Installation manual
Model : PHT-75CHS
Version : 1.10
English

Advertisement

Table of Contents
loading

Related Manuals for Vatech Green X

Summary of Contents for Vatech Green X

  • Page 1 Installation manual Model : PHT-75CHS Version : 1.10 English...
  • Page 3 A thorough review of this manual is recommended to ensure the proper installation of this equipment. The information in this manual may be subject to change without notice, justification, or notification of the persons concerned since the Green X / X18 is in steady improvement.

  • Page 4: Important Notes

    Do not push or pull the equipment.  Failure to read and understand this manual may result in physical injuries, equipment malfunctions, or damage to the equipment. Please read the information in each chapter before starting the installation. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 5: Table Of Contents

    Checking the Parts and Accessories ..........33 Installing the X-ray Unit: Base Stand Type Attaching the Base to the X-ray Unit ..........39 Installing the CEPH Unit (Optional) ........... 46 Installing the Wall and Column Brackets .......... 50 Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 6 Before Beginning ................93 Turning off the Firewall ..............94 Changing the Power Settings ............95 Turning off the User Account Control ..........97 Setting Folder Exclusions with Anti-virus Software ......98 Installing Software Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 7 Installing the Emergency Stop Switch ..........4 Limiting the Column Height ..............5 Connecting the 3rd Party Exposure Switch (Optional) ......9 Checking PC BIOS Settings ..............10 Installation Checklist ................. 11 Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 9: Introduction

    1. Introduction Introduction Manufacturer's Liability As the manufacturer, VATECH assumes liability for the safe and reliable installation and operation of this equipment only when: Equipment installation, including software installation, was conducted by an  authorized agent by this installation manual.

  • Page 10: Conventions In This Manual

    Using this Manual  Notes to emphasize or clarify a point.  Indicates a possible danger from radiation RADIATION exposure. Indicates that an item is susceptible to damage from electrostatic discharges. susceptibility Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 11 Do not step on the base when installing or operating the equipment. Do not use the electric drill to tighten bolts because this can damage the bolts. Ensure to use the drill for drilling the wall only. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 12: Installing The Emergency Stop Switch

    When transporting the equipment, hold the handles in marked locations. Three installers are required for safe installation. Check the location of the emergency stop switch as indicated below: Check the location of the main power switch as indicated below: Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 13 Use an ESD (electrostatic sensitive device) wristband  during installation and connect it to a ground wire. Touch a ground point to discharge static electricity  before handling PCB boards. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 14 Any equipment not provided by VATECH can be  connected when the following standards have complied with IEC 60950-1 and IEC 60601-1 The electrical installation shall comply with local code  requirements for electro-medical systems: IEC 60364- 7-710: 2002. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 15: Marks And Symbols

    The CE symbol indicates that this product complies with the European Directive for Medical Label Devices 93/42/EEC as amended by 2007/47/EC as a class IIb device. MCU board / Warns ESD hazard. Board package Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 16: Pre-Installation Requirement

    The PC monitor, emergency stop switch, and X-ray  exposure switch must be installed near the operator to manage them simultaneously in an emergency. <Without CEPH Unit (optional): 2,500 mm (L) x 1,700 mm (W) or wider > Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 17 2. Pre-Installation Requirement <With CEPH Unit (optional): 2,500 (L) x 2,500 mm (W) or wider > Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 18 2. Pre-Installation Requirement <Ceiling Height: 2,700 mm (H) or higher > Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 19 2,000 mm (78.7’) from the source of the radiation. Maintain visible contact with the patient and a clear view of indicators such as the  warning lamp and imaging status on the PC. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 20: Electrical Installation Requirement

    It is strongly recommended that you install an AVR. An AVR (automatic voltage regulator) maintains a constant voltage and allows for continuous operation during power fluctuation. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 21: Installing Exposure Switch

    The user operates the Exposure Switch from inside the X-ray room. Option No. 2: The user operates the Exposure Switch from outside the X-ray room. The Exposure Switch holder is mounted on the wall. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 22 2. Pre-Installation Requirement Option No. 3: party Exposure Switch (not VATECH’s) is used on the customers' demand. The 3 For this scenario, see Appendix D for details. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 23: Installation Versions

    2. Pre-Installation Requirement Installation Versions 2.5.1 Green X Base-Stand Type (With CEPH unit) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 24 2. Pre-Installation Requirement Base-Stand Type (Without CEPH unit) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 25 2. Pre-Installation Requirement Wall-Mount Type (With CEPH unit) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 26 2. Pre-Installation Requirement Wall-Mount Type (Without CEPH unit) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 27 2. Pre-Installation Requirement 2.5.2 Green X18 Base Stand Type (With CEPH unit) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 28 2. Pre-Installation Requirement Base Stand Type (Without CEPH unit) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 29 2. Pre-Installation Requirement Wall-Mount Type (With CEPH unit) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 30 2. Pre-Installation Requirement Wall-Mount Type (Without CEPH unit Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 31: Installing The Warning Lamp And Door Interlock Switch

    Install the emergency stop switch along with the main power cable in the  central distribution panel. Install this switch within easy reach of the operator but cannot be  accidentally pressed. The switch must be a fool-proof model.  Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 32: Before The Installation

    Tips: 3 mm - 8 mm Ratchet Wrench (0.12” - 0.3”) Needle-nose Pliers Regular Monkey Wrench Cross Head Screwdriver w/ L = 200 mm (7.9”) Magnetic Tip Spirit Level Anti-Static Glove Knife Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 33 L = 200 mm (7.9”) (for Wall Mount type) Transport Dolly Go to checklist no.3 through no.4 in Appendix F to check if all pre-installation conditions are met before installing the equipment. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 34: Checking The Conditions Of The Shock And Tilt Watches

    If the shock or tilt watch has turned red, do not open the box and contact the nearest VATECH representative in your area. The shock and tilt watch locations are the same for Green X and Green X18. To check the conditions of shock and tilt watches:...

  • Page 35: Unpacking The X-Ray Unit

    Assembly 1780 (L) x 780 (W) x 1000 (H) Accessories and Parts  221 / 487 / 70.1" (L) x 30.7" (W) x 39.4" (H) PC System (Optional)  Monitor (Optional)  Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 36 To open the main box: Move the main box close to the installation site. Remove the strapping bands around the box and lift the top cover Top Cover Side Cover Remove the side cover. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 37 3. Before the Installation Remove the plastic cover with a cutter. When one installer removes the side cover, another must hold the box to prevent falling. Remove foams and take out each component as illustrated: Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 38 3. Before the Installation 3.3.2 CEPH Box (Optional) The CEPH box is provided for customers who purchased the CEPH option. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 39: Transporting The X-Ray Unit

    If you move the unit manually, ensure that the  person holding the upper handle takes the lead. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 40 3. Before the Installation <Transportation Example> Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 41: Checking The Parts And Accessories

    3. Before the Installation Checking the Parts and Accessories 3.5.1 Accessories Box 1 & 2 Overview Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 42 Yes □ No □ CEPH Option Hand rest Yes □ No □ Sticker Alignment Floor Mount Yes □ No □ Plate Option Temple right & left 1 set Yes □ No □ Supports Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 43 For Nasal CEPH Option: Silicone Cover Yes □ No □ Positioner extra Left Blank Intentionally Silicone Cap White Yes □ No □ Flat Base Cap White Silicone Base Option Yes □ No □ Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 44 Yes □ No □ Wrench Bolt M8 x 20 Yes □ No □ C E Washer Yes □ No □ 1 Sems Truss Bolt M4 x16 Base Option Yes □ No □ Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 45 Yes □ No □ Spring Washer Yes □ No □ Flat Washer Yes □ No □ Flat Anchor M8 x 30 Yes □ No □ Bolt Hex Bolt M8 x 15 Yes □ No □ Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 46 Part No.37 and 38 are separately stored from other accessories as illustrated below: Part Items Specification Figure Comments Confirmed Lower Column Yes □ No □ Cover Back Column Yes □ No □ Cover Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 47: Installing The X-Ray Unit: Base Stand Type

    If you are installing the X-ray unit on a concrete floor, first complete the steps in 4.4.1 Concrete Floor. To attach the base to the X-ray unit: Remove the lower carrying handle. Required Tool Allen Wrench 6 mm / 0.24” Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 48 Put two wrench bolts into the holes on the bottom of the column unit. Required Tool Allen Wrench 6 mm / 0.24” Parts and M8 x 35 - 2 pcs Wrench Bolt Accessory (Part No. 24) Leave the bolts 30mm outside of the hole. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 49 4. Installing the X-ray Unit: Base Stand Type Install the base to the two-bolt mount. ’ The Base after installation to the two-bolt mount Hold the base unit to keep it from falling. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 50 Tighten three wrench bolts on the underside of the base. Required Tool Allen Wrench 6 mm / 0.24” M10 x 25 w / Parts and Spring and Flat Wrench Bolt Accessory Washers - 3 pcs (Part No. 23) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 51 4. Installing the X-ray Unit: Base Stand Type Grab the upper carrying handle and lift the equipment slowly. Clear the cables from the installation site before lifting the equipment to prevent cable damage and electrical accidents. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 52 Parts and and Flat Washers - Wrench Bolt Accessory 3 pcs (Part No. 23) All wrench bolts inserted in steps 4 and 6 must be fully tightened before starting the next step. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 53 4. Installing the X-ray Unit: Base Stand Type Remove the top carrying handle. Required Tool Allen Wrench 6 mm / 0.24” Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 54: Installing The Ceph Unit (Optional)

    Remove the plastic wrap covering the unit and CEPH cables with a cutter. Attach the CEPH unit to the main unit by sliding four studs into arm holes. Ensure that the CEPH cables come out of the CEPH armhole as below. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 55 6 mm / 0.24” Required Tool Allen Wrench 8 mm / 0.31” M8 x 20 - 4 pcs Wrench Bolt (Part No. 25) Parts and Accessory 4 pcs C E Washer (Part No. 25) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 56 Ensure that the caps of the fiber optic cable have been removed.  Do not touch the tip of the fiber optic cable to prevent it from being dirty.  Insert the fiber optic cable fully until the click sound is heard.  Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 57 Cross Head Required Screwdriver w/ 6 mm / 0.24” Tool Magnetic Tip M3 x 6 Flat Head Screw - 2 pcs Parts and (Part No. 28) Accessory CEPH Arm (Part No. 28) Cover Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 58: Installing The Wall And Column Brackets

    Based on your equipment option, the distance between the bracket and floor must be different: Option Height (mm /ft) Base Stand 1,315 mm (4.31ft) Wall Mount 1,287 mm (4.22ft) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 59 Slide hex bolts into the mounted anchor with washers. Tighten the bolts until they no longer move. Required Torque wrench Spanner type Tool Hex Bolt M8 x 15 Parts and Spring washer Accessory Flat washer Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 60 Wall Mount 1,272 mm (4.17ft) Mark the installing location for the wall bracket and drill the hole for wood screws. Insert wood screws into drilled holes and tighten them with a screwdriver. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 61 Wrench Bolts M8 x 15 - 4pcs (2 Sems) (Part No.29) Parts and Accessory Column (Part. No. 22) Bracket Push the equipment to the wall where the wall bracket is installed. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 62 Allen Wrench 6 mm / 0.24” Required Tool Monkey Wrench M8 x 25 – 2 pcs Wrench Bolt (Part No. 35) Parts and Accessory M8 - 2 pcs (Part. No. 35) Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 63: Fixing The Base

    5/16 x 60 w/ Spring and Flat Washers - Anchor Bolt 2 pcs (Part No. 34) Parts and Accessory Spring washer M8 - 2 pcs Mark the base’s location on the floor. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 64 Remove the debris and clean the holes using the dust pump. Secure the anchor bolts with the hammer. Place the base. Put nuts and washers on the anchor bolts and tighten them with a ratchet wrench to secure the base. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 65 L = 200 mm (7.9”) M12 x 70 – 2 pcs Parts and Wood Screws Accessory (Part No. 34) Put M12x70 wood screws into holes. Tighten the screws with a hammer drill. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 66: Connecting The Cables To The Equipment

    Connect the cables in the back of the column as shown in the figure. Cable No. H000014A Optic Cable (Part No. 21) Parts and Accessory Cable Tie (Part No. 20) Exposure Switch (Part No. 2) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 67 M4 x 10 – 4 pcs Parts and Truss Bolt Accessory (Part No. 27) When you are attaching the cover, make sure that all optic cables come out through the cover’s hole, as illustrated below: Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 68: Removing The Transportation Safety Bolts

    Remove the transportation safety bolts with an Allen wrench. Required Tool Allen Wrench 6 mm / 0.24” Remove the semi-clear tapes on the vertical frame cover. Ensure not to scratch the vertical frame cover when removing tapes. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 69 Remove four safety bolts and two safety brackets with the tags. Required Tool Allen Wrench 6 mm / 0.24” Be sure not to damage the cables when removing the bolts. The safety bolts must be removed before removing the safety bracket. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 70: Leveling The X-Ray Unit

    8 mm / 0.3” Wrench Required Tool Spirit Level Prepare a spirit level. Turn the rotating unit clockwise so that the X-ray tube head faces the front. Loosen eight screws with a T-shaped hex wrench. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 71 Place the spirit level inside the vertical unit, as shown in the illustration below. Use a T-shaped hex wrench to adjust the screws in circled locations until the bubble inside spirit level comes to the middle. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 72 Use a T-shaped hex wrench to adjust screws in circled locations until the bubble inside the spirit level comes to the middle. When you finish leveling the equipment on all four sides, tighten eight screws until they no longer move. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 73: Connecting The Wall And Column Brackets

    4. Installing the X-ray Unit: Base Stand Type Connecting the Wall and Column Brackets Tighten bracket bolts with a monkey wrench, as illustrated below. Allen Wrench 6 mm / 0.24” Required Tool Monkey Wrench Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 74 4. Installing the X-ray Unit: Base Stand Type This Page Left Blank Intentionally Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 75: Installing The X-Ray Unit: Wall Mount Type

    5. Installing the X-ray Unit: Wall Mount Type Installing the X-ray Unit: Wall Mount Type Installing the X-ray Unit Before the installation, clear the site and check if the X-ray unit location is properly marked. Installation Overview Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 76 Drill holes following the mark made in step 2. Each hole must be 10.5 mm x 30 mm (0.41” x 1.18”) in size. Required Tool Hammer Drill L = 200 mm (7.9”) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 77 5/16 x 60 w/ Spring and Flat Washers Parts and Anchor Bolt Accessory 6 pcs (Part No. 34) Place the alignment plate on the floor, ensuring plate holes are aligned with the secured bolts. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 78 When placing the equipment, ensure that the holes on the bottom of the column are engaged in anchor bolts. Before placing the equipment on the alignment plate, clear the cables out of the installation site for safety. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 79 However, do not fully fasten the nut before finishing the leveling. Two persons are required for step 8. When one person is fastening, another person must hold the middle carrying handle to prevent the equipment from falling. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 80: Installing The Ceph Unit (Optional)

    Connecting the Cables to the Equipment Please refer to section 4.5 Connecting the Cables to the Equipment. Removing the Transportation Safety Bolts Please refer to section 4.6 Removing the Transportation Safety Bolts. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 81: Leveling The Equipment

    To level the equipment: Prepare a spirit level. Parts and Spirit Level Accessory Turn the Rotating Unit clockwise so that the X-ray tube head faces the front, as shown in the figure. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 82 M10 x 20 – 4 pcs Parts and Set Screw Accessory (Part No. 30) Place the spirit level as indicated below. Adjust each screw until the bubble inside the level comes to the middle. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 83 5. Installing the X-ray Unit: Wall Mount Type Place the spirit level inside the Vertical Frame as indicated below. Fasten each screw as indicated below to secure the column. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 84: Attaching The X-Ray Unit To The Wall

    Attach the X-ray unit to the wall by connecting the wall and column brackets. Ensure to tighten the bolts until they no longer move. Allen Wrench 6 mm / 0.24” Required Tool Monkey Wrench Fix the column on the floor by tightening bolts and nuts. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 85: Finalizing The X-Ray Unit Installation

    Attach the lower column cover to the column with M 4x10 truss bolts. Cover the boltheads with silicone caps after fixing the cover. M4 x 10– 2 pcs Truss Bolt (Part No. 27) Parts and Accessory 2 pcs Silicone Cap (Part No. 16) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 86 M4 x 16 – 3 pcs Truss Bolt (Part No. 26) 2 pcs Flat Base Cap Parts and (Part No. 17) Accessory 1 pc Round Base Cap (Part No. 17) Round Base Cap Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 87: Mounting The Chinrest And The Temple Supports

    Mount the chinrest and the bite. 1 pc Normal Chinrest (Part No. 9) Parts and Accessory 1 pc Normal Bite (Part No. 12) Mount the temple supports. 1 set Parts and Temple Supports Accessory (Part No. 5) Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 88: Attaching The Switch Holders

    Truss Bolt (Part No. 33) Attach the Up/Down switch holder to the handle frame with M4x10 truss bolts. Connect the Up/Down switch to the X-ray unit and hang the switch on the holder. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 89 M3X16 – 2 pcs Screws (Part No.2) Locate the Exposure Switch Holder with a sticker and two screws. Install the Exposure Switch Holder on the wall at the appropriate height using two screws. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 90: Covering Bolts With Caps

    Attach the vertical top cover with M4x10 truss bolts and cover each bolthead with a silicone cap. M4x10 – 7 pcs Truss Bolt (Part No. 33) Parts and Accessory 7 pcs Silicone cap (Part No. 16) Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 91: Setting Up Pc

    Door interlock (Optional) Fiber Optic Cable - Used to transfer image data to the PC. Warning System Panel - Used to provide a visible indicator: Light on when the equipment is irradiating X-ray. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 92: The Recommended Pc Requirements

     stable power supply, use the automatic voltage regulator (AVR) for a steady power supply. The PC system provided with the Green X / X18  undergoes rigorous tests for software compatibility before shipping. Do not make the changes to its hardware and software settings.
  • Page 93 Add Exclusions to Windows Security Follow the steps below to add exclusions to Windows security: Open the Start menu and type W in the search box. Click the Windows Defender Security Center to start. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 94 7. Setting up PC Click the Virus & threat protection. Click the Virus & threat protection settings. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 95 7. Setting up PC Scroll down to Exclusions. Click on the link Add or remove exclusions. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 96 7. Setting up PC On the Exclusions page, click the Add an exclusion button. On the Select Folder dialog, type C:\VcaptureSW in the folder field and click Exclude this folder. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 97: Installing The Internal Peripherals

    Whenever managing the fiber optic frame grabber board:  1. Wear the anti-static glove. 2. Do not wear the likes of a thick jacket. The following figures and descriptions are based on the PC model Z4 from HP. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 98 Check the locking status between the board and its holder after installing it. Poor installation can cause a failure for dark calibration data acquisition or noisy image acquisition. Put the slot holder back to its initial position. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 99: Connecting The Cables To Pc

    Parts and Accessory 1 pc License Key (Part No. 1) Remove the caps of the fiber optic cable. Connect the fiber optic cable. Insert the 3D viewer license key into a USB port. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 100 7. Setting up PC Confirm that the cable is connected as indicated below. The illustrations may differ from the actual product. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 101: Setting Environment Variables

    Checking PC BIOS settings. If the setting is different, set up the environment variable according to Appendix E. When you update the BIOS settings, the “EnhancedHalt State (C1E)” option will be displayed. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 102: Turning Off The Firewall

    Click the Windows Firewall. Click the Turn Windows Firewall on or off option. Select “Turn off Windows Fire Wall” for private and public network location settings. Click OK to apply the changes. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 103: Changing The Power Settings

    Turning off the Screen Saver To turn off the screen saver: Press the Windows icon and type “Change screen saver.” Click Screen Saver Settings. Select “None” in the dropdown menu. Click OK to apply the settings. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 104 Click the Power Options icon. Click Choose when to turn off the display. Select Never for both Turn off the display and Put the computer to sleep fields. Click Save changes to apply the settings. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 105: Turning Off The User Account Control

    Move the slider to “Never Notify” and click OK to apply new settings. You may be asked to confirm your selection or enter an administrator password. Reboot your computer for the change to take effect. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 106: Setting Folder Exclusions With Anti-Virus Software

    Some files the imaging system uses can be recognized as viruses by anti-virus software. For this reason, you must set a folder exclusion before starting the PC system. For Green X / X18, exclude the following paths and software from the virus scan: Path Software...

  • Page 107: Installing Software

    The image viewer program such as EzDent-i or the one  from the 3rd party should be installed before the InstallShield installation. For information on their installation procedures, refer to the corresponding manuals. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 108: Software Installation Flow

    Installing Image Viewer Programs Before image acquisition, either EzDent-i or the 3 part’s image viewer must be installed. Please go to the EzDent-i manual or the installation manual provided by the 3 party. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 109: Installing The Installshield

    The USB drive provided contains the InstallShield installation information. Before starting the installation, please check if the serial number file (e.g., 047-011752.txt) is correct. Go to the InstallShield folder and click Setup.exe. When the Setup dialog appears, click Next. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 110 9. Installing Software Check if Green X or Green X18 is selected and click Next. Check if all modality options are selected. If your equipment does not include the CEPH feature, uncheck CEPH, and click Next. Check if “WidePano” is selected for the CBCT sensor type and click Next.
  • Page 111 9. Installing Software Check if the “WidePano” is selected for the PANO sensor type and click Next. (Optional) Check if the “WideCEPH” is selected for the CEPH sensor type and click Next. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 112 PC and equipment share the same COM port. 11. Select a language and click Next. 12. Select a connection option for CR modality (Pano, CEPH) and click Next. If EzDent-i is installed, ensure to select SDK. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 113 13. Select a connection option for CBCT modality and click Next. 14. Check if the selected options are correct, then click Next. When the AutoSave is checked, the acquired image data is automatically saved. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 114 15. Select the component you want to install on your PC. 16. Confirm all information displayed in the Ready to Install window. If necessary, click Back to return to and change the previous selection. When all information is confirmed, click Install. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 115 9. Installing Software 9.4.1 Installing the DirectX Follow the steps below to install the Direct X ® Select “I accept the agreement” and click Next. Click Next to download Direct X ® components. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 116 9. Installing Software Click Finish to complete the installation. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 117 X setup. The following sections explain how to set up Flectron and Leon Grabber. 9.4.2.1 Flectron Grabber To Install the Flectron grabber: Select a language and click OK. In the setup dialog box, click Next. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 118 PC at the moment, check “I want to reboot later manually,” then click Finish. If an error occurs during installation, the message is displayed in red. If no error is found, the text is displayed in blue. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 119 Select a language and press OK. Press the V.Grabber’s Install button. After installation, the V.Grabber Installation Program dialog box appears. Click the Yes to reboot the compute or No to reboot later. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 120 Find the programs you want to uninstall and double-click the program to uninstall. When you are asked if you want to continue, click Yes or OK and follow the prompts to finish the uninstallation. Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 121: Setting Imaging Programs (Ezdent-I / Console)

    Once these programs are linked, you don’t need to repeat the step. To link EzDent-I to the console software: Click the EzDent-i icon on your PC. Click Main Menu, then select Settings. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 122 Select Acquisition from the setting options. Select Console Program. In the console program tab, check: Console Program Path: C:/VCaptureSW/exe/VCaptureSW.exe  Capture Message: Green X (Green X18) Captured  Patient Information File Path: C:/VCaptureSW/PatientInfo.ini  Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 123 9. Installing Software Click OK and restart your PC to apply the new setting. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 124 , a dialog box pops up. Fill out the required field ( *) in the dialog box: chart number and name. The rest of the fields are optional. Click Add to save the new patient record. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 125 The imaging mode selection menu may differ due to your equipment’s option (CEPH or non-CEPH) or the Display option you selected in the setting menu. Select an imaging mode from the menu. Based on your selection, the console software window appears. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 126 To configure parameters for the console software: The following information should be entered by the user requirements. Click from the console software’s main window. Check ‘Engineer’ and type the password (vatech). Then click Log in. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 127 Go to Language Option. English is set as a default. If necessary, click next to the language and select a new option you want. Then click Machine Set. Select the language you want. Then click Machine Set. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 128 In the DAP, check that the default DAP Level and DAP Unit are displayed, as shown in the following figure. Click on the General tab and type the equipment’s serial number in the Machine information. Green X PHT-75CHS Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 129 11. In the Link Information Setting, configure the Link Type and File Extension as below. Fields When EzDent-i is used CT / CR Link Type SDK Link CR Save Name .DCM Green X Captured Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 130 9. Installing Software 12. Click on the Sensor / Default tab and configure the user-defined parameters. The default features can be modified according to the user’s requirements. Click Save if changes occur. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 131 If it is not assigned correctly, change the COM port in the Networking option and click Save. Enter the command PVER] to verify the current mode. Note that the equipment is now in packing mode. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 132 Use the command PKEN_0001] to re-enter the packing mode. Click Exit and terminate the Control Panel. (Important!) Exit the imaging program (main GUI). Reboot the system for the changes to take effect. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 133 > Enter the command [SPM_MPOP_0001] in the command field. < When the same Beep Announcement is desired for CT and PANO imaging modality > Enter the command [SPM_MPOP_0002] in the command field. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 134 9. Installing Software 9.5.7 Finalizing the Parameter Settings To finalize the parameter settings: Click Exit and close the control panel page. Exit the imaging program (main GUI). Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 135: 10. Technical Specifications

    165.9 kg (365.74 lbs. - without Base) Without CEPH 220.9 kg (487.00 lbs. – with Base) Green X18 190.9 kg (420.86 lbs. - without Base) With CEPH 245.9 kg (542.11 lbs. – with Base) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 136 75.02(L) x 54.13 (W) x 92.34(H) (”) Rotating Unit Vertical Max. 800 mm (31.50”) Movement Base Stand/Wall Mount Installation type (Default: Wall Mount type) Main Box, CEPH Box (Optional) Base Box Packing Box Organization (Optional) Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 137: Drawing Dimensions

    10. Technical Specifications 10.2 Drawing Dimensions Green X: With Base (unit = mm (inch)) View With CEPH Without CEPH (With Base) Front (With Base) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 138 10. Technical Specifications Green X: Without Base (unit = mm (inch)) View With CEPH Without CEPH (Without Base) Front (Without Base) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 139 10. Technical Specifications Green X18: With Base (unit=mm (inch)) View With CEPH Without CEPH (With Base) Front (With Base) Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 140 10. Technical Specifications Green X18: Without Base (unit=mm (inch)) View With CEPH Without CEPH (Without Base) Front (Without Base) Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 141: Electrical Specifications

    Mode of operation: non-continuous operation (NFPA 70: long time  operation) - needs waiting time (at least 60 times the exposure time) before the next exposure. Column operation time: Max. 2 min. On / 18 min. Off (Ratio 1:9)  Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 142: Environmental Specifications

    Relative humidity 30 ~ 75 % Atmospheric pressure 860 ~ 1060 hPa Temperature -10 ~ 60 ℃ Transport and Storage Relative humidity 10 ~ 75 % Atmospheric pressure 860 ~ 1060 hPa Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 143 10. Technical Specifications This Page Intentionally Left Blank Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 145: Appendix

    MEIGaN guideline. (MEIGaN: Medical Electrical Installation Guidance Notes) Pre-installation planning is crucial to the successful installation of these  devices. For further details, refer to the accompanying volume: Specification for  Electrical Installation. Block Diagram Green X / X18 (Model:PHT-75CHS) Installation Manual...
  • Page 146 Appendix Schematic Diagram Components Supplied Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 147 Install the panel at a proper height according to each cable’s length. Connect the warning lamp (not provided). Connect the door interlock switch (not provided) Connect the power source for the warning lamp. Green X / X18 (Model:PHT-75CHS) Installation Manual...
  • Page 148 The cable sizes must be: N, L, and PE≥12 AWG (3 x 4 mm2).  The switch’s cable must be the same size as the power cable.  Install the socket connector terminal for the 2 protective ground wire.  Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 149: Limiting The Column Height

    Appendix C. Limiting the Column Height To limit the column height: Measure your ceiling height: Hceiling. Use the up/down switch to set the equipment to a suitable height. Green X / X18 (Model:PHT-75CHS) Installation Manual...
  • Page 150 Appendix Removing the Column Cover To remove the column cover: Remove fixing bolts as in the image below. Disassemble the side cover. If necessary, also disassemble the bottom cover. Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 151 Appendix Loosen the screw to adjust the height. (Caution: Do not remove the screws completely at this stage.) Tighten the screws again. Assemble the cover in reverse order of disassembly. Green X / X18 (Model:PHT-75CHS) Installation Manual...
  • Page 152 Hscrew height = 100 mm - d = 100 mm + 136 mm = 236 mm (If d is more than 100 mm, the column height limit is not necessary.) Hscrew height =100 mm – d = 236 screw height = 2,320.6 = 2,200 ceiling Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 153: Connecting The 3Rd Party Exposure Switch (Optional)

    Appendix D. Connecting the 3rd Party Exposure Switch (Optional) To connect the third-party exposure, switch to VATECH equipment: Cut the exposure switch cable provided with the equipment. Rewire the cable according to the schematic diagram below. Check the wiring status before the use.

  • Page 154: Checking Pc Bios Settings

    PC BIOS default Main Menu Sub1 Menu Sub2 Menu Setup Value Advanced Power Options Runtime Power Management [Disable] Advanced Power Options Idle Power Savings [Normal] Advanced Power Options Enhanced Halt State (C1E) [Disable] A-10 Green X / X18 (Model: PHT-75CHS) Installation Manual...

  • Page 155: Installation Checklist

    F. Installation Checklist General Information Customer Information about the Equipment Purchaser Name of Clinic or Hospital Address Phone E-Mail Website Dealer Information about the Equipment Seller Name of Dealer Address Phone E-Mail Website Green X / X18 (Model:PHT-75CHS) Installation Manual A-11...
  • Page 156 Is the freight elevator available? Is the security guard, if any, notified of the installation in advance? Are two installers, including the helpers, available to move and unload the equipment? A-12 Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 157 Did the installers take pictures of boxes before opening them? Did the installer ensure there were no suspicious holes or scratches on the box? Is the ShockWatch indicator red? Is the TiltWatch indicator red? Green X / X18 (Model:PHT-75CHS) Installation Manual A-13...
  • Page 158 Have you read the installation manual out in its entirety before starting the installation? Did the installer take pictures after opening the boxes? Did the installer make sure there were no suspicious holes or scratches on the box after opening it? A-14 Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 159 Did the installer ensure the harness and equipment are well connected and not damaged? Did the installers check if the emergency button (switch) is working properly? Did the installers balance the equipment well while installing? Green X / X18 (Model:PHT-75CHS) Installation Manual A-15...
  • Page 160 Is a firewall installed? If yes, indicate software or hardware. Type: Is the 3 party software installed? If yes, indicate the name(s) and versions. Is it compatible with software from Vatech®? If No, indicate the Version: name(s) and versions. A-16 Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 161 Is the equipment connected to the network? Is the network installation company identified? What is the assigned TCP/IP address? Address: What is the subnet masking address? Address: Is there a DHCP server? Green X / X18 (Model:PHT-75CHS) Installation Manual A-17...
  • Page 162 Appendix This Page Left Blank Intentionally A-18 Green X / X18 (Model: PHT-75CHS) Installation Manual...
  • Page 163 No part of this manual may be reproduced, transmitted, or transcribed without the expressed written permission of the manufacturer. We reserve the right to make any alterations that may be required due to technical improvement. For the most current information, contact your VATECH representative. Tel: (+82) 1588-9510 Email: gcs@vatech.co.kr Website: www.vatech.com...

This manual is also suitable for:

Green x18Pht-75chs

Table of Contents
