- Page 1 ™ Setup Guide Prosthetist For use with Alignment and Setup GaitLab App Download the GaitLab App from the Apple App Store or Google Play Store.
- Page 2 ™ Take the QUATTRO out of Storage Mode by plugging in the charger (must be plugged into power source). Once the QUATTRO is powered on, open the GaitLab App and tap on the QUATTRO Knee image. Next, tap the serial number of the Knee to connect (Figure 1).
- Page 3 Prosthetist Setup Guide Follow the instructions in the App for bench and static alignment. Recommendation: A weight line that falls up to 10 mm anterior to the axis of rotation promotes stability. A weight line that falls up to 10 mm posterior to the axis of rotation may introduce stance flexion while walking.
- Page 4 21850 St Apollinaire, France Irvine, CA 92618 USA call 855.450.7300 Phone: +33 (0)3 80 78 42 08 Phone: +1 855.450.7300 #quattroknee Email: cs@proteor.com Email: info@proteorusa.com #freedomknee Website: Proteor.com Website: ProteorUSA.com #freedominnovations ©2021 PROTEOR. All rights reserved. CG-03-11: Prosthetist Setup Guide...
