µ-Dimension Anna Accent 1107 Assembly Instructions

Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Thank you for purchasing our fine product!
This package contains all tools necessary for assembly.
WARNING
: Failure to follow these directions and warnings can result in serious injury
and/or product damage.
!
Assistance is required to assemble this chair.
!
Never stand on the chair or use it as a ladder.
!
Do not tip the chair when seated.
!
Periodically re-tighten all bolts and legs.
!
Do not exceed 250 lbs. (113.4 kg) weight limit on the chair.
!
If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.
!
Always seek assistance before moving furniture.
#1107 Anna Accent Chair
Assembly Instructions
Give us a chance to make it right
Do not return this item to the store. Contact our friendly, U.S. based
customer service department with any problems or comments.
Replacements for missing or damaged parts are normally
Toll Free: 866-528-8364
Monday - Friday, 8am-5pm, ET. After business hours, leave a message.
We will return your call the next business day.
#1107 Anna Accent Chair
shipped within 24 hours!
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Anna Accent 1107 and is the answer not in the manual?

Questions and answers

Related Manuals for µ-Dimension Anna Accent 1107

Summary of Contents for µ-Dimension Anna Accent 1107

  • Page 1 #1107 Anna Accent Chair Assembly Instructions Thank you for purchasing our fine product! This package contains all tools necessary for assembly. Give us a chance to make it right Do not return this item to the store. Contact our friendly, U.S. based customer service department with any problems or comments.
  • Page 2 #1107 Anna Accent Chair Assembly Instructions PARTS LIST Part Drawing P a r t Name Qty. D r a w i n g P a r t Name Q t y . P a r t B o l t with S e a t C u s h i o n Washers B a c k C u s h i o n...
  • Page 3 #1107 Anna Accent Chair Assembly Instructions Step 2 - Lay the Back Cushion (Part B) on a flat surface. Insert two Wood Dowels (Part F) into the middle- center holes located in the Back Cushion (Part B) like shown below. Step 3 - Align the corresponding dowel holes on the Seat Cushion (Part A) with the dowels inserted in Step 2.
  • Page 4 #1107 Anna Accent Chair Assembly Instructions Step 4 - Insert six Bolts with Washers (Part E) through each of the six holes located on the underside of the Seat Cushion (Part B). Thread the Bolts with Washers by hand until all of the Bolts have been inserted.
  • Page 5 #1107 Anna Accent Chair Assembly Instructions Step 6 - With help, turn the chair upright and place the Pillow (Part D) onto the Seat Cushion. Assembly is now complete. LEVELING CHAIR THE HOLES IN THE SEAT FRAME HAVE BEEN OVERSIZED TO ALLOW FOR EASIER ASSEMBLY.
