Numark Mixstream Pro Service Manual
  1. Manuals
  2. Brands
  3. Numark Manuals
  4. DJ Equipment
  5. MIXSTREAM PRO
  6. Service manual

Numark Mixstream Pro Service Manual

Hide thumbs Also See for Mixstream Pro:

Advertisement

Quick Links

Download this manual
This document contains sensitive proprietary information.
All recipients must have a current non-disclosure agreement on file
with Numark.
Do not make illegal copies of this document.
The information in this document contains privileged and confidential information. It is intended only for the use of
those authorized by Numark. If you are not the authorized, intended recipient, you are hereby notified that any review,
dissemination, distribution or duplication of this document is strictly prohibited. If you are not authorized, please
contact Numark and destroy all copies of this document. You may contact Numark at support@numark.com.
© Copyright Numark
Confidential
Numark
Mixstream Pro
[NH08]
Service Manual
2021-10-20
ATTENTION!
v1.0
Numark Service Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mixstream Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Numark Mixstream Pro

Summary of Contents for Numark Mixstream Pro

  • Page 1 The information in this document contains privileged and confidential information. It is intended only for the use of those authorized by Numark. If you are not the authorized, intended recipient, you are hereby notified that any review, dissemination, distribution or duplication of this document is strictly prohibited. If you are not authorized, please contact Numark and destroy all copies of this document.
  • Page 2 As the owner of the copyright to the Manual, Numark does not give you the right to copy the Manual, and you agree not to copy the Manual without the written authorization of Numark. Numark has no obligation to provide to you any correction of, or supplement to, the Manual, or any new or superseding version thereof.
  • Page 3 ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED NUMARK SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF THAT ENTITY, AND NUMARK SHALL HAVE NO LIABILITY TO THAT ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.

  • Page 4: Safety Instructions

    The product is exposed to water or excessive moisture, The AC power supply plug or cord is damaged, The product shows an inappropriate change in performance or does not operate normally, or The enclosure of the product has been damaged. Confidential Numark Service Manual...

  • Page 5: Specification

    FUNCTION 1. Touchscreen: This full-color, multi-touch display shows information relevant to Mixstream Pro's current operation. Touch the touchscreen (and use the hardware controls) to control the Mixstream Pro interface. 2. Browse Knob: Turn this knob to navigate through lists. Press the knob to move forward in the touchscreen or select a song to load on either deck.
  • Page 6 14.Effects Toggle: Move this toggle switch away from you to activate the selected effect— the toggle will latch to that position. Pull the toggle back to the center position to deactivate the effects. Pull and hold this toggle toward you to activate the selected effect momentarily, and release the toggle to deactivate the effect—the toggle will return to the center position.

  • Page 7: Disassembly Procedures

    DISASSEMBLY PROCEDURES REMOVAL OF THE BOTTOM CHASSSIS . (Fig1) (A) TAKE OUT THE 5 PCS VR CAP AND 15 PCS KNOB AND 15 PCS NUTS FROM OF TOP HOUSING. (B) TAKE OUT THE 16 PCS SCREWS FROM OF BOTTOM CHASSIS. (Fig.1)
  • Page 8 2. REMOVAL OF REAR PCB AND PADDLE PCB AND FRONT PCB. (Fig.2) (A) REMOVE THE 3 PCS SCREWS AND 3 PCS CONNECTORS BEFORE REMOVAL OF REAR PCB . (B) REMOVE THE 4 PCS SCREWS AND 2 PCS CONNECTORS BEFORE REMOVAL OF PADDLE PCB . (C) REMOVE THE 4 PCS SCREWS AND 1 PC CONNECTOR BEFORE REMOVAL OF FRONT PCB .
  • Page 9 3. REMOVAL OF TOP LEFT&RIGHT (DIP) PCB AND SENSOR PCB AND TOUCH PCB AND FILTER1 PCB AND CUE PCB. (Fig.3) (A) REMOVE THE 14 PCS SCREWS AND 1 PC CONNECTOR BEFORE REMOVAL OF TOP RIGHT PCB DIP ASSEMBLY . (B) REMOVE THE 2 PCS SCREWS BEFORE REMOVAL OF TOUCH PCB SMT/AI ASSEMBLY. AND 1 PC CONNECTOR BEFORE REMOVAL OF TOP LEFT FILTER1 PCB DIP (C) REMOVE THE 3 PCS SCREWS ASSEMBLY.
  • Page 15 0.1 PNH08MAR21~24/26 Pack Assembly ..2 BC1015025000 Bubble Pad ..2 CGNH08310MAR01 Inner Box ..2 CTNH08513MAR01 Carton ..2 GEMAR122 Poster ..2 LAC67MAR1093 LOGO Label(Numark) ..2 NM1504452 Cleaning Cloth ..2 OPNH08MAR01 Instruction Book ..2 OPNK14MAR13 Sa ety Manual(1372-H) ..2 PE230440404B09 PE Bag ..2 PLNH0801 Poly oam(Le t) ..2 PLNH0802...

  • Page 16: Rotate Button

    Pack Assembly ..2 BC1015025000 Bubble Pad ..2 CGNH08310MAR01 Inner Box ..2 CTNH08513MAR01 Carton ..2 GEMAR122 Poster ..2 LAC67MAR1093 LOGO Label(Numark) ..2 NM1504452 Cleaning Cloth ..2 OPNH08MAR02 Instruction Book(JP) ..2 PE230440404B09 PE Bag ..2 PLNH0801 Poly oam(Le t) ..2 PLNH0802 Poly oam(Right) ..2 SD77045000...
  • Page 17 0.1 RU1110621501 Rubber Button Printing 0.1 RU1530608 Rubber Foot 0.1 SC0308PBBI Screw M3X8 PBB Tapping 0.1 SC0308PBNI Screw 0.1 SC0308RINI Screw M3X8 PPN 0.1 SC0310RBBI Screw M3X10 PPB Tapping 0.1 SC0310WANI Screw M3X10 12 PPWN W/Washer 0.1 SC0312PBBI Screw M3X12 PPB Tapping 0.1 SPK-PASSIVE007 Passive radiator speaker round 0.1 SPSAFSP036RHBN3 Switch Adaptor 12V/3A(21/22/23/24/26/27)
  • Page 18 ..4 LDL-S291SWC-ML5 LED White SMD 0603 120° LD306,311 R100,125,149,150,151,152,153,154,155,15 6,157,158,159,160,161,162,163,400,401,40 ..4 RS000010J03 RESISTOR 0 5% SMD 0603 2,403,404,405,406,407,408,409,410,411,41 2,413,RR1,2,3,4,5,6 ..4 RS001M10F03 RESISTOR 1M 1% SMD 0603 R112,113,122,123 R101,102,126,127,128,130,131,133,135,13 ..4 RS002210F03 RESISTOR 22 1% SMD 0603 6,139,168,169 R305,306,307,308,309,310,311,312,313,31 4,315,316,317,318,319,320,321,322,323,32 ..4 RS010010F03 RESISTOR 100 1% SMD 0603 4,325,326,327,328,329,330,331,332,333,33 4,335...
  • Page 19 ..4 ECS10616BLE ECAP 10UF/16V 4*5.7mm SMD Low EC700 ..4 RS000010J03 RESISTOR 0 5% SMD 0603 R700,701 ..4 TE6A2000501 Pin Header 180° Pitch 2.0mm 5Pin SMD (TE700) ...3 TWPC19C033G01T TOUCH PCB SMT/AI Assembly ..4 FCN1T0500802 FCN Top Contact ZIF SMD Pitch0.5mm 8P ..4 UH160808T-601Y CAPACITOR FCN801...
  • Page 20 ..4 RS010K10F03 RESISTOR 10K 1% SMD 0603 R639,642,645 ..4 RS47R510F03 RESISTOR 47.5 1% SMD 0603 R700,701, ..4 RS49R910F03 RESISTOR 49.9 1% SMD 0603 R603 ..4 SWEVQPLHA15 Switch Tact Stem Height:1.5mm SMD SW703,707,711,715 ..4 TE6A2000602 Pin Header 180° Pitch 2.0mm Single Row (TE601) ..4 TRDMN6140L Q601,603,605...
  • Page 21 ..2 BTCR122001 Lithium Coin CR1220 (J4) ..2 GELS606C-0100 Heat-Sinking Cream 0.01 (U10) ..2 MT1103225 Heat Sink (U10) ..2 MT11055117 Screw (U10) ..2 PU050005002 Conductive Foam (U10) ..2 PU058005002 Conductive Foam (U10) ..2 SP1106101 Copression Spring (U10) ..2 TWPC20C02301M REAR PCB DIP Assembly ...3 AL4-08-0402 Con USB 4-Pin Female PC-MNT Ho ...3 ICNJM4580D...
  • Page 22 ...3 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO C11,18,26 ...3 CS391J5003NPO CCAP SMD 390P/50V 5% 0603 NPO C180,214 ...3 CS470J5003NPO CCAP SMD 47pF/50V 5% 0603 NPO C232,233 ...3 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO C172,173,176,177 ...3 CS474K1603X7R CCAP SMD 0.47uF/16V 10% 0603 X7R C186 ...3 CS475K1003X5R CCAP SMD 4.7uF 10% 10V 0603 X5R...
  • Page 23 ...3 RS002010F03 RESISTOR 20 1% SMD 0603 R1,9,16 ...3 RS002K10F03 RESISTOR 2K 1% SMD 0603 R39,46 ...3 RS010010F03 RESISTOR 100 1% SMD 0603 ...3 RS010016F02 RESISTOR 100 1% SMD 0402 R8,29,40,47,67,105,108,114,118,119,120,1 ...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 45,154,171 ...3 RS010K16F02 RESISTOR 10K 1% SMD 0402 R63,64,65,69,73,77,91,131 ...3 RS015004F06...
  • Page 24 ...3 UHMPS0630M-100M INDUCTOR WIREWOUND SMT 10uH L10,11,13,14 ...3 UHMPSZ0630-5R6M L1,3 Inductor 5.6UH 8A±20% 6.6x7.4x3mm SMD ...3 UHSQD105T-751 Inductor 5.6UH 8A±20% 6.6x7.4x3mm SMD ...3 XTM225792O9 Crystal Oscillator 22.5792MHz ...3 XTM37400X8 Crystal 37.4MHZ 12PF SMD 3225A...
  • Page 42 +3.3V AZ05_SOM USB_SD CONTROL SURFACE AZ05.SchDoc USB_SD.SchDoc CTRLR_UART_RX SDMMC_PWR UART1_RX SDMMC_PWR PWR_EN CTRLR_UART_TX UART1_TX SDMMC_CLK UART1_CTS SDMMC_CLK SDMMC_CMD UART1_RTS SDMMC_CMD SDMMC_D3 SDMMC_D3 SDMMC_D2 SDMMC_D2 SDMMC_D1 SDMMC_D1 SDMMC_D0 SDMMC_D0 POWER_AND_RESET SDMMC_DET SDMMC_DET PowerAndReset.SchDoc SDMMC_WP SDMMC_WP nPBIN nPBIN nPBIN nRECOVERY nRECOVERY nRECOVERY nRESET_SOC nRESET_SOC SOC_RESET...
  • Page 43 Rail Direction Direction +5V::SOM To SOM Main power input of module +3.3V::IO From SOM IO rail from PMIC, used to gate our IO supplies +3.3V::PMU From SOM PMU rail from PMIC, used to latch main FET NH08 HeatSink +VCC_RTC To SOM RTC power input of module, sourced by our battery Peripheral Typical Usage I2C0...

  • Page 44: Mounting Holes

    +5V::SOM +12VDC FDD4685 MP2315 +VIN +VSYS PMEG3050BEP 20.0 R114 10.0K 0.1uF +5V::SOM 1,000pF 1,000pF 150uF 100K EN/SYNC SMA6J24CA 150uF 5.6uH R132 20.0K 40.2K R133 PS_SYNC GND_ESD DCDC Sync Clock ~725 kHz 0.1uF BSS138 7.50K 0.00 33pF R115 100K R116 2.21K GND_AMP C113 U18A...
  • Page 45 +3.3V +3.3V +3.3V +3.3V R106 R107 BAV99 BAV99 4.75K 4.75K TP14 TOUCH_I2C_SDA TP15 TOUCH_I2C_SCL TP16 TOUCH_INT TP17 TP18 TOUCH_RESET TP19 4.7uF 0.1uF BAV99 BAV99 +3.3V +3.3V +3.3V +1.8V DMP3099L +3.3V +3.3V::MIPI 100K 1.00K 10uF 10uF C107 10pF 1,000pF 0.1uF 0.1uF C108 10pF 10.0K...
  • Page 46 USBO_N USBH1_N USBH2_N USBO_P USBH1_P USBH2_P _USBO_N _USBH1_N _USBH2_N _USBO_P _USBH1_P _USBH2_P __USBO_N __USBH1_N __USBH2_N __USBO_P __USBH1_P __USBH2_P ___USBO_N ___USBH1_N ___USBH2_N ___USBO_P ___USBH1_P ___USBH2_P +VBUS-OTG TYPE-B-2.0 _USBO_N VBUS USBO_N __USBO_N ___USBO_N USB_OTG_DM USBO_P GND_ESD __USBO_P ___USBO_P USB_OTG_DP _USBO_P 90ohms@100MHz SHLD R108 0.1uF USBLC6-2...
  • Page 47 R186 3.32K BAT54S +3.3VA BAT54S +3.3VA +3.3VA DAC 1 - MAIN ADC INPUT BUFFER C180 390pF 10uF, 10V 10uF, 10V C231 0.1uF, 50V 0.1uF, 50V 22uF C215 R188 3.32K 10uF, 10V 0.1uF, 50V DAC LPF R185 33.2 0.1uF, 50V 0.1uF, 50V Gain = +5.62dB U24A MIC_OUT...
  • Page 48 10uH +VSYS +VSYS TP20 Right+ TP21 Right- GND_AMP C117 C118 TO SPEAKERS twisted 470uF 470uF 10uH TP22 Left+ TP23 Left- SIL SHROUDED 2.0mm 1Kohm GND_AMP GND_AMP +3.3V 18mA PVDD OUT_A+ GND_AMP PVDD OUT_A- PVDD PVDD OUT_B+ 10uH OUT_B- DVDD C131 0.22uF GND_AMP BST_A+...
