- Page 1 00-2286 120’ Suzuiki SX4 Fiat Sedici 2006» 661-0900...
- Page 2 rev. 2014-04-04 DC...
- Page 3 Congratulations on purchasing an ATS towbar Alexo Towbars Sweden offer quality towbars produced as a result of direct market research. Every towbar is sold with a unique 5-year guarantee which covers the functioning of the towbar system. Detachable towbars are to be removed when not used for towing, a common result of not removing the towbar during longer periods of time is oxidation of the inner mechanical parts, which causes the towbar to “stick”...
- Page 4 661-0900 Included Material Inkluderat material 2x M10 1x 10 x 70 (8.8) 1x 10 x 65 (8.8) 4 x M12 4 x M12 1 12 x 35 (8.8) 4 x 12 x 25 (8.8) M8x 30 (8.8) M12 x130 (8.8) M12 x 100 (8.8) M12 x 40 (8.8) M12 x 110 (8.8)
- Page 5 Towbar installation diagram Dragkrok installationsdiagram...
-
Page 6: Fitting Instructions
661-0900 Fitting instructions 1. Move ahead the back SEAT and the trunk cover. 2. Remove the frontal and side coatings of the trunk. 3. Remove the bumper 4. Remove the trunk protective rubber where the “A” brackets are going to be fixed in the towbar. At the bottom of the trunk, on both sides, there are 4 cross-shaped marks. - Page 7 Stötfångarens inre kant Såga bort Stötfångarens centrallinje...
- Page 8 661-0900 Removal of type 1 towball Demontering av typ 1 drag Fitting of type 1 towball Montering av typ 1 drag...
- Page 9 Removal of type 2 towball Demontering av typ 2 drag Fitting of type 2 towball Montering av typ 2 drag...
- Page 10 661-0900 Maintenance of detachable towballs Underhåll av demonterbara dragkrokar...
- Page 11 © Copyright Alexo ATS This catalogue and all information within it belongs to Alexo ATS, any use of the material other than as an instruction manual is strictly forbidden and will be reported. All kinds of reproduction and /or usage of material from this catalogue is not permitted. ©...
- Page 12 T= 1850 kg D= 9,98 kN S= 50 kg...
