Numark Mixstream Pro Service Manual page 21

..2 BTCR122001
..2 GELS606C-0100
..2 MT1103225
..2 MT11055117
..2 PU050005002
..2 PU058005002
..2 SP1106101
..2 TWPC20C02301M
...3 AL4-08-0402
...3 ICNJM4580D
...3 JK4680-DR30-04F
...3 JKANC3MAH
...3 JKKD-01H2T-20
...3 RJ1039-09-0580B
...3 SWEVQ11L05R
...3 SWSP70030F13F1
...3 TE10200502
...3 TE10200601
...3 TE512540401
...3 TE612000202
...3 TE612000901
..2 TWPC20C02301T
...3 AL2-51-4401
...3 AL2-51-4403
...3 AL2-54-0138
...3 BAS0305025A
...3 CS100J5003NPO
...3 CS101J5003NPO
...3 CS102J5003NPO
...3 CS102K5002X7R
...3 CS102K5006X7R
...3 CS103K5003X7R
...3 CS104K2502X7R
...3 CS104K5003X7R
...3 CS104K5005X7R
...3 CS105K1605X7R
...3 CS105K5003X5R
...3 CS105K5006X7R
...3 CS106K1003X5R
...3 CS106K1005X7R
...3 CS106K1606X7R
...3 CS106K5006X5R
...3 CS106M5010X5R
...3 CS150J5002NPO
...3 CS200J5003NPO
...3 CS220J5003NPO
...3 CS221J5003NPO
...3 CS224K2503X7R
...3 CS225K1603X5R
...3 CS226K2510X5R
...3 CS226M0605X5R
...3 CS226M3505X5R
Lithium Coin CR1220
Heat-Sinking Cream
Heat Sink
Screw
Conductive Foam
Conductive Foam
Copression Spring
REAR PCB DIP Assembly
Con USB 4-Pin Female PC-MNT Ho
INTEGRATED CIRCUIT
A Type USB Jack 2.0 90°
XLR JACK 3Pin 90° Male
DC Jack 2.0mm 160W 90° DIP
RCA Jack(One Output)
Switch Tact 5mm 160g Horizonta
Switch Power Push Dual Row NON
Connector (5P Socket)180°
Connector in Header 180° Pitc
Pin Header 180° pitch:2.54mm
Terminal 2P 2.0 180°
Connector 9P 180°
REAR PCB SMT/AI Assembly
Transistor 2N4401 NPN
Transistor 2N4403 PNP
Mos et BSS138 N-CH
SMT Fixed
CCAP SMD 10pF/50V 5% 0603 NPO
CCAP SMD 100pF/50V 5% 0603 NPO
CCAP SMD 1nF/50V 5% 0603 NPO
CCAp SMD 1NF 10% 50V 0402 X7R
CCAP SMD 1nF/50V 10% 1206 X7R
CCAP SMD 0.01uF/50V 10% 0603 X7R
CCAP SMD 0.1uF/25V 10% 0402 X7R
CCAP SMD 0.1uF/50V 10% 0603 X7R
CCAP SMD 0.1uF/50V 10% 0805 X7R
CCAP SMD 1uF/16V 10% 0805 X7R
CCAP SMD 1uF 10% 50V 0603 X5R
CCAP SMD 1UF/50V 10% 1206 X7R
CCAP SMD 10uF 10% 10V 0603 X5R
CCAP SMD 10uF/10V 10% 0805 X7R
CCAP SMD 10uF/16V 10% 1206 X7R
CCAP SMD 10U/50V ±10% 1206X5R
CCAP 10uF/50V 20% 1210 X5R
CCAP SMD 15PF/50V ±5% 0402 NPO
CCAP SMD 20pF/50V 5% 0603 NPO
CCAP SMD 22pF/50V 5% 0603 NPO
CCAP SMD 220pF/50V 5% 0603 NPO
CCAP SMD 0.22uF/25V 10% 0603 X7R
CCAP SMD 2.2uF/16V 10% 0603 X5R
CCAP SMD 22uF 10% 25V 1210 X5R
CCAP SMD 22uF/6.3V 20% 0805 X5R
CCAP SMD 22uF/35V 20% 0805 X5R
1 (J4)
0.01 (U10)
1 (U10)
4 (U10)
2 (U10)
2 (U10)
4 (U10)
1
1 J9
1 U5
2 J10,12
2 J17,18
1 J2
1 J5
2 S1,2
1 SW1
1 (J1)
1 (J7)
1 (J3)
2 (J15,16)
1 (J6)
1
5 Q2,5,7,8,9
1 Q12
6 Q3,11,13,14,15,26
4 (U10)
1 C109
C113,196,198,199,200,201,202,203,204,20
13
5,206,207,208
C33,37,38,39,45,52,56,65,115,125,129,137,
24 141,142,143,144,145,146,148,149,150,185,
225,226
3 C77,139,151
2 C2,3
3 C156,179,184
8 C81,82,84,91,121,122,128,140
C1,6,10,12,13,17,19,20,21,25,28,32,34,35,4
1,42,43,44,49,51,53,57,60,62,69,70,72,74,7
8,79,85,87,93,94,96,98,99,100,102,105,114,
69
147,152,154,159,160,161,168,169,170,183,
193,211,212,213,216,217,218,219,220,221,
222,223,224,227,228,229,234,235
2 C209,210
2 C157,158
5 C92,106,132,134,231
1 C90
6 C75,76,83,86,95,189
9 C30,31,36,61,103,104,112,230,236
4 C46,48,50,55
2 C190,191
3 C155,192,194
2 C88,89
1 C187
5 C40,68,163,165,181
2 C47,54
4 C131,133,135,136
4 C58,59,162,167
3 C9,16,24
9 C7,8,14,15,22,23,27,29,71
4 C119,120,123,124
