Main Components - TRAPP TR 200 Instruction Manual

www.trapp.com.br
TR 200
1
4
8
Image merely illustrative
1. Feeding funnel
2. Knob
3. Body
4. Cutting blades
5. Three-wire connector cable with grounding
6. Branch feed nozzle up to Ø25 mm
7. Motor
8. On/Off Switch

Main Components

TR 200G
2
6
3
7
5
Image merely illustrative
Image merely illustrative
1. Feeding funnel
2. Belt stretcher hand wheel
3. Locknut of the belt tensioner
4. Transport wheels
5. Feed hopper attachment handles
6. Body
7. Gasoline Engine
8. Branch feed nozzle up to Ø25 mm
9. Cutting blade
10. Power cut-off button (TRAPP / Lifan motor)
11. Throttle / Choke (TRAPP / Lifan motor)
12. Fuel valve (TRAPP / Lifan motor)
1
5
7
6
10
11
8
9
5
3
2
4
12
