2 For the User Maintenance 3 For the Installer Delivery and handling The water heater design Pipe installation Electrical installation Commissioning and adjusting 4 Technical data Dimensions Technical specifications Energy labelling Contact information NIBE VPB S/ VPBS S Table of Contents...
This is an original manual. It may not be General translated without the approval of NIBE. Rights to make any design or technical VPB S/ VPBS S is designed and manufactured according modifications are reserved. to good technical practice in order to ensure safe usage.
It must be disposed of at a special waste station or dealer who provides this type of service. Improper disposal of the product by the user results in administrative penalties in accordance with current le- gislation. NIBE VPB S/ VPBS S Chapter 1 | Important information...
Hot water (page Shut off valves Mixing valve Cold water (page Shut off valves Non-return valve Safety valve Electricity (page 14) Sensors Electrical anode (VPB S/ VPBS S enamel only) Chapter 1 | Important information NIBE VPB S/ VPBS S...
Draining is performed through the siphon (using hose) When replacing components on VPB S/ VPBS S only in the cold water connection (XL3). replacement parts from NIBE may be used. Charge coil Draining is performed through the siphon (using hose) in the docking connection, return to heat pump (XL9).
VPB S/ VPBS S Enamel Move the hatch backwards and slightly to the side. Pull the cover to one side. Pull the hatch forwards. 50 mm 1 x Potentiostat Chapter 3 | For the Installer NIBE VPB S/ VPBS S...
The water heater design VPB S200 VPB S300 / VPBS S300 XL13 XL14 QM22 QM22 The figure shows VPBS S300 NIBE VPB S/ VPBS S Chapter 3 | For the Installer...
Page 10
Direct-current anode (VPB S/ VPBS S enamel only) Cable to direct-current anode (VPB S/ VPBS S enamel only) Miscellaneous Rating plate Adjustable feet Designations according to standard EN 81346-2. Chapter 3 | For the Installer NIBE VPB S/ VPBS S...
VPBS S300 has an additional coil, which is used for an external heat source, e.g. thermal solar panels or a stove with a back boiler. NIBE VPB S/ VPBS S Chapter 3 | For the Installer...
Page 12
• Install expansion vessel and pressure gauge as illus- trated. • Install the safety valve as illustrated. Recommended opening pressure is 0.25 MPa (2.5 bar). For information about max opening pressure, see technical specifica- tions. Chapter 3 | For the Installer NIBE VPB S/ VPBS S...
Page 13
• sensor for external heat source, tank (BT54) • pressure gauge • expansion vessel • pressure relief valve • AXC module • circulation pump • sensor, external heat source (BT53) XL13 XL14 NIBE VPB S/ VPBS S Chapter 3 | For the Installer...
Use the sensors provided with the heat pump (or other heat source). When no heat sensors have been provided these must be ordered from the manufacturer of the heat source. The figure shows VPBS S300. Chapter 3 | For the Installer NIBE VPB S/ VPBS S...
Page 15
Connect the potentiostat to a suitable 230 V wall socket. NOTE The cable between the potentiostat and the anode must either be extended or shortened. The figure shows VPB S200 enamel NIBE VPB S/ VPBS S Chapter 3 | For the Installer...
Net weight Part No. 081 142 081 144 081 143 Scale for the product’s efficiency class A+ to F. With the feet removed, the required ceiling height is approx. 1930 mm. Chapter 4 | Technical data NIBE VPB S/ VPBS S...
Tel: +46 (0)433-27 3000 info@evan.ru info@nibe.se nibe-evan.ru nibe.se SWITZERLAND NIBE Wärmetechnik c/o ait Schweiz Industriepark, CH-6246 Altishofen Tel. +41 (0)58 252 21 00 info@nibe.ch nibe.ch For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information.
Page 24
WS release date: 2021-06-02 16:05 Publish date: 2021-07-02 11:18 This manual is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this manual.
