2 D
ESCRIPTION
Pump operation
mode
Standby mode
The EU–48 temperature regulator is designed for central heating boilers. It controls the water
circulation pump ., the hot utility water (C.W.U.) pump, the floor heating pump, the circulation pump,
the blow (fan) and the fuel feeder. Two modules controlling three-way or four-way valves can be added
to the EU–48 thermoregulator (this is an additional option).
The advantage of this controller is its simplicity in operation. The user makes all changes of pa-
rameters with the knob of the pulse generator. Another advantage is a large and clear graphic display,
where the user can exactly see the current condition of the boiler's operation.
Any comments concerning the program should be reported to the boiler's manufacturer.
Each controller should be set individually for own needs, depending on the type of fuel used for
burning as well as the type of the boiler. The TECH company does not bear any responsibility for improper
controller settings.
3 F
UNCTIONS OF THE REGULATOR
This chapter describes the functions of the regulator, the method of changing the settings and
navigating the menu which takes place by means of the pulse generator (knob). The boiler's opera-
tional parameters are displayed on the main screen of the controller. The user selects the operation mode
and a number of settings of the boiler according to their own needs.
The boiler manufacturer's name as well as the program version appear on the graphic display
after activation of the controller. After a few seconds a message with language selection appears. In this
function, the user can change the language version.
Pulser knob
Active room thermostat
Exit
Clock
Current flue gas
temperature
Fan (%),
pumps: CH,
HW, circulating
(or valve), valve
calibration
