Summary of Contents for Yealink CP935W
-
Page 1: Table Of Contents
Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Requirements 2.1 Identifying phone model 2.2 Phone firmware 2.3 DHCP server 2.4 PBXware version 3 Installation 3.1 Power adapter 3.2 Find the phone IP address 3.3 Reset to factory settings 4 Registering phone 4.1 Manual configuration... -
Page 2: Requirements
Make sure that your phone is loaded with appropriate firmware version, 148.86.0.5. To find out the firmware version of your Yealink phone model open a new browser window and enter your phone IP address in order to access the phone web administration interface login screen. -
Page 3: Dhcp Server
Connect the Network and Power Connect the charging cradle to the phone to charge the CP935W device. Yealink CP935W is a wireless touch-sensitive HD conference phone, you can register a SIP account directly through Wi-Fi. Find the phone IP address Find out your Yealink phone IP Address. -
Page 4: Registering Phone
Do not unplug or remove power to the phone while it is updating firmware and configurations. Registering phone This chapter describes how to identify Yealink phone model, requirements that must be met and how to register the phone using manual configuration or auto provisioning. The following topics are covered:... - Page 5 Navigate to Settings:UAD. Make sure Yealink UAD is enabled. To check the UAD status click on the edit icon corresponding to your Yealink phone. Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
- Page 6 Registering Phone This chapter describes how to register Yealink phone using Hostname or IP Address. The following topics are covered: Hostname or IP Address Hostname or IP Address Login to phone web administration interface Open a new browser window and enter your phone IP address in order to access the phone web administration interface login screen.
-
Page 7: Auto Provisioning
UAD settings. Navigate to Settings:UAD. Make sure Yealink UAD is enabled. To check the UAD status click on the edit icon corresponding to your Yealink phone. Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes. - Page 8 Enter Yealink phone MAC address. Example: 001565FF1536. MAC address can be found at the back of the phone. Click on the Save button. Registering Phone This chapter describes how to register Yealink phone using DHCP, TFTP, HTTP & HTTPS. The following topics are covered: DHCP TFTP or HTTP & HTTPS...
- Page 9 DHCP Configure DHCP Make sure your DHCP router is configured to use option 66 to automatically instruct phones with the URL for auto provisioning. For more information refer to your router documentation or contact your network administrator. Phone first boot or user initiated reboot Auto provisioning process will start during phone first boot or after reboot process has been initiated by user.
-
Page 10: Using Tls
Example for IP Address USING HTTPS: https://192.168.1.10/prov Enter Auto Provisioning username and password into Username and Password fields. If you choose to use server type TFTP enter tftp:// followed by Hostname or IP Address Example for Hostname: tftp://voip.bicomsystems.com Example for IP Address: tftp://192.168.1.10 Click on Confirm button. -
Page 11: Additional Configuration Template
Additional Configuration Template If You want to include some additional UAD configuration for Yealink CP935W, just add fields to User Agent General Auto Provisioning Template in Settings -> UAD -> Yealink CP935W menu, or add them directly to the extension in UAD Auto Provisioning Template section.
