2. Button Operations

Button Function
Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to
turn on the UPS.
Mute the alarm: After the UPS is turned on and in battery mode, press and
hold this button for at least 3 seconds to disable or enable the alarm system.
ON/Mute
(N/A for warnings or errors)
Button
Up key: Press this button to display previous selection in UPS setting mode.
Self-test mode: Press ON/Mute buttons for 3 seconds to enter UPS
self-testing while in AC mode, ECO mode, or converter mode.
Turn off the UPS: Press and hold this button at least 2 seconds to turn off
the UPS. The UPS will be in standby mode under power normal or transfer to
OFF/Enter
Bypass mode if the Bypass setting is enabled.
Button
Confirm selection key: Press this button to confirm selection in UPS
setting mode.
Switch LCD message: Press this button to change the LCD message for
input voltage, input frequency, input current, battery voltage, battery
current, battery capacity, ambient temperature, output voltage, output
frequency, load current and load percent.
Select
Button
Setting mode: Press and hold this button for 3 seconds to enter UPS
setting mode when in Standby and Bypass mode.
Down key: Press this button to display next selection in UPS setting mode.
Switch to bypass mode: When the main power is normal, press ON/Mute
and Select buttons simultaneously for 3 seconds and the UPS will enter
bypass mode. This will not function if the input voltage is out of range.
ON/Mute
+ Select Exit setting mode or returning to the last menu: In setting mode,
Button press the ON/Mute and Select buttons simultaneously for 0.2 seconds to
return to the upper menu. Once in the main menu, exit settings mode by
pressing these two buttons simultaneously.

2.1 LCD Panel
