- Page 1 CHASSIS DYNO V1 Instruction Manual REV2.0...
-
Page 3: Using This Manual
USING THIS GUIDE Before Using the Dyno This dyno is a high-quality analyzing tool intended for persons Before building and operating your dyno, YOU MUST read aged 18 years and older with previous experience building and through all of the operating instructions and instruction man- operating Radio Control vehicles. -
Page 5: Table Of Contents
CONTENTS Using this Manual ..........2 Before Using the Dyno ......2 Tools Required .........2 Equipment Required ......2 Dyno Feature Highlights ........6 Assemble the Dyno ..........7 Electronic Connections ........8 (miniPRO) Volt. & Current Sensor ..8 (Attopilot) Volt. & Current Sensor .. 10 ESC/Servo Controller Sensor ... - Page 6 CONTENTS Dyno Setup ............16 General Settings ........16 Firmware Update ......... 17...
-
Page 7: Dyno Feature Highlights
DYNO FEATURE HIGHLIGHTS This is a universal chassis dynamometer (dyno) that is ready to test gas or electric vehicles out of the box. Featuring an onboard electrical board equipped with an optical rpm sensor that measures motor speeds at up to 50,000 rpm. The board is also equipped with external ports for an external LCD screen, throttle controller, and different types of sensors for measuring voltage, current, and temperature. -
Page 8: Assemble The Dyno
ASSEMBLE THE DYNO The dyno its already been pre-assembled. All you need to do is install the flywheel base plate and straps for the vehicle. Install the Flywheel Base Install the Flywheel Assy. and Belt NOTE: If you are using your Motor Dyno Flywheel Assy then NOTE: Do not tighnen the screws. -
Page 9: Electronic Connections
ELECTRONIC CONNECTIONS miniPRO H1 Voltage and Current Sensor Connection Voltage and Current Sensor Diagram Solder Connector 1. (+) Battery Conn. 2. (-) Battery Conn. 3. (-) ESC Conn. 4. (+) ESC Conn. 5. Electronic Board Conn. - Ground 6. Electronic Board Conn. - Voltage 7. - Page 10 ELECTRONIC CONNECTIONS CONT. miniPRO A1 Voltage and Current Sensor Connection Voltage and Current Sensor Diagram Voltage and Current Board Diagram 1. (-) ESC Conn. (Black) 2. (+) ESC Conn. (Red) 3. Electronic Board Conn. - Current 4. Electronic Board Conn. - Voltage 5.
-
Page 11: (Attopilot) Volt. & Current Sensor
ELECTRONIC CONNECTIONS CONT. Attopilot Voltage and Current Sensor Connection Voltage and Current Sensor Diagram Voltage and Current Board Diagram 1. (-) ESC Conn. (Black) 2. (+) ESC Conn. (Red) 3. Electronic Board Conn. - Current 4. Electronic Board Conn. - Voltage 5. -
Page 12: Esc/Servo Controller Sensor
ELECTRONIC CONNECTIONS CONT. Throttle Controller Sensor Connection ESC/Servo Controller Diagram 1. (-) Ground 2. (+) Positive 3. Signal 4. USB mini-b port NOTE: This sensor its already been pre-programed to be used with the dyno. ESC Connection 1. Connect the ESC’s throttle OR the Servo’s throttle cable to the sensor’s throttle port. -
Page 13: Driver Installation
DRIVER INSTALLATION Electronic Board Driver Installation for Windows 7 and 8 Download the driver, and connect the dyno Open the “Device Manager” to the pc using the micro-b USB cable. Go to -->http://minipro.wiki/downloads and download NOTE: When you plug the dyno, a new comunication port the latest driver and extract the driver to a new folder. -
Page 14: Dyno Driver For Windows 10
DRIVER INSTALLATION CONT. Electronic Board Driver Installation for Windows 10 Connect the dyno to the pc using the Verify the driver was automatically installed micro-b USB cable. by opening the “Device Manager.” Go to -->http://minipro.wiki/downloads and download the latest driver and extract the driver to a new folder. NOTE: The electrinic board driver is installed automatically by NOTE: When you plug the dyno, a new comunication port Windows 10;... -
Page 15: Esc Controller Sensor Driver
DRIVER INSTALLATION CONT. ESC Controller Sensor Driver Installation Connect the sensor to the pc using the Run setup.exe. mini-b USB cable. The installer will guide you through the steps required to install the sensor. Go to -->http://minipro.wiki/downloads During the installation, Windows will ask you if you want to install the drivers. -
Page 16: Software Installation
SOFTWARE INSTALLATION Install the Software Download Software Read the Warning Notes and click “Next” if you agree. Go to--> http://minipro.wiki/downloads Next, download the latest software and start the installation. Select the location folder where “mini D” Confirm that you want to install “mini D” on will be installed, and then select the person your computer, and click “Next”... - Page 17 DYNO SETUP General Settings To access the settings of your dyno, you must open the main application and select “ Dyno Settings. ” 1. Connect/Disconnect the dyno to setup mode 5. Factory reset your dyno settings 2. Save the settings of your dyno 6.
- Page 18 FIRMWARE UPDATE General Guide Enter Setup Mode Establish a Connection Switches 1.1. Change only Switch #8 to ON. Reset Button 1.2. Press the Reset button on the board. 1.3. Open miniPRO Application. 1.4. Select “Dyno Settings” NOTE: Make sure you installed the latest application of Make sure NOTE: only Switch #8 is ON.
- Page 21 CHASSIS DYNO www.minipro.com © 2018 miniPRO, LLC. All Rights Reserved.
