- Page 1 SAPPORO AUDIO TV BED LIFESTYLE SLEEPMOTION 200i 1.5 hour approx Two person assembly time assembly MK1 220603...
-
Page 2: Assembly Tips
Thank you Hello, thanks for choosing to purchase your bed from Dreams - you're now on your way to your best ever night's sleep. Before you begin building your bed, please take a moment to read through the instructions and make sure that you've got all the relevant parts listed on the following pages. -
Page 3: Parts List
Parts The TV Bed you have purchased comes with a Lifestyle Sleepmotion 200i electric bed base. Follow the instructions to assemble the bed around the base after first preparing the base as in Step 2. The footend of the bed is fitted with a real 6 channel Surround Sound amplifier that is connected to the television with the HDMI ARC cable - DO NOT REMOVE THIS CABLE - just connect the plug to the HDMI ARC socket on the side of the television - carefully read Step 8 before installing the television. -
Page 4: Tools Required
TV Installation Kit packed inside the accessory box in the footboard, Pack 2 (h) choose a pair of suitable bolt sets k x2 (j) choose a suitable Allen key Bolt set Counter-sunk screw Counter-sunk screw Allen key (4mm) Allen key (2.5mm) M8 x 25mm TV Support Slide set (M6x12mm) - Page 5 Prepare the electric bed base before assembling the bed frame. Screw in the eight longer 6" (15cm) legs as shown. Positioning the electric bed base. Place the headboard in the position in which it shall be used and attach the right hand side rail to the headboard bracket (D), using two bolt sets (a, b &...
- Page 6 Connecting power to the the electric base. Bring the powe r le ad out from the e le ctric base , unde rne ath the headboard. Connect the plug to the wall socket - for safety this must be an earthed power supply. iii) Raise both the head end and foot end of the bed base using the remote control.
-
Page 7: Electrical & Cable Connections
Plug the small power Electrical & Cable Connections plug on one end of the mains power lead (G) into the socket at the bottom of the footboard. On the other end of the lead, bring the 3 pin plug out under the headboard and connect it to your wall socket - for safety this must be an earthed... - Page 8 Bring the aerial lead (H) out under the headboard and plug it into the wall socket . Before connecting the television, please read the important information below. The bed is fitted with a real 5+1 six channel surround sound amplifier that should be connected to the television fitting the HDMI plug into the HDMI ARC socket on the side of the TV.
- Page 9 Height of TV is normally pre-set - follow this guide if it needs to be changed. Measure the height of the television and add 5mm to the height then adjust the column to suit.. Max TV Height 573mm Loosen the two column adjustment bolts, slide column so the curved lid lifter is just above the TV and re-tighten the two bolts.
- Page 10 IF HARDWARE IS SUPPLIED WITH THE TV, PLEASE USE IT IN PREFERENCE Fitting the TV. When spacers are provided it is very important that these are fitted in the correct place, fit between television Check the hardware supplied with & the TV mounting bracket (x) as in television and if Vesa screws and spacers are supplied please use these to fit the TV.
- Page 11 Note: For illustration purposes only, TV connections may vary. Keep wires tight so they TV Power Lead can't get supplied with the TV cover from cable clips & adhere to back of the TV. HDMI PLUG TO CONNECT TO THE HDMI ARC SOCKET ON THE SIDE OF THE TELEVISION PLUG IN - KEEP ALL LEADS TIGHT - USE CLIPS &...
- Page 12 Make sure everything is connected safely then fit the left hand side rail. Head board LH side side rail rail Check the bolts on the Make sure the bed is iii) Fit the side rail then tighten all x4 side rails are sitting squared up as shown.
- Page 13 Fit the remote control holster to left or right side rail. RC for TV Align the mattress base correctly using the sketch below as a guide. 20mm 20mm Sapporo Sleepmotion Lifestyle TV Bed - Assembly guide - Page 13...
- Page 14 Sapporo Real 5.1 SS Audio System HDMI (ARC) amplifier system Music Power total = 210 Watts. Three front speakers x30W Two Rear speakers x30W One Sub Woofer x60W OPERATION GUIDE TURN AMPLIFIER ON or OFF. SAPPORO 5.1 1) Turn on the mains power to the TV Bed. Remote Control (W) 2) Press the Remote Control (RC) ON button for 2 seconds to synchronise and prepare the system, system voice shall say 'Power On'.
-
Page 15: Care And Maintenance
Technical Specifications Max TV Size: 975 x 575 x 85 (WHDmm) Overall Dimensions (LWH mm) Double: 2285 x 1575 x 1240 King: 2385 x 1725 x 1240 Super King: 2385 x 2025 x 1240 Internal Dimensions (LW mm) Double: 1930 x 1380 King: 2030 x 1530 Super King: 2030 x 1830... - Page 16 TV BED SAFETY INFORMATION GENERAL INFORMATION It is very important not to place any vessel containing liquids, e.g. drinks or vase of flowers, on top of the TV footboard which may accidentally spill and enter the TV compartment as this could cause damage to the TV and/or the TV lifting equipment. If this happens, please contact Customer Services - ring 0800 652 6750.
- Page 17 Little dreamers Keep the little ones entertained while you assemble your new purchase.
Need help?
Do you have a question about the SAPPORO LIFESTYLE SLEEPMOTION 200i and is the answer not in the manual?
Questions and answers
we’ve moved house and lost remote control
The document does not provide specific instructions for replacing the remote control for the DREAMS SAPPORO LIFESTYLE SLEEPMOTION 200i. However, if the connection between the remote and the TV lift is lost, you can re-pair it by:
1. Disconnecting all mains power to the bed for at least 60 seconds.
2. Pressing and holding either the UP or DOWN button on the TV Lift Remote Control.
3. While holding the button, reconnect the mains power and keep holding the button for at least 5 more seconds.
4. The TV Lift should start moving, indicating that re-pairing is complete.
For a replacement remote, you may need to contact the Help Centre at 0800 652 6750 (or 028 9050 8300 for Northern Ireland).
