  • Page 1 Instructions...

  • Page 2: Table Of Contents

    PROTEOR | FREEDOM QUATTRO | Instructions for Use Contents System Components Included Terms / Symbols Used in This Guide Warnings / Safety Precautions Product Description Indications Intended Use Contraindications Product Technical Specifications Physical Properties Environmental Basic Operation Battery Information Battery Charge Port Access Location...

  • Page 3: System Components Included

    PROTEOR | FREEDOM QUATTRO | Instructions for Use 01 | System Components Part Number Part Description Included w/QUATTRO Available/Sold Separately QNX0601 QUATTRO Battery Wall Charger & Adapters IFU-03-014 QUATTRO Instructions for Use (IFU) CG-03-011 QUATTRO Prosthetist Guide CG-03-012 QUATTRO User Guide...

  • Page 4: Warnings / Safety Precautions

    PROTEOR | FREEDOM QUATTRO | Instructions for Use 04 | Product Description 03 | Warnings / Safety Precautions The QUATTRO is a microprocessor controlled, single axis Please read this instruction manual thoroughly before using. • prosthetic knee joint system with internal sensors to control Failure to comply with safety precautions can result in the •...

  • Page 5: Physical Properties

    PROTEOR | FREEDOM QUATTRO | Instructions for Use 09 | Physical Properties 11 | Basic Operation Product Weight: 1655 g [3.56 lbs.] 11.1. Battery Information • Build Height: 216 mm [8.5 in] • Operating voltage: 7.4 VDC Maximum Flexion Angle: 135°...

  • Page 6: Keypad Location & Functionality

    PROTEOR | FREEDOM QUATTRO | Instructions for Use 11.5. Charging Battery 11.4. Keypad Location & Functionality Inserting Charge Connector a. Pull the protective charging port cover open and insert charge connector with the cable oriented up. The connector is magnetic and will snap into place.

  • Page 7: Keypad Operation

    PROTEOR | FREEDOM QUATTRO | Instructions for Use 11.6. Keypad Operation 11.6.3. Pair Knee with Mobile App 11.6.1. Check Battery Status Wireless To pair your QUATTRO to the app the first Press and release button to show the time you connect, quickly press and release current battery power status.

  • Page 8: Led Reference

    PROTEOR | FREEDOM QUATTRO | Instructions for Use 11.8. LED Reference Condition LED Behavior Battery is charged Battery LED solid green Battery is charging Battery LED flashing green Battery is low Battery LED solid Battery is very low Battery LED flashing...

  • Page 9: Modes

    PROTEOR | FREEDOM QUATTRO | Instructions for Use Each of these can be customized by pressing the “+” or “-“. This allows 11.10. Modes you to have 3 custom settings for the amount of flexion needed for a particular golf swing.

  • Page 10: Power-Off Behavior

    PROTEOR | FREEDOM QUATTRO | Instructions for Use 11.11. Power-Off Behavior When the battery is depleted or the knee has been put into 13 | Alignment and Setup storage mode, a Power-Off Flexion resistance is used. The Follow the Clinician User Guide and the GaitLab smartphone power-off flexion resistance can be adjusted to accommodate app to properly align and setup the device.

  • Page 11: Warranty And Service

    See company website for details. • The QUATTRO may be interfered with by other equipment, even if that other equipment complies with CISPR For knee service or repair, please contact PROTEOR at EMISSION requirements. 1.855.450.7300. A loaner knee will be provdied upon request. •...

  • Page 12: Ce Conformity

    20 | CE Conformity Freedom QUATTRO is tested and certified to comply with the MDR (EU) 2017/745 (EN 55011 Class B and IEC60601-1, STSI EN 300-328 under R&TTE Directive 1999/5/EC and ISO 10328). The device complies with Part 15 of the FCC Rules and carries the CE mark.
  • Page 13 Phone: +33 (0)3 80 78 42 08 Email: cs@proteor.com www.proteor.com PROTEOR USA 3 Morgan Irvine, CA 92618 phone: 855.450.7300 email: info@proteorusa.com www.proteorusa.com Connect with us #quattroknee #freedomknee #FreedomQuattro #HumanFirst #PROTEOR ©2021 PROTEOR. All rights reserved. Freedom QUATTRO is a trademark of PROTEOR. IFU-03-014 Rev B...
