cumulative, Continuous Cumulative) Var Net VA Delivered [arithmetic or vectorial] (Max, Present, Previous, Projected, Cumulative, Continuous Cumulative) VA Received [arithmetic or vectorial] (Max, Present, Previous, Projected, Cumulative, Continuous Cumulative) VA Lag (Max, Present, Previous,... - Page 56 Operation: CP1SD/T/L Version Display Mode Informational Data Display Item Normal Alternate Test Toolbox4 Days Since Demand Reset Demand Reset Count Diagnostic Counters 1-5 Display On Time Firmware Revision Last Outage Date & Last Outage Time Last Program Date & Last Program Time Last Reset Date &...
-
Page 57: Magnetic Switch
Operation: CP1SD/T/L Version Display Mode Informational Data Display Item Normal Alternate Test Toolbox4 Time Remaining in Demand Subinterval Time Remaining in Test Mode TOU Expiration Date Transformer Ratio User Data 1-3 Voltage Transformer Ratio Magnetic Switch The magnetic switch enables scroll lock of display items as well as manual switching between display modes. -
Page 58: Alternate Display Mode
Operation: CP1SD/T/L Version Alternate Display Mode The Alternate Display Mode is functionally identical to the Normal Mode. The meter itself still operates under normal measurement, but the display sequence can be programmed to show a different set of displayable items from those in the Normal Display Mode. While in Alternate Display Mode, the “ALT”... -
Page 59: Test Display Mode
Operation: CP1SD/T/L Version All “PhA”, “PhB”, “PhC” quantities are displayed with a fixed decimal and no leading zeros. While displaying phase information, the load emulator cycles at a fixed rate in the direction of energy flow for that phase. The Load Emulator is not displayed while the diagnostic counters are displayed. -
Page 60: Test Alternate Display Mode
Operation: CP1SD/T/L Version Values calculated in Test Mode are not added to previous billing values or stored for retrieval. After exiting Test Mode, all billing data previously transferred to non-volatile memory is retrieved, an end-of-interval (EOI) is initiated, and a new demand interval begins. -
Page 61: Demand Registers
Operation: CP1SD/T/L Version Measured Energy Phases Directions Quantity Type delivered VA-hours (vectorial or arithmetic [RMS]) aggregate received lagging phase A phase B Volt-hours (Vh) phase C average phase A Amp-hours (Ah) phase B phase C aggregate aggregate delivered Q-hours aggregate received Demand Registers Demands can be calculated from any of the eight selected energy quantities. -
Page 62: Instantaneous Registers
Operation: CP1SD/T/L Version Instantaneous Registers The D/T/L Register is capable of displaying Primary or Secondary Instantaneous registers, with the following exceptions: Frequency, Power Factor (PF), and Phase Angles. The user can configure the CT and VT multipliers (transformer ratios) using PC-PRO+ Advanced programming software. -
Page 63: Programming
Operation: CP1SD/T/L Version Programming The software for programming this meter (PC-PRO+ Advanced) is a 32-bit Windows NT/2000/XP application. User-definable security codes in both the programming software and the meter prevent unauthorized access to the meter. Programming and/or interrogation of the meter can be accomplished through the optical port using a laptop PC and an optical probe. -
Page 64: Daily Patterns
Operation: CP1SD/T/L Version Daily Patterns Each pattern defines the times during the day that rate period A, B, C, or D begins and ends. Up to 24 rate period changes may be specified for each daily pattern. Day Types There are four day types: Weekday, Saturday, Sunday, and Holiday. Each day of the week is assigned to one of the four day types. -
Page 65: Rate Annunciators And Active Rate Indicators
Operation: CP1SD/T/L Version Rate Annunciators and Active Rate Indicators Rate annunciators are available with each demand and energy register. An A, B, C, or D will be displayed on the far right side of the LCD to indicate the rate period for each quantity being displayed. -
Page 66: Load Profile
32,767, MV-90 will record a negative number (received value) for that interval. Itron recommends programming any D/T/L Register with load profile that is interrogated by MV-90 or any system that exports load profile information to MV-90 to use 15 bit resolution or 32,767 pulses per interval. -
Page 67: Interval Lengths
Operation: CP1SD/T/L Version Interval Lengths The load profile records data on a block interval basis. The interval length is programmable for 1, 2, 3, 4, 5, 6, 10, 12, 15, 20, 30, or 60 minutes. The interval length is the same for all channels and is independent of the interval length for demand quantities. -
Page 68: Data Storage
Operation: CP1SD/T/L Version The maximum number of pulses is 65,535; therefore, the smallest pulse weight (PW) that can be used is: 1800 0275 Since the pulse weight value must be a multiple of 0.01 in the meter, 0.03 Wh could be programmed as the pulse weight (Ke) for the kWh channel in load profile in this example. -
Page 69: Recording Duration
The D/T/L Register has an Event Log that records historical events that have taken place in the meter. The events to be logged must be configured via the PC-PRO+ Advanced programming software. To aid in troubleshooting, Itron recommends enabling all events to be logged. - Page 70 Operation: CP1SD/T/L Version Each event log record includes an event description, a time and date stamp, and additional information on certain events. For meters with batteries, all logged events are retained through a power outage. For meters without batteries, the Event Log is periodically written to non-volatile memory. Events that occur just prior to a power outage may be lost depending on whether they were backed-up or not.
-
Page 71: Security Codes
Operation: CP1SD/T/L Version Security Pass—logon with security code succeeded SiteScan Error—a SiteScan error occurred Test Mode Entered—Test Mode or Alternate Test Mode was entered Test Mode Exited—Test Mode or Alternate Test Mode was exited Time Changed—a time adjustment forward or backward occurred TOU Schedule Error—see Non-fatal Error 3 for description Security Codes The meter security codes provide protection for meter register and load profile data. -
Page 72: Implementing Security Codes
Operation: CP1SD/T/L Version Implementing Security Codes When a customer file is created, security codes are entered by the software (PC-PRO+ Advanced) operator. Each security code may be from 1 to 20 characters long. For example, the primary code is selected to be ABC and the secondary code is to be 123. When the software first attempts to communicate with a meter that has just been delivered from the factory, the meter has only null security codes. -
Page 73: Firmware Upgrades
You must install the D/T/L Register firmware on your computer to make it available to PC-PRO+ Advanced. You can obtain firmware upgrades through your Itron, Inc. Sales Representative. You can install only one version of D/T/L Register firmware on a computer. -
Page 74: Sitescan On-Site Monitoring System
SiteScan system and installation diagnostic checks Diagnostic output alarms Using the Itron, Inc. PC-PRO+ Advanced Programming software package you can customize the SiteScan System for each individual metering site. The use of the SiteScan on-site monitoring system greatly enhances the ability to diagnose and resolve site-specific metering or tampering problems. -
Page 75: Sitescan Meter Self-Diagnostic Checks
Operation: CP1SD/T/L Version SiteScan Meter Self-Diagnostic Checks The CENTRON Polyphase meter performs self-diagnostic checks to confirm proper meter operation. The following is a list of possible errors and associated error codes: Error Error Type Error Code Flash Error Fatal Error Error1 Error2 RAM Error... -
Page 76: Figure 25: Toolbox Phase Notation For Form 9S And 16S Centron Polyphase Meters
Operation: CP1SD/T/L Version The PC-PRO+ Advanced software lets the user retrieve Toolbox information (the same information available by accessing the display list through the use of a magnet and magnetic switch) on an instantaneous basis with a graphical vector diagram. To best understand the values on the Toolbox display, one should graphically plot this information. -
Page 77: Figure 26: Plot Of Toolbox Display Mode
Operation: CP1SD/T/L Version Definition 2: The SiteScan system uses the A phase voltage as a reference point. Therefore, the Toolbox Mode display of the A phase voltage angle will always be 0.0°V. The CENTRON Polyphase meter is still determining this angle and will still detect a problem if the A phase voltage angle is incorrect. - Page 78 Operation: CP1SD/T/L Version The following is an example of the data available in the Toolbox Mode. This example is for a Form 9S meter wired for a 4-Wire Wye system: Phase A Display Phase B Display Phase C Display (Left Element) (Center Element) (Right Element) Voltage Phase...
-
Page 79: Sitescan System And Installation Diagnostic Checks
Operation: CP1SD/T/L Version SiteScan System and Installation Diagnostic Checks The SiteScan on-site monitoring system has the ability to continuously monitor the site for metering installation or tampering problems through the system and installation diagnostic checks. The following software programmable diagnostic checks are available: SiteScan Diagnostic #1 Cross-Phase, Polarity &... - Page 80 Operation: CP1SD/T/L Version The system reports diagnostic errors in several ways. If a diagnostic check is enabled and an error occurs, the system will always increment the corresponding diagnostic counter by one. The range for all diagnostic counters is from 0 to 255. When the counter reaches 255, it remains there until it is reset by the user.
-
Page 81: Figure 27: Form 9S Centron Polyphase Meter 4-Wire Delta Phasor Diagram
Operation: CP1SD/T/L Version Load Line (CBA Rotation) Expected vector diagram at unity power factor with load connected line-to-neutral Figure 27: Form 9S CENTRON Polyphase Meter 4-Wire Delta Phasor Diagram CENTRON® Polyphase Meter Technical Reference Guide... -
Page 82: Figure 28: Form 9S Centron Polyphase Meter 4-Wire Wye Phasor Diagram
Operation: CP1SD/T/L Version Load Line (ABC Rotation) Figure 28: Form 9S CENTRON Polyphase Meter 4-Wire Wye Phasor Diagram CENTRON® Polyphase Meter Technical Reference Guide... -
Page 83: Figure 29: Form 16S Centron Polyphase Meter 4-Wire Delta Phasor Diagram
Operation: CP1SD/T/L Version Line Load (CBA Rotation) Figure 29: Form 16S CENTRON Polyphase Meter 4-Wire Delta Phasor Diagram CENTRON® Polyphase Meter Technical Reference Guide... -
Page 84: Figure 30: Form 16S Centron Polyphase Meter 4-Wire Wye Phasor Diagram
Operation: CP1SD/T/L Version Line Load (ABC Rotation) Expected vector diagram at unity power factor with load connected phase-to-neutral Figure 30: Form 16S CENTRON Polyphase Meter 4-Wire Wye Phasor Diagram CENTRON® Polyphase Meter Technical Reference Guide... -
Page 85: Sitescan Diagnostic #1
Operation: CP1SD/T/L Version SiteScan Diagnostic #1 The purpose of this diagnostic is to verify that all meter elements are sensing and receiving the correct voltage and current for each phase. This diagnostic may indicate one or more of the following problems: Cross-phasing of a voltage or current phasing Incorrect polarity of a voltage or current circuit Reverse energy flow of one or more phases... - Page 86 Operation: CP1SD/T/L Version A multitude of wiring conventions, phase loadings, and power factors can exist at metering sites. Therefore, the vector diagrams obtained from actual metering sites will most likely vary from those shown here. This should be expected and will cause no metering errors, but some unusual circumstances could necessitate reconfiguration of one or more of the diagnostics.
-
Page 87: Sitescan Diagnostic #2
Operation: CP1SD/T/L Version Figure 31: Diagnostic #1 Error Diagram By comparing the phasor diagram drawn from the information found in the snapshot with the typical phasor diagram, it becomes clear that the B phase voltage is incorrect. The correct phasor should be around 120°, not 300° where the phasor currently is. Since the phasor is approximately 180°... -
Page 88: Phase Voltage Deviation Check
Operation: CP1SD/T/L Version Phase Voltage Deviation Check Once every five seconds, the phase A voltage is combined with a user-defined percentage tolerance (x) to determine the upper and lower bounds of the acceptable range for the other voltages. The range of values for the percent tolerance is 1 to 25. For Diagnostic #2 to pass, the following equations must be satisfied: ≤... -
Page 89: Sitescan Diagnostic #3
Operation: CP1SD/T/L Version By using the equations above and substituting in the voltages for the upper and lower limits, one can also see why the diagnostic check has failed. For Diagnostic #2 to pass, the following equations must be satisfied: <... - Page 90 Operation: CP1SD/T/L Version Refer to the PC-PRO+ Advanced documentation for instructions on how to program this value into the CENTRON Polyphase meter. Diagnostic #3 Error Example This example is for a Form 9S meter wired for a 277 volt, 4-Wire Wye system, but the site has a shorted current transformer.
-
Page 91: Sitescan Diagnostic #4
Operation: CP1SD/T/L Version SiteScan Diagnostic #4 The purpose of this diagnostic is to verify that the current elements are sensing and receiving the correct current for each phase. It is basically a power factor check diagnostic. This diagnostic check may indicate one or more of the following problems: Poor load power factor conditions Poor system conditions Malfunctioning system equipment... -
Page 92: Figure 32: Envelope Example
Operation: CP1SD/T/L Version An example would be if a typical diagram has the C phase current angle at 240° and the user has programmed an acceptable envelope of ±45° around that phasor, then the actual current phasor must be between 195° to 285° from VA for the diagnostic to pass that check. The system will check each current phasor in a similar fashion. -
Page 93: Sitescan Diagnostic #5
Operation: CP1SD/T/L Version The next step is to graphically plot the above information into a phasor diagram as shown in the figure below. Figure 33: Phasor Diagram By comparing the phasor diagram drawn from the information found in the snapshot versus the typical phasor diagram, it becomes clear that the C phase current is out of the user- defined envelope. -
Page 94: Current Waveform Distortion Check
Operation: CP1SD/T/L Version Current Waveform Distortion Check Diagnostic #5 detects DC on a per-phase basis using what is know as a comb filter method. Rectified loads produce even harmonics which are typically in phase with the voltage signal. The algorithm works by summing current samples, which occur 90° after every zero crossing of the voltage waveform. -
Page 95: Testing, Troubleshooting, And Maintenance
Operation: CP1SD/T/L Version Phase A Display Phase B Display Phase C Display (Left Element) (Center Element) (Right Element) %TDD I 0.010 0.500 0.500 Diagnostic Counters The snapshot data indicates that there was harmonic distortion on Vb. Also note that the diagnostic counter d6 has incremented to 1. -
Page 96: Load Indication/Direction Annunciator
Operation: CP1SD/T/L Version Load Indication/Direction Annunciator The CENTRON Polyphase meter is equipped with a Liquid Crystal Display (LCD) load emulation indicator. The Load Emulator follows the Infrared Test LED. For each pulse of the Test LED, the Load Emulator increments one segment. The operation of the Load Emulator depends on the quantity being pulsed. -
Page 97: Nominal Voltage Indication Annunciator
Operation: CP1SD/T/L Version Nominal Voltage Indication Annunciator The CENTRON Polyphase meter is equipped with a nominal voltage indication annunciator. This annunciator indicates the voltage value to which the nominal voltage is nearest. Nominal voltage indication values are 120, 240, 277, and 480. Test Mode Annunciator The CENTRON Polyphase meter is equipped with a Test Mode LCD annunciator. -
Page 98: Testing Using The Load Indication Annunciator
If accuracy or repeatability is poor, the Kh may be incorrect or the “settling time” in the test bench must be adjusted. (Itron recommends a 4–5 second settling time.) Testing Using the Load Indication Annunciator The CENTRON Polyphase meter is capable of visually being tested by using the load emulation annunciator shown in Load Indication/Direction Annunciator. -
Page 99: Recommendations
Operation: CP1SD/T/L Version The current ramps (directly or through zero) to the LL current level at unity power factor. A pulse from the meter starts the LL test and another pulse ends it. Most test boards use jogging (slewing) immediately following a FL or PF test to shorten the time required for the next test to start. -
Page 100: Demand Testing
Operation: CP1SD/T/L Version Solution 3 Install the latest test board software revision. A test board ideally should recognize no new test pulses after the completion of a test until jogging, ramping, and settling time have all transpired. Settling time should be programmed for three to six seconds. There is nothing to be gained by using settling times greater than six seconds. -
Page 101: Demand Test Method
Operation: CP1SD/T/L Version Demand Test Method Connect the meter under test and the reference standard in the same circuit with all voltage coils in parallel and current coils in series as per standard meter testing procedures. Figure 35: Test Connections Apply rated voltage to the meter under test and the reference standard. -
Page 102: Demand Calculations
Operation: CP1SD/T/L Version Meter Single Phase Test Constants (SPTC) A Phase B Phase C Phase Form Series Only Only Only 9 or 16 3Ø, 3W, 0.911 .866 .0866 9, 16, or 14 3Ø, 4W, wye This test method is valid for kWh, kVAh, kvarh, kW, kVA, and kvar at any load or power factor. -
Page 103: Field Testing
Operation: CP1SD/T/L Version where: N = Coil factor (See Testing With the Infrared Test LED) SPTC=Single phase test constant (See the table in Demand Test Method) Calculation D: Actual kVA Demand kVA = kVAh x 60/T where: T = Test Mode demand interval length in minutes Field Testing Field testing of the CENTRON Polyphase meter may be accomplished with conventional methods using either the infrared test pulses or the load emulation annunciator. -
Page 104: Troubleshooting
Operation: CP1SD/T/L Version Troubleshooting Typically, meters are placed in a very unfriendly environment. While the CENTRON Polyphase meter is designed to perform within this harsh environment, things can go wrong with the meter or installation. Fatal Errors Fatal errors cause the display to lock on the error code because of the possibility that billing data may have been corrupted or that the meter may not be operating correctly. -
Page 105: Non-Fatal Errors
Operation: CP1SD/T/L Version Fatal Errors Error Code Error Possible Cause Error Description Error4 Front A problem has If the meter detects this occurred with the problem, return the meter for Process metrology portion of repair. or Error the meter. Error5 Power A problem has The billing data has been... - Page 106 Operation: CP1SD/T/L Version Non-Fatal Errors Error Code Error Possible Cause(s) Error Description Err 1----- Battery Voltage A low battery check is Battery performed once a day and Error upon a set clock procedure. If Battery Not a low battery is detected, the Connected condition will remain until the Properly...
- Page 107 Operation: CP1SD/T/L Version Non-Fatal Errors Error Code Error Possible Cause(s) Error Description Err ---4-- Reverse The configured Reverse power is tested every Power reverse power second and an accumulator Flow Error threshold has for it is maintained. If power is been reached delivered during the second, then the accumulator is...
-
Page 108: Other Problems
Operation: CP1SD/T/L Version Non-Fatal Errors Error Code Error Possible Cause(s) Error Description Err - 9--- SiteScan SiteScan auto This is tested after the power- Error service up delay time has expired detection could following a power-up, an exit not determine Test mode and a reconfigure the meter's of SiteScan configuration data. - Page 109 Operation: CP1SD/T/L Version Time and Date Wrong (TOU Version) Time/Date Wrong in PC or Handheld Device—Verify and update time/date in programming device and download new time and date to meter. Refer to the appropriate software manual for more detailed directions. Wrong Line Frequency—Verify proper line frequency is selected in setup routine in programming software.
-
Page 110: Maintenance
Discard the battery using proper hazardous waste procedures. Corrective Maintenance Because of the high level of integrated packaging and surface-mount components, on-board component repairs are not recommended. The entire meter should be returned to Itron, Inc. Customer Service for repair. CENTRON® Polyphase Meter Technical Reference Guide... -
