Using This Manual; Before Using The Dyno; Tools Required; Equipment Required - Mini Pro Chassis Dyno V2 Instruction Manual

USING THIS GUIDE

Before Using the Dyno

This dyno is a high-quality analyzing tool intended for persons
aged 18 years and older with previous experience building and
operating Radio Control vehicles. This is not a toy; it is a preci-
sion testing equipment. This dyno is not intended for use by
beginners, inexperienced customers, or by children without di-
rect supervision of a responsible, knowledgeable adult. If you
do not fulfill these requirements, please return the kit in unused
and unassembled form back to the shop where you have pur-
chased it.

TOOLS REQUIRED

Hex: 2.0mm, 3.0mm
2.0mm
3.0mm

EQUIPMENT REQUIRED

Vehicle
Electric Powered
OR
Gas Powered
Soldering Iron
* Only for Electric Vehicles
Electronic Speed
Control (ESC)
Battery
* Only for Electric Vehicles
Before building and operating your dyno, YOU MUST read
through all of the operating instructions and instruction man-
ual and fully understand them to get the maximum enjoyment
and prevent unnecessary damage. Read carefully and fully un-
derstand the instructions before beginning assembly. Contents
of the box may differ from pictures. In line with our policy of
continuous product development, the exact specifications of
the dyno may vary without prior notice.
IR Tachometer (Optional)
Throttle Controller
R/C Transmitter and Receiver
OR
Servo Tester
OR
ESC Controller Sensor*
(Sold by miniPRO)
* Additional USB port is required.
Windows PC
Operating System: 7, 8, or 10
(1) USB Port for Dyno
