3.2.1 REPEATER INSTALLATION CHECKLIST
Installation Location Requirement
Working Space available
AC power supply at each installation location:
155~285VAC 45~55HzHz
EMC and interference
Maintain reasonable distance from chassis to
DT, MT antennas
Suitable operating environment
3.2.2 ANTENNA INSTALLATION CONSIDERATION
Installation Location Requirement
Locate donor antenna in a site to receive the
maximum signals from the desired BTS and to
shield the other signals at the same time
Line of sight between BTS antenna and donor
antenna is required
Isolation of BTS antenna and mobile antenna
(I) must be larger than the maximum gain of
the repeater in operation
3.2.3 CABLE REQUIREMENTS
Cable Name
coaxial cable
coaxial cable
Local Commissioning Cable
Communication Bus
SR-2110 QE
ENU Status : 1-0-0
EQUIPMENT MANUAL FOR SR-2110
Considerations
Ample space on mounting wall surface (recommended
to reserve 0.8m x 0.8m x 0.8m) for unrestricted airflow
and cable routing. After installation of the repeater, the
lower end of the chassis, where is the exit of cables,
should be 1.2 m higher than the ground
Power cord length is 3m (10 ft), use a dedicated AC
breaker or fuse circuit, and with good access to an
earthing point
Do not locate near large transformers or motors that
may cause electromagnetic interference
Reduce of signal loss in feeder cable
-20° C to 40° C, Maximum 85% relative humidity.
Avoid direct sun exposure and keep good air cooling
environment
Table 6: Repeater Installation checklist
Considerations
For maximum output power, Maximum input power =
Maximum Output Power – G
I > G
Table 7: Antenna installation checklist
Interface
N-N
Connect donor antenna to DT port of the equipment
N-N
Connect mobile antenna to MT port of the equipment
X14J5-DB9
For local OMT connection
X14J5-RJ45
For cascading from Master Unit to Slave Unit
Table 8: Cable types used for SR-2110 connection
Copyright - refer to title page
+ 10dB
max
Purpose
max
Page 24
