Thank you for purchasing our fine product!
WARNING
: Failure to follow these directions and warnings can result in serious injury
and/or product damage.
Assistance is required to assemble this loveseat.
!
Never stand on the loveseat or use it as a ladder.
!
Do not tip the loveseat when seated.
!
Periodically re-tighten all bolts and legs.
!
If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.
!
Always seek assistance befor moving furniture.
!
#1432L Cassidy Loveseat
Assembly Instructions
This package contains all tools necessary for assembly.
Give us a chance to make it right
Contact our friendly, U.S. based customer service department with any
problems or comments. Replacements for missing or damaged parts
will be shipped promptly.
Toll Free: 866-528-8364
Monday - Friday, 8am-5pm, ET. After business hours, leave a message.
We will return your call the next business day.
#1432L Cassidy Loveseat
Page 1
Advertisement
Table of Contents
Related Manuals for µ-Dimension Cassidy 1432L
Summary of Contents for µ-Dimension Cassidy 1432L
- Page 1 #1432L Cassidy Loveseat Assembly Instructions Thank you for purchasing our fine product! This package contains all tools necessary for assembly. Give us a chance to make it right Contact our friendly, U.S. based customer service department with any problems or comments. Replacements for missing or damaged parts will be shipped promptly.
- Page 2 #1432L Cassidy Loveseat Assembly Instructions PARTS LIST Qty. Part Qty. Part Drawing Part Name Drawing Part Name Bolt with Seat Washers (5/16” x 2 1/2”) Back Wood Dowel Front Leg Allen Wrench Pillow Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed above.
- Page 3 #1432L Cassidy Loveseat Assembly Instructions Step 2 - Place the Back (Part B) on its back on a flat surface. Insert two Wood Dowels (Part F) into the middle-center holes located on the Back. Step 3 - Align the corresponding dowel holes on the Seat (Part A) with the dowels that were inserted in Step 2.
- Page 4 #1432L Cassidy Loveseat Assembly Instructions Step 6 - With help, place the assembled Loveseat upright in its intended location. Place the two Pillows (Part D) onto the Back like shown below. Assembly is complete. Give us a chance to make it right. TOLL FREE: 1-866-528-8364 Monday - Friday, 8am-5pm, ET.
