- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com HT-ATLAS BYOD Conference Speakerphone with presentation switch and wireless casting User Manual Version: 1.0 Hall Technologies August 22, 2022 Page 1 of 30...
- Page 2 8. Protect the power cord from being walked on or pinched particularly at plugs. 9. Only use attachments / accessories specified by the manufacturer. Refer all servicing to qualified service personnel. Hall Technologies August 22, 2022 Page 2 of 30...
-
Page 3: Table Of Contents
Welcome Menu – Custom Web UI Logo ................25 Guide Screen ........................25 Firmware Upgrade ....................... 26 System ................. 26Error! Bookmark not defined. Firmware Version ..............26Error! Bookmark not defined. Troubleshooting ..........................27 Specifications ..........................28 Hall Technologies August 22, 2022 Page 3 of 30... -
Page 4: Introduction
Ÿ Auto detects source status to send power on/off command to sink display. Ÿ Plug and Play compatibility for Window, Mac OS, and Android, also UC platforms like Zoom, WebEx, Teams, etc. Hall Technologies August 22, 2022 Page 4 of 30... -
Page 5: Package Contents
Ÿ 1 x AC Power Cord with AU Pins Ÿ 1 x USB Type C to Type C Cable with Type C to USB 3.0 Type A Adapter Ÿ 1 x Cable Fixing Bar (with Screws) Hall Technologies August 22, 2022 Page 5 of 30... -
Page 6: Panel Description
Panel Description Hall Technologies August 22, 2022 Page 6 of 30... - Page 7 USB PD: 60W Max USB-C Connect to a USB-C video source (e.g. laptop) for video input using the USB Type C cable provided. You can also use either of the following suggested cables: Hall Technologies August 22, 2022 Page 7 of 30...
-
Page 8: Applications
(Using Web UI or API commands to switch the scenario, refer to “Web UI” section or the separate document “API Command Set HT-ATLAS”. Note: After the speakerphone is connected to a laptop with the cable provided, it can be detected by the system and specific applications with the following name: •... -
Page 9: Key Functions
• When remove the source selected currently: Firstly, check the last selected wired source, if it is active, the device will switch to the source and show it on the screen. Hall Technologies August 22, 2022 Page 9 of 30... -
Page 10: Screen Mirroring
ð Soft AP SSID: as same as the device name and can be obtained from OSD at the upper right of the display screen. By default, it is set as HT-ATLAS. ð Password: set through Web UI or Telnet API and can be obtained from OSD at the bottom right of the display screen. - Page 11 3. The display device displays your iPhone’s screen. 4. To disconnect iPhone from the device: click Stop Mirroring, the display stops displaying your iPhone’s screen. Hall Technologies August 22, 2022 Page 11 of 30...
-
Page 12: Screen Mirroring Over Miracast
3. Screen mirroring Miracast For Windows 10 PC: 1. Enable the WLAN feature of your PC. 2. Click the icon on bottom right of the screen to open Action Center. Hall Technologies August 22, 2022 Page 12 of 30... - Page 13 3. Click Connect. Hall Technologies August 22, 2022 Page 13 of 30...
-
Page 14: Screen Mirroring Over Ht-Voyager
The Guide Screen can be personalized to allow custom connection instructions on the device’s Web UI page. When all video sources are disconnected from the device, the Guide Screen appears on the display screen automatically as following. Hall Technologies August 22, 2022 Page 14 of 30... -
Page 15: Osd
The device supports OSD (On Screen Display) to convey device basic information, including video source’s information, access code, device name and IP address, etc. Here are two different OSD examples in different scenarios. Example 1: Full Screen Mode: Hall Technologies August 22, 2022 Page 15 of 30... - Page 16 Example 2: Split Screen Mode: Hall Technologies August 22, 2022 Page 16 of 30...
-
Page 17: Web Ui
IP address. 2. Connect the PC to the same network as the device. 3. Input the device’s IP address in the browser and press Enter, the following window pops up. Hall Technologies August 22, 2022 Page 17 of 30... -
Page 18: General Page
Redefine the device name to names easy to remember. Device Name Note: The name must be 1~20 characters in length, including letters, numbers, “_” or “-”. Apply Click to perform settings. NETWORK Hall Technologies August 22, 2022 Page 18 of 30... -
Page 19: Wi-Fi Settings
Configure the wireless channel for the device. Channel By default, it is set as Auto. Auto means the device select a wireless channel automatically for itself. Apply Click to perform settings. Hall Technologies August 22, 2022 Page 19 of 30... -
Page 20: Soft Ap
• Off: Disable the device’s BYOD feature. Enter a four-digit access code to help prevent users from accidentally connecting Access Code to an unintended device and protect from an unauthorized access. Hall Technologies August 22, 2022 Page 20 of 30... -
Page 21: Cec
Enter the CEC Display Off command of a controlled display device and click “Save”. For more information about the command, see the user guide of your Display Off display devices. By default, it’s set as blank. Hall Technologies August 22, 2022 Page 21 of 30... -
Page 22: Standby
If it’s set to 0 minute, it means this function is disabled, you cannot set the device to standby mode. By default, auto standby is set as 1 minute. Apply Click to perform settings. Video HDMI OUT RESOLUTION Hall Technologies August 22, 2022 Page 22 of 30... -
Page 23: Output Hdcp
By default, it's set as Follow. VIDEO MUTE UI Element Description On: Set video mute on. Ÿ Video Mute Ÿ Off: Set video mute off. By default, it's set as Off. Hall Technologies August 22, 2022 Page 23 of 30... -
Page 24: Manage Alias
Video Source Displays the video source name. Alias Enter a name to change the video source name to a new one. Apply Click to perform the current settings. Advanced Settings APPLICATION MODE Hall Technologies August 22, 2022 Page 24 of 30... -
Page 25: Login Password
Perform networking according to application 1 or application 2, and click to select either of them. Source Status Shows the current selected source name. LOGIN PASSWORD UI Element Description Login Password Set a new login password. Hall Technologies August 22, 2022 Page 25 of 30... -
Page 26: Lock Button
Set a new picture for Guide Screen. Click to upload the picture file to the device. Upload Note: The picture must be in jp(e)g format that has 1920 x 1080 pixels. Hall Technologies August 22, 2022 Page 26 of 30... -
Page 27: Firmware Upgrade
Note: You can also perform this task by sending the API command “gbcontrol -- reset-to-default”. For more information, see the separate API document. Reboot Click to restart the device. FIRMWARE VERSION Firmware version shows the current firmware in use. Hall Technologies August 22, 2022 Page 27 of 30... -
Page 28: Troubleshooting
Answer: to check if the Mic of HT-ATLAS is in Mute mode (in Mute mode the circle indicator on control panel is light up red). 5. When the HDMI in port of HT-ATLAS connect a PC to use, the Speaker and Mic function can't be activated, how to check? Answer: to check if you have connected the USB A - USB Mini cable between HT-ATLAS and the PC which connected the HDMI in port on HT-ATLAS. -
Page 29: Specifications
DC 24V 5A Charging via Type-C Port 60W (Max) Power Consumption 89W (Max) Device Dimension (W x H x D) 267.3mm x 105.5mm x 232mm/10.52” x 4.15” x 9.13” Product Net Weight 1.06kg/2.33lbs Hall Technologies August 22, 2022 Page 29 of 30... - Page 30 © Copyright 2022. Hall Technologies All rights reserved. 1234 Lakeshore Drive, Coppell, TX 75019 halltechav.com / support@halltechav.com (714)641-6607 Hall Technologies August 22, 2022 Page 30 of 30...
