  • Page 1 UPS2URM3000DC-NC-1N User Guide...
  • Page 2: Rear Panel View

    IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS - This manual contains important instructions that should be followed during installation and maintenance of the UPS and batteries. 1. Rear Panel View NOTE: Before installation, please inspect the unit for shipping damage. NEMA TYPE 1.
  • Page 3: Rack-Mount Installation

    1.2 Installation For safety consideration, the UPS is shipped out from factory without connecting battery wires. Before installation of the UPS, please follow the steps below to re-connect the battery wires. Rack-Mount Installation Caution! – DO NOT use the mounting brackets to lift the unit. The mounting brackets are only for securing the unit to the rack.
  • Page 4: Ups Output Connection

    1.3 Setup 1. Select a proper location to operate the UPS • The UPS should only be operated indoors in a clean environment, away from windows and doors. Place on a flat surface away from dust, humidity, high temperatures, liquids, gases, or corrosive and conductive contaminants.
  • Page 5 There are two kinds of outputs: programmable outlets and general outlets. Connect non-critical devices to the programmable outlets and critical devices to the general outlets. During power failure, you may extend the backup time to critical devices by setting shorter backup time for non-critical devices.
  • Page 6: Install Software

    1.4 Internal Battery Replacement Note: This UPS is equipped with internal batteries and only a trained technician should replace the batteries. Replace with V7 Replacement Battery Cartridge RBC1RM2U3000V7 Replace the batteries if icons are flashing in the LCD display and alarm is sounding every 2 seconds.
  • Page 7 CAUTION - A battery can cause a risk of electrical shock and high short-circuit current. Contact with any part of a grounded battery can result in electrical shock. Observe the following precautions when working with batteries: • Remove watches, rings, or other metal objects. •...
  • Page 8: Button Operations

    2. Button Operations Button Function Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS. Mute the alarm: After the UPS is turned on and in battery mode, press and hold this button for at least 3 seconds to disable or enable the alarm system. ON/Mute (N/A for warnings or errors) Button...
  • Page 9 Function Display Backup time information Indicates the estimated backup time. H: hours, M: minute, S: second. Configuration and fault information Indicates the configuration items. Configuration items are listed in detail in section 2-5. Indicates the warning and fault codes. Codes are listed in detail in sections 2-7 and 2-8.
  • Page 10: Audible Alarm

    2.2 Audible Alarm Battery Mode Sounds every 5 seconds Low Battery Sounds every 2 seconds Overload Sounds every second Fault Continuously sounding Bypass Mode Sounds every 10 seconds 2.3 LCD display wording index Abbreviation Display content Meaning Enable Disable Escape High loss Low loss Active open...
  • Page 11: Ups Setting

    2.4 UPS Setting There are two parameters to set up the UPS. Parameter 1 Parameter 2 Parameter 1: Program alternatives. Refer to below table. Parameter 2: Setting options or values for each program. 01: Output voltage setting Interface Setting Parameter 2: Output voltage For 100/110/115/120/125/127VAC models, you may choose the following output voltage: 100: presents output voltage is 100VAC...
  • Page 12 05: ECO voltage range setting Interface Setting Parameter 2: Set the acceptable high voltage point and low voltage point for ECO mode by pressing Down key or Up key. HLS: High loss voltage in ECO mode in parameter 2. For 100/110/115/120/125/127VAC models, the setting range in parameter 3 is from +3V to +12V of the nominal voltage.
  • Page 13 49Hz. (Default: 47Hz) For 60Hz output frequency models: 55-59Hz: Set the frequency low loss point from 55Hz to 59Hz. (Default: 57Hz) 09: Programmable outlets enable/disable Interface Setting Parameter 2: Enable or disable programmable outlets. ENA: Programmable outlets enable DIS: Programmable outlets disable (Default) 10: Programmable outlets setting Interface Setting...
  • Page 14 13: Maximum charger current setting Interface Setting Parameter 2: Set the charger maximum current. 1/2/4/6/8: Set the charger maximum current 1/2/4/6/8 in Ampere. (Default: 2A) Note: Set the appropriate charger current based on battery capacity used. The recommended charging current is 0.1C~0.3C of battery capacity as following table for reference.
  • Page 15: Operating Mode Description

    18: Display setting for autonomy time Interface Setting Parameter 2: Set the display setting for autonomy time EAT: If EAT is selected, it will display the remaining autonomy time. (Default) RAT: If RAT is selected, it will show accumulated autonomy time so far.
  • Page 16: Warning Indicator

    2.6 Faults Code Reference Fault event Fault code Icon Fault event Fault code Icon Bus start fail Battery voltage too high Bus over Battery voltage too low Bus under Charger output short Inverter soft start fail Over temperature Inverter voltage high Overload Inverter voltage Low Charger failure...
  • Page 17 Fault code 27 is displayed on the Battery voltage is too high Contact your reseller or LCD and the alarm is continuously or there is a charger fault. techsupport@v7-world.com sounding. Fault code 28 is displayed on the Battery voltage is too low Contact your reseller or LCD and the alarm is continuously or there is a charger fault.
  • Page 18: Storage And Maintenance

    The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. Contact your reseller or techsupport@v7-world.com. Be sure to deliver the spent battery to a recycling facility or ship it to your dealer in the replacement battery packing material.
  • Page 19: Specifications

    5. Specifications MODEL (VPN) UPS2URM3000DC-NC-1N CAPACITY* 3000VA / 2740W INPUT 80VAC/70VAC/60VAC/55VAC ± 5 % Low Line Transfer (based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
  • Page 20: Runtime Chart

    6. Runtime Chart UPS2URM3000DC-NC-1N Model (VPN) Battery Minutes Load percentage 100.00% 2.64 90.00% 3.36 80.00% 4.34 70.00% 5.53 60.00% 7.33 50.00% 9.79 40.00% 13.51 30.00% 19.90 20.00% 32.61 10.00% 72.53 7. Instructions & Safety Warnings 7.1 Transportation Transport the UPS system only in the original package to protect from damage.
  • Page 21: Operation

    FOR PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and shall be easily accessible. CAUTION: The unit is heavy. Lifting the unit requires a minimum of two people. 7.4 Operation Do not disconnect the mains cable on the UPS system or the building wiring outlet (shockproof socket outlet) during operations since this would cancel the protective earthing of the UPS system and of all connected loads.
