HIP CLUB CHAIR
407
1
PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
Are included using the Parts List below.
Tools Required:
#2 Phillips Head Screwdriver; 4mm Allen Key(included)
CHAIR FRAME (407F)
SEAT ASSEMBLY
50mm Hex Lag
Part Code: 316-1/4-10-50HL
#14 x 3/4 Phillips Pan Head Screw
Part Code: 316-14X3/4PPSMS
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
x 1
x 1
x 4
x 14
SEAT BACK ASSEMBLY
ARM SET
4mm Allen Wrench
Part Code: 4MMALLEN
x 1
x 1
x 1
Page 1
Advertisement
Table of Contents
Related Manuals for Seaside Casual HIP CLUB CHAIR 407
Summary of Contents for Seaside Casual HIP CLUB CHAIR 407
- Page 1 #14 x 3/4 Phillips Pan Head Screw Part Code: 4MMALLEN x 14 Part Code: 316-14X3/4PPSMS WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114 Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com Page 1...
- Page 2 ATTACH SEAT TRAY ASSEMBLY On a clean at surface connect Seat Tray Assembly using (6) 3/4” Phillips Pan Head Screw (AS SHOWN). Do Not Over Tighten. ATTACH SEAT BACK ASSEMBLY Connect Seat Back Assembly to Chair Frame on both sides with (4)50mm Hex Lags (AS SHOWN).
