PoliPUMP eco
Multi-line electric pump for grease
Manual drawn up in accordance with EC
Directive 06/42
Dropsa products can be purchased from Dropsa bracnhes and authorized distributors,
User Operating and Maintenance Manual
Original Instructions
visit www.dropsa.com/contact or contact us at sales@dropsa.com
- WK 24/19
C2291IE
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DROPSA PoliPUMP eco
Summary of Contents for DROPSA PoliPUMP eco
- Page 1 Multi-line electric pump for grease User Operating and Maintenance Manual Original Instructions Manual drawn up in accordance with EC Directive 06/42 - WK 24/19 C2291IE Dropsa products can be purchased from Dropsa bracnhes and authorized distributors, visit www.dropsa.com/contact or contact us at sales@dropsa.com...
-
Page 2: Table Of Contents
Sommario 1. INTRODUCTION ........................... 3 2. GENERAL DESCRIPTION ....................... 3 2.1 DIRECT-POINT LUBRICATION ....................... 3 2.2 SPECIFICATIONS ..........................3 3. PRODUCT IDENTIFICATION ......................3 4. TECHNICAL CHARACTERISTICS ...................... 4 5. COMPONENTS ..........................5 6. UNPACKING AND INSTALLATION ....................6 6.1 UNPACKING ............................6 6.2 INSTALLATION OF PUMPING ELEMENTS / CAPS ................... -
Page 3: Introduction
2.2 SPECIFICATIONS PoliPUMP eco electric pump is a piston pump driven by an eccentric system, designed to be operated with a maximum of 35 pumping elements, allowing several independent lines to be supplied. It is supplied as a standard without pumping elements, which must be ordered separately by choosing the desired flow between six models that can be identified by pairing different colours. -
Page 4: Technical Characteristics
4. TECHNICAL CHARACTERISTICS GENERAL TECHNICAL CHARACTERISTICS With single acting pumping systems with cam Pumping system drive Drive assembly DC motor with reducer Motor power-supply voltage 12V DC 24V DC Net weight standard version 3 Kg (6.6 lb) Max. number of outlets/pumping elements 12 –... -
Page 5: Components
5. COMPONENTS PoliPUMP (standard) Warranty seal Reservoir, 2L Stirring paddle with wiper reservoir Loading door to the Pumping element grease nipple housing holes/caps Pump replacement cap (included within the scope of supply) Input power cable gland Cartridge loading predisposition/eventual return in pump M22x1.5 PUMPING ELEMENTS RED - (1 notch) GREEN - (2 notches) -
Page 6: Unpacking And Installation
6. UNPACKING AND INSTALLATION 6.1 UNPACKING Once you have identified the suitable place for installation, open the package and remove the pump and check that it has not suffered any damages during transport and storage. The packing material does not require special disposal precautions as it is in no way dangerous or pollutant. - Page 7 Screw in the pumping elements and tighten with a torque of 10 Nm using a 12mm socket spanner. Screw in the caps into the remaining holes and tighten with a torque of 10 Nm using a 12mm socket spanner or a 6mm Allen wrench.
-
Page 8: Operating Instructions
Use gloves and eye protection as required by the lubricant safety data sheet. DO NOT use lubricants that are aggressive to NBR gaskets. If you are unsure, contact the Dropsa S.p.A technical office for a detailed list of recommended lubricants. -
Page 9: Use
Ensure that the pump starts; Ensure the adequate lubrication of the machine (if there are doubts on correct operation, you can contact the Dropsa S.p.A. Technical Office and ask for the testing procedure). 7.3 FILLING THE RESERVOIR Check that all the pump housing holes/caps are occupied. -
Page 10: Problems And Solutions
The piston of the pumping element Replace the pumping element. is worn out. The delivery valve of the blocked Replace the pumping element. pumping element. : Operation may only be carried out by Dropsa specialised personnel (send the product to Dropsa headquarters). -
Page 11: Maintenance Procedures
9. MAINTENANCE PROCEDURES ATTENTION: Before any maintenance or cleaning operation, make sure that hydraulic feed and electric power are disconnected. The pump does not require special tools for any check and/or maintenance operations. In any case, it is recommended to use suitable equipment and personal protective equipment (gloves, protection goggles, etc.) that in good condition in accordance with applicable regulations to avoid injury or damage to parts of the pump. -
Page 12: Order Information
11. ORDER INFORMATION PUMPS PUMPING ELEMENTS Power CAPACITY PART CAPACITY PART Max. number of PUMPING ELEMENTS zione NUMBER NUMBER 0.02cc/cy 0888451 0.08cc/cycle 0888454 12VDC 0888270-ECO 0888271-ECO 0888272-ECO 0.03cc/cy 0888452 0.10cc/cycle 0888455 24VDC 0888273-ECO 0888274-ECO 0888275-ECO 0.04cc/cy 0888453 0.13cc/cycle 0888456 OPTIONAL SPARE PARTS PART PART... -
Page 13: Dimensions
12. DIMENSIONS PoliPUMP (standard) Dimensions in mm [in]. 13. HANDLING AND TRANSPORT Before shipment, the pumps are carefully packed inside a cardboard box. During transport and storage of the equipment, pay attention to the direction indicated on the box. Upon receipt, check that the packaging is not damaged and store the pump in a dry place. -
Page 14: Precautions For Use
Electrocution. This can occur only in the event of serious negligence by the user who, however, is qualified. Use of unsuitable lubricant. The characteristics of the lubricant are indicated both on the pump and in this Operation and maintenance manual (in the event of any doubt, contact the Dropsa S.p.A. Technical Office): PROHIBITED FLUIDS Fluids...
