Driver Installation; Dyno Driver For Windows 7, 8 - Mini Pro Chassis Dyno V2 Instruction Manual

DRIVER INSTALLATION

Electronic Board Driver Installation for Windows 7 and 8
1
Download the driver, and connect the dyno
to the pc using the micro-b USB cable.
Go to -->https://support.minipro.com/095696-Drivers
and download the latest driver and extract the driver to a
new folder.
3
To open the "Device Manager"
3.1. Go to --> right-click on Computer.
Click Properties
4
Select "Other Devices" and right click "Un-
known device" and then select "Update
Driver Software"
Note: If "Other devices" is not available, then check the
USB connection, or otherwise, It might be possible that
the driver was already been installed by windows.
15
3.2. In the Properties window, click on Device Manager.
4.1. Select "Browse my
computer... " "
4.2. Select "Let me pick
from a list.. "
4.3. Select "Have a disk"
and locate the driver
that was saved earlier.
2
Open the "Device Manager"
NOTE: When you plug the dyno, a new comunication port
should appear when the driver was installed successfully.
5
Take note of the new comunication port
created by the electronic board driver.
OR
NOTE: The communication port is required to run the dyno.
Above port number may differ from your pc.
If the driver was automat-
ically installed, it might be
available under "Ports. "
