Seaside Casual Cambridge Sectional Armless 002 Assembly Instructions

Instruction Revision: A

Parts List:

(1) Seat Assembly
(1) Top Rail (001,002,004 Only)
001 (3) Long Legs & (1) Short Leg
002 (2) Long Legs & (2) Short Leg
003 (4) Short Legs
004 (4) Long Legs
Back Slats (4) 001, (2) 002, (6) 004

Hardware:

(8) 3" Hex 1/4" Lags
(8) 1-1/4" Phillip's Head Screws (001)
(4) 1-1/4" Phillip's Head Screws (002)
(0) 1-1/4" Phillip's Head Screws (003)
(12) 1-1/4" Phillip's Head Screws (004)
READ ENTIRE INSTRUCTIONS BEFORE BEGINNING! Carefully remove contents
from box. Make sure that all parts and hardware are included.
This assembly requires two people

Step Two: Long Leg Assembly (001,002,004 Only)

Lay top rail upside down on a clean flat surface with insert nuts
showing. Insert top of leg with a hanger bolt into the insert nuts
in the top rail. Then spin the leg clockwise till its tight and square
with the top rail (Right Picture). Once you feel tension, continue
to turn until notches for back slats are aligned with top rail. Re-
peat process for all long legs per item.
Corner Leg will be marked C in the large notch for the seat.
Right & Left Leg will be marked R&L in the large notch for the
seat.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114

Tools Required:

Phillip's Head Screwdriver
4MM Allen Wrench (Included) or
Screw Gun with 4MM Driver (Not Included) (Recommended)
Assembly Instructions

Step One: Set Up

1
