Parts List - Renishaw RENGAGE RMP600 Installation Manual

see Section 7,"Parts list"

Parts list

Item
RMP600
Battery
Battery
Stylus
Stylus
Stylus
Stylus
Tool kit
Battery cassette
Battery gasket
Diaphragm kit
Bobbin kit
RMI
RMI-Q
Mounting bracket
Styli tool
Publications. These can be downloaded from our website at www.renishaw.com.
RMI-Q
Styli
Probe software
Taper shanks
Part number Description
A-5312-8503 RMP600 probe with batteries, tools and product support card
(factory-set to radio on / radio off).
P-BT03-0005 AA battery – alkaline – supplied as standard with probe (pack
of two).
P-BT03-0008 AA battery – lithium-thionyl chloride (pack of two).
A-5003-7306 50 mm long carbon fibre stylus with Ø6 mm ball.
A-5003-6510 100 mm long carbon fibre stylus with Ø6 mm ball.
A-5003-6511 150 mm long carbon fibre stylus with Ø6 mm ball.
A-5003-6512 200 mm long carbon fibre stylus with Ø6 mm ball.
A-4038-0304 Probe tool kit comprising Ø1.98 mm stylus tool (× 1),
2 mm A/F hexagon key (× 1), 2.5 mm A/F hexagon key (× 2),
4 mm A/F hexagon key (× 1) and shank grub screw (× 2).
A-4038-0300 Battery cassette assembly.
A-4038-0301 Battery cap gasket kit.
A-5312-0302 RMP600 diaphragm kit.
A-4038-0303 Bobbin for shank switch (supplied with shank).
A-4113-0050 RMI (side exit) with 15 m (49.2 ft) cable, tools and product
support card
A-5687-0050 RMI-Q (side exit) with 15 m (49.2 ft) cable, tools and product
support card
A-2033-0830 Mounting bracket with fixing screws, washers and nuts.
M-5000-3707 Tool for tightening / releasing styli.
H-5687-8504 Installation guide: for set-up of the RMI-Q.
H-1000-3200 Technical specifications guide: Styli and accessories – or visit
our Web shop at www.renishaw.com/shop.
H-2000-2298 Data sheet: Probe software for machine tools – programs and
features.
H-2000-2011 Data sheet: taper shanks for machine tool probes.
7.1
