280-7254-00
12 DISC CD CHANGER
Owner's manual
Thank you for purchasing the CDC1255z/RDC1255z sys-
CDC1255z
8-TIMES OVERSAMPLING DIGITAL FILTER
/DUAL 1-BIT DAC
OPTICAL DIGITAL OUTPUT
tem. The CDC1255z/RDC1255z is designed incorporat-
ing the latest digital technologies, while featuring a newly
DIGITAL AUDIO/12- DISC CD CHANGER
developed CD mechanism to achieve excellent perform-
ance and good reliability.
Please read this owner's manual entirely before proceed-
ing with installation.
CLASS 1
MODEL
12V
GROUND
LASER PRODUCT
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
051 722 877
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDI-
TIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFER-
Clarion Co.,Ltd.
MADE IN JAPAN
ENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
CAUTION
UNDESIRED OPERATION.
1.Be sure to use the screws, etc., included in the package tor installa-
tion.Using other screws could damage the set.
I S O
THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR SUB-
CHAPTER J APPLICABLE AT DATE OF MANUFACTURE.
8
2.Set the selectors on both side panels to the H Position when
Screws
CLARION CO.,LTD.
installing the set horizontally, to the V Position when installing
50 KAMITODA, TODA-SHI, SAITAMA-KEN, JAPAN.
the set vetically.When installing at the angle of 45, set the selectors
M5 8 W-SEMS
to the center click position.
The set may be damaged if the selectors are not set to the proper
H
positions.
45
V
SERIAL No.
This equipment has been tested and found to com-
USE OF CONTROLS, ADJUSTMENTS, OR PER-
ply with the limits for a Class B digital device, pursu-
FORMANCE OF PROCEDURES OTHER THAN
ant to Part 15 of the FCC Rules.
THOSE SPECIFIED HEREIN, MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
These limits are designed to provide reasonable pro-
tection against harmful interference in a residential
THE COMPACT DISC PLAYER SHOULD NOT BE
installation. This equipment generates, uses, and can
ADJUSTED OR REPAIRED BY ANYONE EXCEPT
radiate radio frequency energy and, if not installed
PROPERLY QUALIFIED SERVICE PERSONNEL.
and used in accordance with the instructions, may
CHANGES OR MODIFICATIONS NOT EX-
cause harmful interference to radio communications.
PRESSLY APPROVED BY THE MANUFACTURER
However, there is no guarantee that interference will
FOR COMPLIANCE COULD VOID THE USER'S
not occur in a particular installation. If this equip-
AUTHORITY TO OPERATE THE EQUIPMENT.
ment does cause harmful interference to radio or
INFORMATION FOR
USERS:.
television reception, which can be determined by
CHANGES OR MODIFICATIONS TO THIS PROD-
turning the equipment off and on, the user is en-
UCT NOT APPROVED BY THE MANUFACTURER
couraged to consult the dealer or an experienced
WILL VOID THE WARRANTY AND WILL VIOLATE
radio/TV technician for help.
FCC APPROVAL.
1
FEATURES
12-Disc Capability (Two 6-Pack Magazines)
Spring-Loaded Silicon Oil-Dampened Suspension
System
CeNET with Balanced Audio Line Transmission
and Dynamic Noise Canceling
Eject Capability While lgnition-Off
8-Times Oversampling Digital Filter
120˚ Mounting Capability
Dual 1-Bit D/A Converters
Optical Digital Output
Zero-Bit Detector
Mute Circuit
Dimensions: 10.6" (268mm)W
6.7" (170mm)D
3-Beam Laser System
2
PRECAUTIONS
1. This unit does not operate independently. The unit must be used with a source unit that has a cable connec-
tion for CeNET wire bound (sold separately).
2. When playing 3" (8cm) CDs, use an adapter that conforms to the recommended CD standards or the adapter
included with the
mark. Refer to the adapter instruction manual concerning operation and loading 3"
(8cm) CDs in the adapter.
3.
The pickup, the heart of a player, is built in deep behind the door. Do not leave this door open for extended
periods to prevent dust adhering to the pickup.
When the inside of the car is very cold and the player is used soon after switching on the heater, dew may
form on the disc or optical parts of the player and proper playback may not be possible. If dew forms on the
disc, wipe it with a soft cloth. If dew forms on the optical parts of the player do not use the player for about
one hour and the condensation will disappear naturally to allow normal operation.
4. While the system is in play, do not plug or unplug the cables as this will cause damage.
5. Do not expose the magazine to direct sunlight, the car heater or other sources of strong heat. Replace the
CD magazine (CAA-122) with a new one if bent or otherwise damaged.
Caution
• ONLY use the magazine included with the CDC1255z or RDC1255z. For additional magazines, pur-
chase Clarion Model CAA122. Do not attempt to insert different style magazine into the CD changer
even if they fit into the magazine opening. Inserting other manufacturers' magazines or previous
Clarion 6 Pack style magazines into the CDC1255z or RDC1255z will cause damage to the mecha-
nism and void the warranty.
3
CAUTIONS ON HANDLING CDs
Use only compact discs bearing the
mark.
Do not play heart-shaped, octagonal, or other specially shaped compact discs.
Handling
Do not use commercially available CD protection
New discs may have some roughness around the
sheets or discs equipped with stabilizers, etc.
edge. The set may not work or the sound may skip
These may get caught in the internal mechanism
if such discs are used. Use a ball-point pen, etc.,
and damage the disc.
to remove roughness from the edge of the disc.
Storage
Do not expose compact discs to direct sunlight or
Ball-point pen
any heat source.
Roughness
Do not expose compact discs to excess humidity
or dust.
Do not expose compact discs to direct heat from
heaters.
Cleaning
Never stick labels on the surface of the compact
To remove fingermarks and dust, use a soft cloth
disc or mark the surface with a pencil or pen.
and wipe in a straight line from the center of the
Never play a compact disc with any cellophane
compact disc to the circumference.
tape or other glue on it or with peeling off marks.
Do not use any solvents, such as commercially
If you try to play such a compact disc, you may
available cleaners, anti-static spray or thinner to
not be able to get it back out of the CD player or it
clean compact discs.
may damage the CD player.
After using special compact disc cleaner, let the
Always handle the compact disc by the edges.
compact disc dry off well before playing it.
Never touch the surface.
English
4
IDENTIFICATION OF PARTS
1 Installation selector levers
2 Eject button
Press the eject button for ejecting the magazine.
3 Sliding door
4 CeNET terminal for input and output
(13-pin)
5 Digital optical fiber output terminal
6 Address switch
When connecting an CD changer and MD changer
by CeNET, no more than 2 units can be connected.
When both of them are CD, the address switch needs
to be reset so that the address switch number is not
the same for each.
<How to change the address switch>
1. Rotate and change the switch using a fine-tipped
screwdriver.
2. Rotate the switch until it clicks into position.
<Example of address switch setting>
Setting example 1
CD changer
1
Address switch
number 1
Source unit
2
CD changer
Address switch
CeNET wire bound
number 2
Setting example 2
CD changer
1
Address switch
number 1
Source unit
MD changer
Address switch
CeNET wire bound
number 1
1
Caution
• The unit may not operate when both CD
• Do not use address switch numbers "3" or "4".
changers are set to the same address switch
number.
• Never change the address switch during op-
3.9"(98mm)H
eration. Doing so can cause malfunction or
breakdown. Do not change the address switch
forcibly, because this may also cause
malfunciton.
• The CeNET cable wiring must be less than
65.62 ft (20m) in length.
5
CD MAGAZINE
Inserting the CD
Inserting the Magazine
1. Load the discs with the labels facing upwards, as
1. Slide the sliding door to the right until it is com-
shown in the diagram.
pletely latched on.
2. When the discs are loaded into the magazine the
disc lever will move upwards in the direction of
the arrow.
Disc Lever (White color)
Magazine
2. Load the magazine in the direction as shown in
the diagram. Push it in until it is locked into the
unit.
Label Side
One in each slot (6 pieces)
Notes:
• Use commercially sold adapters for 3" (8cm) CDs.
• Up to two CD adapters can be used in one maga-
zine. 3 or more adapters in a magazine may cause a
trouble in ejection.
3. After the magazine has been loaded, close the
sliding door.
• Some adapter may be transformed by heat.
Extracting the CD
Extracting the Magazine
Pull the disc lever in the direction of the arrow and a
1. Open the sliding door and depress the eject but-
ton.
part of the disc will emerge from the magazine. Hold
carefully the edge of the disc and pull it out.
Pull
2. Remove the magazine when it has been ejected.
Note:
When taking out the CD do not let your fingers touch
the signal side of the CD.
3. Close the sliding door.
6
SYSTEM EXAMPLE
This unit is available for upgrade in various ways.
When you want to upgrade the system, make sure that the upgrade unit fits and wire it correctly.
3
2
6
1
5
CeNET
cable
4
Y-adapter
(Brack)
2 3
1
4
Digital optical fiber cable
Address switch
7
INSTALLATION OF CONNECTORS
Important
Important
Note:
Be sure that the CD changer
Only the provided screws and brackets should be used during installation. Us-
numbers are not the same.
ing screws other than those specified will cause damage.
•
When the CeNET cable is connected, it must be inserted fully and
securely. After connecting, fasten the cable using the cable holder or
cable clamp. After connecting, fasten the cables with cable holders,
etc.
•
When removing the digital optical fiber cable, rotate it to loosen it and
Important
pull it gently while holding the slide cap (a gray color part on the source
unit).
Do not use address switch
numbers "3' or "4'.
•
Do not coil up the digital optical fiber cable with a radius of less than 1"
(3 cm). With a radius of less than 1", the performance of the cable will
be greatly impaired.
•
When installed in a glove box or console box, make sure that the source
unit cables or cords do not interfere with the opening or closing of the
slide door.
8
INSTALLATION
Not used.
2 3
Prior to Installation
1
4
1. Decide on the installation place and direction.
Before shipment from the factory, the levers are normally placed in the horizontal position.
Address switch
2. Adjust the installation selector levers to the desired installation position.
Adjustment of Installation Selector Lever on
the Right Side
The installation direction can be adjusted by using
the sharp end of a screwdriver or ballpen to insert
into the round hole.
H
V
Sliding door
H: Horizontal
45
H
V
H
V
Right Side
Base
Set the position of the installation
Set the position of the installation
selector levers on the right side
selector levers on the right side
and at the base of the unit to "H".
and at the base of the unit to "45".
Caution
• Adjust the installation selector levers into the correct locations. Setting the locations incorrectly or
in varied positions will cause skipping.
• Do not move the installation selector levers while the unit is in use. This will cause damage to the
mechanism and the disc.
Installation Procedure
1. Use the double seamed hexagonal bolts to fix the
lead clamp and installation bracket to the unit (on
both sides) in the desired direction fo installation.
Example
(Vertical Position)
2. Use the wing nut to hold in place the installation
bracket with bolt to the installation bracket, which
is attached to the unit. Then affix the cushion rub-
ber.
Source unit
RCA extension
(Vertical Position)
cable
MD changer
DPH7500z
(Gray)
Ferrite
(Brack)
clamp
(Horizontal Position)
(Gray)
CDC1255z/RDC1255z
(Suspending Position)
CeNET cable
Digtal optical
Slide cap
fiber cable
9
TROUBLESHOOTING
Symptom
Loss of power
Connection with
the source unit is
not recognized.
Adjustment of Installation Selector Lever at the
base
Magazine cannot
The installation direction can be adjusted by insert-
be loaded.
ing the sharp end of a small screwdriver into the
square hole which can be seen from the adjustment
hole.
"No Disc" sign
appears when
searching for
discs.
Noise, skipping
45: Slope
V: Vertical
45
45
H
H
V
H
V
H
Mechanism does
V
V
not function.
Right Side
Base
Right Side
Base
Set the position of the installation
selector levers on the right side
and at the base of the unit to "V".
lf the same phenomenon still occurs after checking the above, or it is impossible to remove the magazine, please
consult your local dealer.
10
SPECIFICATONS
Frequency Response
Signal-to-Noise Ratio
Wow and Flutter
Power Supply
For your convinience, identification marks are put
Current Consumption
beside holes on the unit and the brackets. That is,
Unit Weight
holes with the "RH/LH" marks are to be used for
Dimensions
horizontal, "RV/LV" for vertical installation and "RT/
LT" for suspending installation.
For horizontal or suspending installation, use
Due to improvements, the design and these specifications may be modified without prior notice.
the attached installation screw to fix the lead
clamp.
Printed in Japan 1998/10 (To.K)
3. Remove the floor carpet and decide on the place
to install. Adjust the installation bracket with bolts
to suit the place of installation.
The installation bracket with bolt may be bro-
ken off if it is bent many times at the perforated
line.
4. Remove the separator of the cushion rubber that
is attached to the installation bracket with bolt and
install accordingly.
5. Unfasten the wing nut and remove the unit.
6. Return the floor carpet to its original place. Use a
knife to cut into the carpet where the bolt can be
felt, and allow the bolt to protrude from the carpet.
7. Align the unit with the bolts and secure it with the
wing nuts.
Cause
Remedy
Bad connection.
Check connections. Connect the cable again.
The length of the CeNET
Rewire the connection so that the length of cable is less than 65.62 ft
cable wiring is more than
(20m).
65.62 ft (20m).
Address switch num-
When the 2 CD changers are connected, set the address switch so
bers are the same.
that they do not have the same address number. Refer to the "Exam-
ple of address switch setting" in the section titled "IDENTIFICATION
OF PARTS".
Magazine inserted
Insert correctly.
wrongly.
A magazine is already
Eject the magazine and insert the other.
in the player.
Distorted magazine.
Buy New Magazine CAA-122.
There is no CD in the
After inserting a CD into the magazine, reload into the CD changer.
magazine.
The installation selec-
Set the installation selector levers to the same position on both sides.
tor levers are set to dif-
ferent positions on both
sides.
The unit installation di-
Set the unit installation direction and the installation selector lever
rection and the instal-
positions to match each other. When installed at an angle, change the
lation selector lever po-
installation selector lever to a position (H, 45, V) not prone to noise or
sitions do not match.
sound loss.
Disc bent or badly
Compare with another disc. If bad, discard the damaged disc.
damaged.
Disc is very dirty.
Clean the disc.
Mechanical error.
1. Referring to section "INSTALLATION", check the three angle of in-
stallation selector levers are properly set. If not, set them at the
proper position for the angle of installation.
2. Check whether the CD magazine can be ejected by pressing the
CD magazine eject button, then insert a new CD magazine.
: 5Hz~20kHz( 1dB)
: 105dB(1kHz)IHF•A
: Below measurement limits
: DC14.4V (10.8~15.6V) negative ground
: Less than 1A
: 7.28lb. (3.3kg)
: 10.6"(Width)
3.9" (Height)
6.7"(Depth)
[268mm(W)
98mm(H)
170(D)mm]
Clarion Co.,Ltd.
All right Reserved. Copyright © 1998:Clarion Co., Ltd.
PE-2289 / 2287B 280-7254-00
Advertisement
